Thank you for purchasing a Shelti product. All of us at Shelti want you to be completely satisfied with
your Foos game, so feel free to contact us for help with the assembly of your product, Shelti parts, or
other information you may require.
Tools Required:
1/2" Wrench
3/4" Wrench
Hammer
Phillips screwdriver
Level
STEP #1
•
Remove the following parts from the Foos 400 accessory box.
Description
Shelti Soccer Leg Assembly
Goalie Rod Assembly
5 - Man Rod Assembly
3 - Man Rod Assembly
2 - Man Rod Assembly
C - Accessories Bag
C - Assembly Instructions
Shelti Rubber Bumper
Shelti Soccer Man Red
Shelti Soccer Man Black
Spirol Pin
5/16" Flat Washer
5/16" Hex Nuts
Score Posts
Score Rods
Red Score Beads
Black Score Beads
#8 x 2" Wood Screw
Spirol Pin Punch
Super Lube Tube
Balls
Rod Block
Assembly Instructions
Part Number
CS-SSL-0
ES-GRA-0
ES-5RA-0
ES-3RA-0
ES-2RA-0
CS-ASA-0
210-0001-0
203-0001-0
201-0001-0
201-0005-0
205-0006-0
303-0002-0
302-0002-0
201-0006-0
205-0007-0
003-0002-0
003-0003-0
304-0005-0
210-0012-0
210-0002-0
201-0007-0
102-0070-0
Quantity
4
2
2
2
2
1
1
16
13
13
26
8
8
4
2
5
5
4
1
1
3
1
