Thank you for buying a PlymoVent product.
Before you unpack and put it into operation
please read this product manual, and follow the instructions.
THIS MANUAL SHOULD BE HANDED OVER
AND KEPT BY THE SERVICE DEPARTMENT
English 071201
Product User Manual
DCV-Controller

Table of contents

1 Technical data ....................................................2
1.1 Frequency Inverter ....................................2
1.2 Pressure Transmitter ................................2
2 Safety Information .............................................3
3 Function .............................................................3
4 Installation - Mechanical ............................... 4-5
5 Installation - Electrical ......................................5
5.1 Important information ................................5
5.2 Mains connections ....................................5
5.3 Motor connections ....................................5
5.4 Control cables ...........................................6
6 Configuration .....................................................7
6.1 Control keys ..............................................7
6.2 Application specific data ...........................8
6.3-6.5 Programming .................................. 9-10
7 Start-up ............................................................10
EU Declaration of Conformity ................... 11-12
AFTER THE INSTALLATION!
Page:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DCV and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Plymovent DCV

  • Page 1: Table Of Contents

    6.3-6.5 Programming ........9-10 7 Start-up ............10 EU Declaration of Conformity ....11-12 Thank you for buying a PlymoVent product. Before you unpack and put it into operation please read this product manual, and follow the instructions. THIS MANUAL SHOULD BE HANDED OVER...
  • Page 2: Technical Data

    © Copyright: All rights reserved. Nothing from this publication may be reproduced, handed over, DCV-Controller copied, or translated into other languages, in any form or means without written permission from Ply- moVent AB. PlymoVent AB reserves the right to make design- and technical changes without notice. DCV-Controller TO ACHIEVE OPTIMUM PERFORMANCE AND...
  • Page 3: Safety Information

    For complete safety information – consult the inverter handbook Function The DVC-Controller will operate your process ventilation by monitoring the air pressure of your system. The DCV-Controller will only run the fans to meet the demand of your production and do it automatically. 3 / 10...
  • Page 4 © Copyright: All rights reserved. Nothing from this publication may be reproduced, handed over, copied, or translated into other languages, in any form or means without written permission from Ply- moVent AB. PlymoVent AB reserves the right to make design- and technical changes without notice. EXAMPLE OF INSTALLATIONS:...
  • Page 5: Installation - Mechanical

    © Copyright: All rights reserved. Nothing from this publication may be reproduced, handed over, DCV-Controller copied, or translated into other languages, in any form or means without written permission from Ply- moVent AB. PlymoVent AB reserves the right to make design- and technical changes without notice. Installation – Mechanical •...
  • Page 6: Control Cables

    Application with start/stop using the frequency inverter panel (continuous running). 5.4.2 Application with start/stop using an external NO (normally open) switch. External switch 5.4.3 Applications with integrations with PlymoVent control equipment for start and stop of the system. ICE-LC ICE-LC...
  • Page 7: Configuration

    © Copyright: All rights reserved. Nothing from this publication may be reproduced, handed over, DCV-Controller copied, or translated into other languages, in any form or means without written permission from Ply- moVent AB. PlymoVent AB reserves the right to make design- and technical changes without notice. Configuration Control Keys...
  • Page 8: Application Specific Data

    6.2 Application specific data Do not neglect to fill out the values below. They are needed if for some reason the unit lost it’s configuration example: after a long term power failure. Prior to the configuration of the frequency inverter some application data needs to be determined: 6.2.1 Determine the pressure (Set value) that should be used in this application, at the measuring point of the pressure transmitter. (Extraction arm + system normally 800-900Pa). Value: __________ Pa 6.2.2 Note the lowest measuring value for the pressure transmitter.
  • Page 9: 6.5 Programming

    Initiate programming • !!! Put the switch A54, (under the display), in position I (to the right). The inverter must be without power. Restoring to factory settings Press MAIN MENU twice Special functions 14.2 Reset functions 14-22 Operation Mode Initialisation (2). Important! After point 6.4 is completed, disconnect power to the frequency inverter and wait until the display goes blank.
  • Page 10: Start-Up

    © Copyright: All rights reserved. Nothing from this publication may be reproduced, handed over, DCV-Controller copied, or translated into other languages, in any form or means without written permission from Ply- moVent AB. PlymoVent AB reserves the right to make design- and technical changes without notice. 20-21 Setpoint 1 See 6.2.1 (normally 800-900Pa).
  • Page 11: Eu Declaration Of Conformity

    Reg.nr: 2.25-1 Edition: 4 Date: 080512 EU Declaration of Conformity We hereby declare that the equipment described below conforms to the relevant fundamental safety and health requirements of the appropriate EU Directives, both in its basic design and construction as well as in the version marketed by us.
  • Page 12 Podj˜to odpowiednie “rodki wewn•trzzak–adowe w celu zapewnienia sta–ej zgodno“ci urz•dze— produkowanych seryjnie z wymaganiami aktualnych Dyrektyw UE i odpowiednich norm. Podpisuj•cy deklaracj˜ s• upowa”nieni do reprezentowania i podejmowania dzia–a— w imieniu kierownictwa firmy. PRODUCT: CONTROL EQUIPMENT BATCH NO: 04401--XXXXX MODELS: ICE-LC, ES-90, DCV/TG M-1000, PCU-1000, SA-24, ECMOA EU-DIRECTIVES: 89/336/EEC, 92/31/EEC EN 61000-6-4...
