- Page 1 XVR Kit Quick Start Guide Please read the Quick Start Guide fully before using the product and keep it for your records. Related tools and documents of products, please download from http://www.metrahometheater.com.
-
Page 2: Safety Precautions
Statement Thank you for purchasing our products, if you have any questions or requires, please contact us. This Guidelines adapt for XVR and HD cameras in the kits.It will be updated subject to product’s updating; new version will be not noticed specifically. If this manual’s any products description not accord with the real products, please in kind prevail. -
Page 3: Step 1: Installation Preparation
XVR rear panel interface description：BNC Video input, CVBS Video output, Audio output, VGA Video output interface, HD video output interface, Audio input, Ethernet port, USB2.0 port, RS485 connection PTZ, power input, as below： Analog camera interface Description: power input interface, BNC video output interface, as below: Note: Images for instruction use only, your unit may look different but use the same methods. - Page 4 Step 2: Device Connection Use the 5ch power cable splitter to connect with the power supply, and other ends connect with XVR recorder and the HD cameras. Default XVR IP address: //192.168.1.88. Connection diagram below: 12V/5A Note: Images for instruction use only, your unit may look different but use the same methods. Step 3: Make sure XVR kit working properly：...
- Page 5 Start up the XVR, right click the desktop and enter the user login interface. Input the username and password, click " Login ". System default username : "admin" password : "12345". Enter preview interface after device start up. Preview interface include date and time of system, and channel name.
-
Page 6: Recording Settings
Shortcut Menu Introduction Right click to popup shortcut menu, the menu consists with the following three parts: Preview mode: Select the preview mode in the menu bar you prefer. Shortcut menu mode: There is Poll, Record，Add Camera, NVR image, you can click and then enter corresponding menu. - Page 7 3、Motion Detection Setting. Enable “Motion” to activate motion recording, motion sections have no more than 6 times each day. If the setting of manual record and motion record are overlapped, it can only save the motion records while motion detection comes up. Enter “Playback”...
- Page 8 Left click 【1-Win】/【4-Win】in the menu, and enter real time view interface, can add one or more cameras at the same time.
- Page 9 Webpage XVR Login １. Login to XVR on LAN (PC & XVR connected to same router LAN) 1. Make sure the XVR and the connected PC (computer) are in the same segment. If not, please set IP address of your PC to the same segment as the XVR’s, for example ‘192.168.1.33’， but it must be different IP as the XVR’s.
- Page 10 Mobile App Access Download and install SpyclopsPRO on a smart phone or tablet using either option below: 1. On the Android App Store or iPhone App Store enter “SpyclopsPro” search, download and install. 2. Scan the following QR codes to download and install the App. Android Run the SpyclopsPRO App (new users need to register an account to log in first).
- Page 11 8.1 Tap the device you would like to add 1. Tap in the upper left menu 9.1 Enter the username and password and tap Done. 2. Tap "Device" bar ; 9.2 Enter your choice of Device name, select the group 3.
- Page 12 4. Swipe left or right on the time line to change the recording time view. Note: Green bars are recording from schedule and Red is from motion detection. ©2020 Metra Electronics Corporation 460 Walker Street, Holly Hill, FL 32117-2699 Sp Specifications are subject to change without notice.
