1825 VIA BURTON
ANAHEIM CA 92806
714-772-5202 / FAX 714-772-2302
EMAIL: MAIL@MAJORMFG.COM
WEB: WWW.MAJORMFG.COM
INSTRUCTIONS
FOR
HIT-40AR8
RETRO FIT TEMPLATE
TO INSTALL AR STYLE
4560,61, 65, 68 & 69 LEVER HANDLE
AND
4590 & 4591 PADDLE HANDLE
WHEN USING POWER TOOLS
ALWAYS WEAR
EYE AND EAR PROTECTION!!
Copyright 2008 Major Manufacturing, Inc.
Advertisement
Table of Contents
Summary of Contents for Major Manufacturing HIT-40AR8
- Page 1 EMAIL: MAIL@MAJORMFG.COM WEB: WWW.MAJORMFG.COM INSTRUCTIONS HIT-40AR8 RETRO FIT TEMPLATE TO INSTALL AR STYLE 4560,61, 65, 68 & 69 LEVER HANDLE 4590 & 4591 PADDLE HANDLE WHEN USING POWER TOOLS ALWAYS WEAR EYE AND EAR PROTECTION!! Copyright 2008 Major Manufacturing, Inc.
- Page 2 Put the 1/4” dowel pin in the HIT-22 guide and slide the HIT-40AR8 drill guide over the top. Square to the door with a combination square. Hold firmly to the door and drill the top hole with a #21 drill.
- Page 3 10-32 tap. Remove the HIT-22 drill guide. The 4580 cam driver for the lever handle is shown on the right. Install in the cylinder hole and tighten the cylinder set screw. Page 2 Copyright 2008 Major Manufacturing, Inc.
- Page 4 The lever handle can now be installed in the cam driver. Install mounting screws both top and bottom and install the lock faceplate. Installation is now complete. That’s all there is to it! Page 3 Copyright 2008 Major Manufacturing, Inc.
- Page 5 Install the two binder posts and secure with the 1/4-28 hex nuts. Reinstall lock and 4580 cam disc. The cam disc is secured with the cylinder set screw. Page 4 Copyright 2008 Major Manufacturing, Inc.
- Page 6 While there sign up for our newsletter and we will email new product information directly to you. Page 5 Copyright 2008 Major Manufacturing, Inc.
