Rixson 1351 Installation Instructions

RIXSON
ASSA ABLOY
Model 1351

Max. Gate Size: 54" x 120"

Pull Side Mount ONLY

1
Locate and mark closer mounting plate.
Using one aluminum slide track (B), insert it
into the closer mounting plate (A). This insures
the track will be in exact alignment to the closer
body. Mark the hole locations on the post.
IMPORTANT: Position (A) so the closer portion of
the plate will be mounted to the pull side of the gate.
2
mounted in either orientation.) Use
and
mounting. Use
tubular post mounting. Attach (A) with
four hex screws. If the gate post is
masonry, use the longer screws with
the anchors included in the package. If
tube post extends above gate, use
masonry hole locations.
1351IS (06-13)
®

Tools Required

B
Mount plate to post on pull
side of gate. (Note that this
plate is not handed so it can be
holes for masonry post
and holes for
1351 Gate Closer
Installation Instructions
25mm
5.5mm
Tube Post
www.rixson.com
1351IS (06-13)
Slide "B" into "A"
A
Push
Side
Hinge
Side
6mm
50mm
40mm
8mm
8mm
866-474-9766 Technical Department
Masonry
Post
