Summary of Contents for PRO-DESIGN B-SAFE 105
- Page 1 1 of 15 OWNERS MANUAL B-SAFE 105 light weight reserve system for the Paraglider edition 31.03.2009 www.pro-design.at PRO-DESIGN version 1.1 03.09...
-
Page 2: Table Of Contents
2 of 15 TABLE OF CONTENTS 1-5 GENERAL INSTRUCTIONS General guidelines Use with paragliders Limitations Duration of use Technical data 6-7 OPERATING INSTRUCTIONS Deployment instructions Packing instructions Photo instructions 8. MAINTENANCE Disclaimer and Safety Notice Warranty PRO-DESIGN version 1.1 03.09... -
Page 3: General Guidelines
3. LIMITATIONS The B-SAFE 105 may only be used as a rescue system with Paragliders. It is not permitted to use this rescue device as a skydiving chute or as a normal flying chute. -
Page 4: Duration Of Use
WARNING Manufacturer and seller of the rescue system B-SAFE 105 do not take any liability for risks in Paragliding. Also accidents, loss, improper handling, improper maintenance, direct and indirect damages, which occur through the use of the rescue system are in the responsibility of the pilot. -
Page 5: Packing Instructions
7. PACKING INSTRUCTIONS 1. The rescue chute B-SAFE 105 is easy to pack. Accuracy is the most important thing when packing the chute. The right sequence of the opening is the most important requirement for a fast and faultless deployment of the rescue system. This fact was one of the important guidelines during construction. - Page 6 (Photo 23). Then close the right side of flap same way and make a line loop through the rubber ring (Photo 24). Finally close the left side of flap same way and make a line loop through the rubber ring (Photo 25). Packing is now finished. PRO-DESIGN version 1.1 03.09...
- Page 7 6. count again if left and right symetrically (each 12), with panel number 1 up 7. separate line bundles, left and right 8. check lines for free running without same number of lines, center line in the middle entanglement PRO-DESIGN version 1.1 03.09...
- Page 8 11. .. then on the other side 12 remove line from packing loops (very important, don't forget!) 13. place inner container aside 14. fold canopy into S-folds .. folded basis 15. .. more folds .. 16. .. until finished PRO-DESIGN version 1.1 03.09...
- Page 9 23. close flap by guiding center rubber ring 24. close right side of flap same way and make through left side flap slit and then through front a line loop through rubber ring flap slit, make a line loop through rubber ring PRO-DESIGN version 1.1 03.09...
- Page 10 For the connection of the bridle of the reserve with the bridle of the harness you may use a sufficient strong carbine (Photo 26). DO NOT FORGET TO REMOVE THE SPARE-LINES. 19. Check the function by a test opening! PRO-DESIGN version 1.1 03.09...
-
Page 11: Maintenance
Every two years you should bring your rescue system to PRO-DESIGN or to a proffessional packer to have it checked. -
Page 12: Warranty
01.01.2008 for the period of 1 year. This guarantee covers failures caused by material or production problems for which PRO-DESIGN should be responsible. 2. This Guarantee is valid for all DHV-certified products from PRO-DESIGN, that are used for leisure flights. The guarantee does not include products which are used for educational or professional purposes. - Page 13 3. The customer also has the option of acquiring a new product if an appropriate amount is paid to make up the difference in value. Good faith PRO-DESIGN is under no obligation beyond those described above. It is possible, however, that it will make a good faith settlement. PRO-DESIGN Hofbauer GmbH., PRO-DESIGN &...
- Page 14 14 of 15 PACKING- AND CHECKING BOOKLET RESERVE SYSTEM B-SAFE 105 Type: B-SAFE 105 Manufacturer: PRO-DESIGN Zimmeterweg 4 A-6020 Innsbruck, Austria PRO-DESIGN version 1.1 03.09...
- Page 15 It is recommended to have the reserve system re-packed and checked every 4 months. If you do not follow this advice, slow opening or even failure of the operation may result. CHECKS NUMBER WORK DONE RESULTS NEXT CHECK DATE, SIGNATURE First general check To be re-checked every two years. Changes reserved. PRO-DESIGN version 1.1 03.09...
