Summary of Contents for Entec Wearable Air Purifier Mask
- Page 1 Korean English Wearable Air Purifier Mask User Manual DAEHYUNENTEC...
-
Page 2: Table Of Contents
CONTENTS Ⅰ. Usage and Features of the Product ································ 1 Ⅱ. Cautions ················································································ 2 Ⅲ. Method for Usage ······························································ 3 Ⅳ. Storage and Maintenance ················································· 6 Ⅴ. Product Configurations ····················································· 8 Ⅵ. Product Specifications ······················································· 9 Product Warranty A/S Application... -
Page 3: Ⅰ. Usage And Features Of The Product
Ⅰ. Usage and features of the product Use it outdoor when the air quality is bad Use it at dusty workplace Product explanation This product uses a filter to purify fine dust and other contaminants, supplying fresh air thereafter to the user's face. Features The product is equipped with a filter and air flow control for proper air supply ... -
Page 4: Ⅱ. Cautions
Ⅱ. Cautions Warning Do not use without filter. Fine dust is not blocked. Do not use if the oxygen concentration in the room is less than 18%. Be sure to use the parts included in the product diagram and not to use the product ... -
Page 5: Ⅲ. Method For Usage
Ⅲ. Method of Usage Filter Installation Replace the filter with the power turned off. Lift the cover under the mask and insert the filter Close the cover and press it to make a click sound. Controller Using Method ①... - Page 6 Ⅲ. Method of Usage Wear Mask Buckle-type head strap ① Unhook the head strap, place the entire mask face in front of your face, and fill the buckle of the head strap behind your head. ② Adjust the length of hair strap to fit your face. ③...
- Page 7 Ⅲ. Method of Usage Use/Charge The charging controller turns on a red light, and currently used one illuminates a blue light. The light is removed after it is fully charged. When the controller is off, the remaining of battery can be determined by the ...
-
Page 8: Ⅳ. Storage And Maintenance
Ⅳ. Storage and Maintenance Storage Store the product in a dry, clean place when it will not be used for a long time. Keep the product out of direct sunlight and store away from heat, oil, organic vapor and moisture. Pre-operation is required to obtain the battery capacity of the controller when ... - Page 9 Ⅳ. Storage and Maintenance Troubleshooting If the product does not operate smoothly, follow the Troubleshooting Guide. If the problem is not solved after checking, please contact us or apply for A/S. Problems Cause Solution Press and hold the power button on The power was not turned on the controller for 3 seconds The controller was not charged...
-
Page 10: Ⅴ. Product Configurations
Ⅴ. Product Configuration Product name Quantity Product name Quantity Front body Silicon holder Rear body Controller Filter Battery Filter cover Motor Filter body Charger Filter inner cover 5 pin cable Face silicon Head strap (Velcro type) Pass silicon Head strap (Buckle type) * Filter and Face silicone can be purchased separately. -
Page 11: Ⅵ. Product Specifications
Ⅵ. Product Specifications Category Specification Mask : 120mm x 110mm x 120mm Size Controller : 10mm x 3mm x 3mm Weak : 100 L/min Air flow rate Middle : 120 L/min Strong : 140 L/min Weak : 5hr Operational time Middle : 4hr Strong : 3hr Operational temperature... - Page 12 Product warranty Product Name Wearable Air Purifier Mask Model Name DH-WAPM1 Warranty Period 12month for free, 10 years for paid This product has been completed through strict quality test. Free repair is possible within the warranty period if a failure occurs during the ...
