NEVADA GOLD TOPPER ASSEMBLY
FIELD INSTALL INSTRUCTIONS
TO BEGIN INSTALLATION
Center the topper assembly on the Nevada Gold Classic
or Nevada Gold II machine. The topper is held on by two
large magnets as shown below.
The cables need to be secured on the back of the base.
The cables may be secured to either side of the back of
the topper base.
OR
The power adapter has a 6 ft cord to the topper and then
a 6 ft cord to the wall outlet.
Arrow International, Inc. has made every effort to ensure that this user's manual is accurate.
Information in this user's manual is subject to change without notice.
Please visit the Arrow International website for the latest user manual updates.
https://equipment.arrowinternational.com/support#manuals
Advertisement
Table of Contents
Summary of Contents for Arrow International Nevada Gold Classic
- Page 1 The power adapter has a 6 ft cord to the topper and then a 6 ft cord to the wall outlet. Arrow International, Inc. has made every effort to ensure that this user’s manual is accurate. Information in this user’s manual is subject to change without notice.
- Page 2 If the middle button LED switched to OFF, all 9 sequences run continuously. The topper stores its configuration when power is removed. To access the panel you must remove the two screws at the top of the topper. © ARROW INTERNATIONAL INC. HH4895V7000-MNL...
