Conceptronic C54PSERVU How-To

How to install within windows vista
Hide thumbs Also See for C54PSERVU:

Advertisement

Table of Contents

How to install the C54PSERVU within Windows Vista
This document describes how to install your printer using the Conceptronic C54PSERVU print server within
Windows Vista.

1. Installing the printer

Before you can print using the C54PSERVU you will need to install your printer as local printer. This means
you will have to connect it to your computer and install the correct Windows Vista drivers for your printer.
When correctly installed, your printer should be mentioned as default printer in Windows Vista. Check this by
going to "Start" » "Control Panel" » "Printers". In our example, we installed an Epson Stylus Photo 810, as
can be seen in the screenshot below. The green check icon represents the default printer.
An Epson Stylus Photo 810 installed as default local printer
When the printer is installed correctly as local printer, you can disconnect it from your computer and
connect it to the C54PSERVU in the network. Make sure you turn the printer on, otherwise the C54PSERVU
cannot recognize it.
®
Copyright
2008 by Conceptronic – All rights reserved
www.conceptronic.net
Page 1 of 7

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C54PSERVU and is the answer not in the manual?

Questions and answers

Related Manuals for Conceptronic C54PSERVU

Summary of Contents for Conceptronic C54PSERVU

  • Page 1 1. Installing the printer Before you can print using the C54PSERVU you will need to install your printer as local printer. This means you will have to connect it to your computer and install the correct Windows Vista drivers for your printer.
  • Page 2 2. Installing the C54PSERVU software Use the included CD-ROM or download the latest software from www.conceptronic.net. Start the auto run menu by clicking on “Autorun.exe” and choose the option “Install Print Server Manager”. Follow the onscreen instructions to install the software.
  • Page 3 You will now get the “Print Server List” in which the C54PSERVU should be listed. If it is not listed, you will need to click the “Refresh” button in order to search for available print servers. If it is listed, you can click the “Next”...
  • Page 4 “>” button. When you print server port is not mentioned at all, you will need to click the “Refresh” button. The “Configure Port” option can be left to “Auto”. When done, press the “OK” button. ® Copyright 2008 by Conceptronic – All rights reserved www.conceptronic.net Page 4 of 7...
  • Page 5 “Properties” window select the “Ports” tab. Look for a port that is called “<PRINTSERVER>-P1” (in our example this is “EPSON810-P1”), tick the checkbox in front of it and click the “OK” button. ® Copyright 2008 by Conceptronic – All rights reserved www.conceptronic.net Page 5 of 7...
  • Page 6 You will now need to set the print server to get an IP address automatically. Go to “Start” » “All programs” » “Conceptronic” » “C54PSERVU” » “Server Manager” and click on “PrintServer Configuration”. The Server Manager will be opened and your print server will be mentioned in the left column. Select it and click the second button in the button bar (“Setup”).
  • Page 7 The last thing that you will need to do is setting the printer to online status. Go to “Start” » “Control Panel” » “Printers”, right click your printer and select “Use Printer Online”. Your Conceptronic C54PSERVU and printer are now set up and ready to be used within Windows Vista. ®...
