IF YOU CANNOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS
INTRODUCTION
This remote control system offers the user a 110-120 VAC powered multi-purpose remote control to be used with AC pow-
ered products such as lamps, heaters, fans, electric fireplaces and lighting from up to 30 feet away. The system operates
on one of 10,000,000 security codes that are programmed into the transmitter at the factory.
TRANSMITTER
The transmitter operates on (1) 3-volt Lithium CR2450
button cell battery (included), capable of a 3 year battery
life. Battery life is calculated at an average of 20
activations per day.
Before using the transmitter, look for a small notch under
the battery cover and slide the cover toward the notch and
lift it off.
Underneath the battery is an insulation tab. Pull the tab out
from underneath the battery. Note: Below the area where
the battery is installed is a slide switch that shows 3
different positions. This 3 position switch is not used with
this system. Ensure the switch is in the #1 position and
reinstall the battery cover.
There is a low battery indicator built into the transmitter. A
red LED flash will blink once every 4 second indicating the
battery level is low.
Skytech: 7015
MODEL: 7015
Installation AND OPERATING INSTRUCTIONS
DO NOT ATTEMPT TO INSTALL OR OPERATE
The button transmitter has a green and red LED light ring that
ilimunates when you press and release the top button. Tapping
the transmitter one time, turns the appliance ON, emitting one
green blink. Double tapping the transmitter turns the appliance
OFF, emitting two red blinks.
The receiver plugs directly into a polarized 110-120 VAC
grounded receptacle. Then an AC powered appliance is plugged
directly into the receiver which is controlled by the transmitter
(remote control). In addition the receiver has a red LED indicator
light verifying power to the receiver.
If an extension cord is required, only use a (Model 18SPT-3) cord
consisting with an appropriate temperature rating for the intended
use. Both ends of the extension cord must be grounded and
polarized. An extension cord can be purchased from your
appliance dealer.
Remove Battery
Cover
Look for notch
Tab
UP
CR2450
CR2450
Battery
1
3
2
REV. 8-5-20 Page 1
Advertisement
Table of Contents
Summary of Contents for PG Skytech 7015
- Page 1 MODEL: 7015 INSTALLATION AND OPERATING INSTRUCTIONS IF YOU CANNOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS DO NOT ATTEMPT TO INSTALL OR OPERATE INTRODUCTION This remote control system offers the user a 110-120 VAC powered multi-purpose remote control to be used with AC pow- ered products such as lamps, heaters, fans, electric fireplaces and lighting from up to 30 feet away.
- Page 2 TRANSMITTER CONT. BATTERY REMOVAL Tools Needed: Small jewelers screwdriver or a pen. Remove the battery cover. Hold the transmitter upside down in one hand and with the other hand use a pen or small screwdriver to pull down the metal clip. The battery will “pop”...
- Page 3 INSTALLATION Installation is simple. Plug the receiver into a polarized 120 VAC grounded receptacle/outlet. Plug your AC powered electrical appliance into the receptacle of the receiver and turn the appliance switch ON. At the bottom of the receiver directly Recessed Button above the indicator light is a recessed “learn”...
- Page 4 TROUBLESHOOTING If you encounter problems with your 7015, the problem may be with the electrical appliance itself, the remote or the receiver. Review the electrical appliance manufacturer’s operation manual to make sure all connections are properly made. Then check the operation of the remote in the following manner: •...
- Page 5 Federal Communication Commission Interference Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 6 LIMITED WARRANTY 1. Limited Warranty. Skytech II, Inc. (“Skytech”) warrants that each new Skytech Control System, including all hardware, parts and components (the “System”), when used in accordance with the instructions furnished by Skytech provided with each System, shall be free in all material respects, of defects in materials and any workman- ship under normal use, subject to proper installation (“Limited Warranty”).
- Page 7 hardware, component or part repaired by Skytech hereunder, or any replacement System, hardware, component or part shall be shipped to the Customer by Skytech at Skytech’s cost and the Warranty, the Additional Terms, and all other terms and conditions set forth herein shall extend to such repaired or replacement System, hardware, component or part. Skytech shall pay no refund before Skytech from the Customer receives the defective System, hardware, component and/ or parts.
