Eurotops 26815 User Manual

Pic 1
Pic 4
(1) LCD display (2) Contactors (3) breath inhaler (4) Flashlight (5) Battery (6) Power button flashlight (Figure 1)
Inserting the battery: 1. Open the battery compartment by pushing down the lid. 2. Insert two 1.5V AAA batteries, being sure to observe the
correct polarity, as shown in the battery compartment. 3. Close the battery compartment. (Picture 2)

Use of alcohol tester

Preparation

1. Press the power button once, the display will turn on and you hear a beep (Image 3).
2. The "warm up" symbol appears on the display and a countdown timer counts down from 10-0, the tester is in preparation mode.
Note
When first opening the package or after long disuse of the alcohol tester, the breath inhaler might contain many gases and air pollution on, in this
case, the tester requires a multiple preparatory phase, please press the power switch for this purpose more often.

Use

1. The "blow" symbol is shown on the display and a countdown from 10-0 is shown, then the tester is ready (Figure 4)
2. Approach your mouth to the breath inhaler and blow for 3-5 seconds in it.
3. Read off the test result.
4. In reaching a value of 0.02% BAC (oder0,2gll) to 0.05% (or O, Sg / 1) in addition appears a "caution" symbol on the display: 12:02% BAC (or
0.2gll) to 0.05% BAC (or 0.5g / l) 0.05% BAC (or 0.5gn) to 0.08% to BAC (or o.8gn) -. (Figure 5).
5. When you reach a value of 0.05% BAC (oder0,5gll) or more, in addition the "Danger" symbol appears on the display: over & EQUAL 0.05% BAC
(or O.Sg/1). over & EQUAL 0.08% to BAC (or 0.8gn)

Automatic shutdown

1. The test result is displayed for about 15 seconds, then an "Off ' icon appears for 2-3 seconds and the tester is turned off. 2. If not blown into the
breath inhaler during an ongoing test, the display shows 0.00 as the test result.
Note
To achieve a more accurate result, we recommend that you perform the test 2-3 times. Display Battery exhausted: When the "L" symbol flashes
when you turn on, the batteries are exhausted, please replace them. Replace the batteries at the latest if their capacity is no longer sufficient to turn
on and prepare.

Hand Strap

Please use the supplied carrying strap.
Flashlight: To use the integrated flashlight of the alcohol tester, press the button on the back of alcohol tester (Figure 6)

WASTE of electronic devices

The product must be disposed of in accordance with applicable standard regulations of the local community and should not be treated as household
waste. The product must be withdrawn from a recycling center or dealer for disposal. The distributor shall bear the costs for a product in accordance
with the statutory regulations of disposals. The product contains non-biodegradable components that may enter the environment if not disposed of
properly. Some of these parts can be recycled to prevent pollution. There is a general duty to protect the environment contribute.
The symbol shown indicates that the product is subject to the requirements of the new guidelines established to protect the environment (2002/96 /
EC, 2003/108 / EC. 2002/95 / EC). For more information on the disposal of waste, please contact your local authorities. Anyone who does not
dispose of the product in accordance with the above requirements must expect legal consequences.
(1) L'afficheur LCD (2) contacteurs (3) le souffle inhalateur (4) Lampe de poche (5) batterie (6) bouton d'alimentation de lampe de poche (Photo 1)
Insertion de la batterie: 1. Ouvrez le compartiment de la batterie en appuyant sur le couvercle. 2. Insérez deux piles 1.5V AAA, en étant sûr de
respecter la polarité, comme indiqué dans le compartiment de la batterie. 3. Fermez le compartiment de la batterie. (Photo 2)
Utilisation du testeur d'alcool
Préparation
1. Appuyez sur le bouton d'alimentation, l'écran se met en marche et vous entendrez un bip (Photo 3)
2. Le symbole «réchauffer» apparaît sur l'écran et un compte à rebours compte de 10 à 0, le testeur est en mode de préparation.
Note
pic 2
pic 5
EN - User Guide Digital Breathalyzer, Solutions 2 Go '
FR - Guide de l'utilisateur numérique alcootest, Solutions 2 Go '
pic 3
pic 6
