EP657/ HG-AF041S
PLEASE READ THE MANUAL BEFORE YOUR FIRST USE. KEEP THIS MANUAL
PRODUCT DESCRIPTION
Fig.1
TECHNICAL CHARACTERISTICS
Battery type: 3XAAA/LR03 (not supplied) 4.5V
3 LEDs: 1x white LED (strong intensity), 3W, 150 lumens
2 x red LEDS (flashing SOS signal), 0.1W and 1 lumen for each LED
LEDs' Classification (red and white): risk group 0 (no risk)
Ingress protection rating: IPX4 (resists against splashing water)
BATTERY INSTALLATION
1
FUNCTION DESCRIPTION
1.
LED LAMP ET SOS SIGNAL
The flashlight has 3 lighting modes: red LED, white LED (strong intensity) and flashing SOS signal.
Press the ON/ OFF button to switch between the 3 modes.:
1
Red LED
Light distance: up to 100 meters
INDUCTIVE SENSOR HEADLAMP
SAFE FOR FUTURE REFERENCE!
2
2
SOS
White LED
(Strong intensity)
1. ON/ OFF button (Red LED/ SOS/
Flashlight)
2. Button to open battery
compartment
3. Button to activate motion sensor
4. Battery compartment
5. LED flashlight
6. Red LED/ SOS
3
3
4
4
OFF
Advertisement
Table of Contents
Summary of Contents for Eurotops 40758
- Page 1 INDUCTIVE SENSOR HEADLAMP EP657/ HG-AF041S PLEASE READ THE MANUAL BEFORE YOUR FIRST USE. KEEP THIS MANUAL SAFE FOR FUTURE REFERENCE! PRODUCT DESCRIPTION 1. ON/ OFF button (Red LED/ SOS/ Flashlight) 2. Button to open battery compartment 3. Button to activate motion sensor 4.
- Page 2 2. LIGHTING TRIGGERED BY MOTION SENSOR Press white transparent button. To turn on, move your To turn off, move your hand in front of flashlight, hand again. from top to bottom or vice versa. Motion sensor range : about 25 cm 3.
- Page 3 This symbol indicates that electrical and electronic devices are collected selectively. The symbol shows a waste container crossed out with an X symbol. Imported by PRODIS SAS, 1 rue de Rome, 93110 Rosny-sous-Bois, France Marketed by EUROTOPS VERSAND GMBH D-40764 LANGENFELD, Germany Made in PRC...
