Access & Power Integration
T2KK3F8
8 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove2 enclosure with TKA2 Altronix/Keyscan backplane
- (1) eFlow6NB - Power Supply/Charger
- (1) ACM8 - Fused Access Power Controller
- (1) T16100 Transformer
T2KK3F8Q
8 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove2 enclosure with TKA2 Altronix/Keyscan backplane
- (1) eFlow6NB - Power Supply/Charger
- (1) LINQ2 - Network Communications Module
- (1) ACM8 - Fused Access Power Controller
- (1) T16100 Transformer
All components of these Trove kits are UL Listed sub-assemblies.
Please refer to the included corresponding Sub-Assembly Installation Guides for further information.
Installation Guide
All registered trademarks are property of their respective owners.
Rev. TKK072817
Installing Company: _____________________ Service Rep. Name: __________________________________________
Address: ________________________________________________________ Phone #: _________________________
T2KK3F8D
8 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove2 enclosure with TKA2 Altronix/Keyscan backplane
- (1) eFlow6NB - Power Supply/Charger
- (1) ACM8CB - PTC Access Power Controller
- (1) T16100 Transformer
T2KK3F8DQ
8 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove2 enclosure with TKA2 Altronix/Keyscan backplane
- (1) eFlow6NB - Power Supply/Charger
- (1) LINQ2 - Network Communications Module
- (1) ACM8CB - PTC Access Power Controller
- (1) T16100 Transformer
