- Page 1 AlphaBlower EX 100 / 125 Manual February 2021...
- Page 2 RadonTec GmbH Hauptstraße 5 89426 Wittislingen - Germany Tel: (+49) 9076 - 919 98 35 E-Mail: info@radontec.de Website: radontec.de Shop: radonshop.com Version: 01...
-
Page 3: Table Of Contents
Operation with speed controller ......25 10.4 Operation with transformer ........26 10.5 Commissioning ............26 Maintenance............... 27 Troubleshooting ............28 Spare parts..............29 Transport and storage ..........30 Disassembly and disposal ........... 30 Manual – AlphaBlower EX 100/ 125... - Page 4 Circuit diagrams ............32 Two-year warranty ............. 34 Unterstützung und Kontakt ........35 Support and Contact ..........35 19.1 Troubleshooting/FAQ ..........35 19.2 Contact Us .............. 35 Manual – AlphaBlower EX 100/ 125...
-
Page 5: Introduction
(IP X4 - protection against splashing water from all sides and a temperature range of -25 °C to +50°C ). The built-in radial motor is extremely robust and designed for a long service life. Manual – AlphaBlower EX 100/ 125... - Page 6 Application example 1: Point radon extraction with discharge at floor level. Manual – AlphaBlower EX 100/ 125...
- Page 7 Application example 2: Point radon extraction under the floor slab with discharge above the roof. Manual – AlphaBlower EX 100/ 125...
- Page 8 Application example 3: Extraction of radon soil air via an external radon well. Manual – AlphaBlower EX 100/ 125...
-
Page 9: Technical Data
3 x 1.5 mm² Installation location Outdoor area Installation position vertical Material Sheet steel, galvanised Fluid temperature at IMax -20 °C to 70 °C Sound pressure level 52 dB(A) (distance 3 m, free field conditions) Manual – AlphaBlower EX 100/ 125... - Page 10 EX 100 EX 125 Nominal width 100 mm 125 mm Nominal power 50 W 49 W 0,22 A 0,22 A Delivery volume 300 m³/h 325 m³/h Weight 4,5 kg 4,4 kg Manual – AlphaBlower EX 100/ 125...
-
Page 11: Name Of The Parts
● AlphaBlower EX radon aspirator is supplied with square roof base. The roof base can be removed for direct pipe mounting. ● Accessory bag in terminal box: conduit grommet and strain relief with 2 fastening screws. ● Assembly and operating instructions Manual – AlphaBlower EX 100/ 125... -
Page 12: Product Features
Depending on the size and temperature conditions, the cooling time can be up to 30 minutes. Do not switch on the unit until this time has elapsed. Manual – AlphaBlower EX 100/ 125... -
Page 13: Dimensions
Dimensions Depending on the nominal width, the variants of the AlphaBlower EX have different dimensions. Dimensional drawing [mm] Dimensional drawing [mm] Manual – AlphaBlower EX 100/ 125... - Page 14 Dimensional drawing [mm] Dimensional drawing [mm] Manual – AlphaBlower EX 100/ 125...
-
Page 15: Intended Use
As well as installation close to the ground. • A fixed installation with permanently installed electrical supply cable is mandatory: • With roof base only on a suitable substructure. Manual – AlphaBlower EX 100/ 125... -
Page 16: Non-Permitted Operation
ISO 13857. We offer the matching protective grille for this as an option. (Must be purchased separately). Non-permitted operation RadonTec is not liable for damage caused by improper use. Do not use the unit under any circumstances: • For conveying air saturated with water vapour or containing grease •... -
Page 17: Ambient Conditions
The installation personnel must be height- and foot-safe. When working on the roof, sufficient safety precautions must be taken to protect the installation personnel. Manual – AlphaBlower EX 100/ 125... - Page 18 (near the floor). Secure the unit and piping against foreign bodies being sucked in. Risk of injury from objects in the impeller. Do not insert any objects into the unit. Manual – AlphaBlower EX 100/ 125...
-
Page 19: Assembly And Electrical Connection
2 metres. This can reduce wilful damage, tampering or the risk of injury to children or animals. Assembly and electrical connection Cutting injuries due to sharp-edged housing plates. Wear protective gloves. Notes • Observe the permissible roof load. Manual – AlphaBlower EX 100/ 125... -
Page 20: Fan Installation
2. Sufficiently dimensioned fastening material must be provided by the customer (screws with Ø 10 mm, min. strength class 8.8). 3. Screw the unit tightly to the roof, roof base or pipework. Manual – AlphaBlower EX 100/ 125... - Page 21 2. Mark the 4 mounting holes, drill them and insert the dowels. 3. Lift the unit and fit suitable insulation and soundproofing material. Manual – AlphaBlower EX 100/ 125...
- Page 22 OR fasten the spiral ducts to the fan with elastic collars or connecting pieces. 6. In the case of free intake, fit a protective grille as protection against contact and intake. 7. Fit suitable insulation and sound-insulating material. Manual – AlphaBlower EX 100/ 125...
-
Page 23: Electrical Connection
Pierce the cable grommet so that it can tightly enclose the mains cable. Manual – AlphaBlower EX 100/ 125... - Page 24 6. Connect the mains to the terminal strip according to the circuit diagram. 7. Fit a repair switch near the unit. (Can be ordered as an option) 8. Fit an on-off switch to be provided by the customer. 9. Connect optional accessories. Manual – AlphaBlower EX 100/ 125...
-
Page 25: Operation With Speed Controller
1. Observe the operating instructions of the speed controller. 2. Always set the minimum speed at the speed controller in such a way that the fan motor restarts after a voltage failure. Manual – AlphaBlower EX 100/ 125... -
Page 26: Operation With Transformer
4. Remove the restart fuse and switch on the mains fuse. 5. Carry out a function test. Check the smooth running of the impeller and ensure it if necessary. It is also important that the air can flow freely. 6. Switch off the unit. Manual – AlphaBlower EX 100/ 125... -
Page 27: Maintenance
Risk of injury from rotating impeller. Before removing the upper part of the casing, wait until the impeller has come to a standstill. Cutting injuries due to sharp-edged casing plates. Put on protective gloves. Manual – AlphaBlower EX 100/ 125... -
Page 28: Troubleshooting
Check the repair switch if necessary. Thermal overload Impeller blocked. Repair only protection of the permitted by a specialist: Check motor switches off impeller and clean if necessary. the fan. Impeller does not Motor too hot. rotate. Manual – AlphaBlower EX 100/ 125... -
Page 29: Spare Parts
Have the cause of the fault determined and eliminated by a trained electrician. Spare parts Spare parts are: Terminal box complete Operating capacitor Motor/impeller set When ordering spare parts, always state the type plate no. on the side of the type plate. Manual – AlphaBlower EX 100/ 125... -
Page 30: Transport And Storage
Danger to life due to electric shock. Switch off all supply circuits before accessing the terminals. Switch off the mains fuse, secure it against being switched on again and visibly attach a warning sign. Manual – AlphaBlower EX 100/ 125... - Page 31 The appliance contains recyclable materials and substances that must not be disposed of with other waste. At the end of its service life, the appliance must be disposed of in accordance with the regulations in force in your country. Manual – AlphaBlower EX 100/ 125...
- Page 32 Circuit diagrams AlphaBlower EX AlphaBlower EX with 5 stage transformer Manual – AlphaBlower EX 100/ 125...
- Page 33 AlphaBlower EX with speed controller Manual – AlphaBlower EX 100/ 125...
- Page 34 It is also void if the product has been repaired or altered by another EIC Inc. To obtain this warranty service, please contact us at: info@radontec.de Manual – AlphaBlower EX 100/ 125...
- Page 35 Should you have any further questions or require further help and technical support, please do not hesitate to contact us. RadonTec GmbH Hauptstraße 5 89426 Wittislingen - Germany Tel: (+49) 9076 - 919 98 35 E-Mail: info@radontec.de Website: radontec.de Shop: radonshop.com Manual – AlphaBlower EX 100/ 125...
