- Page 1 Control button Rose Stirrup Overflow Lift rod Blocking clip Seal Plug Plug seal Plug nut Cistern seal STORM SWITCH 33A / ASSEMBLY MANUAL Réf. 5539 - Imprimerie PONS s.a.
- Page 2 I - PREPARATION OF THE MECHANISM Measure the cistern: - H (from top of lid to inside bottom of cistern) - D (diameter of hole in lid) ➌ ➍ Check the positioning of the stirrup if the stirrup (k) is positioned correctly with reference to the table below, move on to step ➑...
- Page 3 III - ASSEMBLY OF CISTERN TANK IV - ADJUSTMENT OF WATER LEVEL First connect your float valve to the water system, open the stop valve and adjust the Full flush level using the float valve (see on back). NB: the maximum water level should be 20 mm below the overflow (j).
- Page 4 Membrane Adjustment screw Locking Gasket/filter Fiber gasket Locking nut 4, quai Antoine 1 - BP 219 - MC 98007 MONACO Cedex Tél. 00 377 93 15 53 75 - Fax : 00 377 92 05 71 04 - E-mail: contact@siamp.com...
