- Page 1 DC / AC DIGITAL MULTIMETER (CAT III 300V) The reproduction of this document (even in partial form) is prohibited without the Fasangas S.r.l. authorization...
-
Page 3: General Description
Usable to test various devices or for the environment, the Fasano Tools multimeter is a versatile and high-performance instrument. This instrument has been designed in compliance with the IEC 61010 standard (Standard CEI EN 61010-1 / A1: "Safety requirements for electrical measuring,... - Page 4 ATTENTION Never use the multimeter for measurements that require category IV instruments To avoid electric shock or personal injury, follow these instructions: o do not use the multimeter if damaged. Before use, check the appliance. Pay particular attention to the insulation of the connectors o check the tips for any damage to the insulation and make sure that there are no exposed metal parts.
- Page 5 o correctly use tips, functions and ranges according to the measurement you want to take o before making current or temperature measurements, check the multimeter's fuses and turn off the equipment being measured before connecting the multimeter to it o before switching the multimeter between the different functions, disconnect the test leads from the tested equipment AC (Alternating Current) DC (Direct Current)
-
Page 6: Front Panel
REF. DESCRIPTION / USE 3 3/4 Digital LCD Display - maximum reading capacity 3999 points Range mode to manual selection mode Func is button to switch from direct current mode to alternating current mode or between diode function and continuity function "Hold"... -
Page 7: Lcd Display
The sensors are located at the top of the meter and inside the case. 1. Sound sensor 2. Light sensor 3.Humidy sensor Continuity test is selected Diode test is selected Autorange modeis selected Relative mode is active Data Hold is enabled Negative sign Battery is low and must be replaced immediately... - Page 8 1MHz=10 kHz=10 Unit of %: percent Unit of illumination lx: lux Unit of sound measurement Unit of relative humidity %: percent DISPLAY: 3 3/4 LCD with a max. reading of: 3999 NEGATIVE POLARITY INDICATION: negative sign shown on the display automatically SAMPLING RATE: 2 to 3 time/sec IP GRADE:...
- Page 9 RANGE RESOLUTION ACCURACY OVERRANGE INDICATION 1 mV OL shown on the display ±(1.0%+5) 40 V 10 mV 300 V 100 mV Input impedance: Max. allowable input voltage: 300V DC/AC Frequency range: 40 Hz - 400 Hz Response: avarange (calibrated in rms of sine wave) [1] DANGER if the voltage being measured is >...
- Page 10 Overload protection: for mA°C terminal inputs only: 500mA/300V Fast fuse for 10A terminal inputs only: 10A/300V Fast fuse Max. Input current: 10A (for inputs > 2A: measurement duration <10 seconds, interval > 15 minutes) Max. voltage drop: 400 mV Frequency range: 40 Hz - 400 Hz Response: averange (calibrated in rms of sine wave)
- Page 11 RANGE RESOLUTION ACCURACY OVERRANGE INDICATION 4 nF 0.001 nF 40 nF 0.01 nF ± (4.0% + 5) OL shown on the display 400 nF 0.1 nF 1 nF 10 nF 100 nF ± (8.0% + 5) RANGE RESOLUTION ACCURACY OVERRANGE INDICATION -20°C~ 400°C 0.1 °C...
- Page 12 RANGE RESOLUTION ACCURACY OVERRANGE INDICATION 30% ~ 90% 0.1% Working temperature: 0°C ~ 40°C Response time: 45% RH utes [1] if the humidity being measured is out of the range of 30% ~ 90% the display may show a reading but, the measurement error my be large. RANGE RESOLUTION ACCURACY...
-
Page 13: Hold Mode
The relative mode can be used with all functions but not with the Frequency function and the Duty Cycle function. By selecting Relative Mode, the multimeter stores the measurement made and uses it as a reference value for subsequent measurements. 1. -
Page 14: M E A S U R I N G D C O R A C V O L T A Ge
e. When the unit of measurement "A" is shown on the display and the current to be measured exceeds 10A The buzzer emits 5 beeps 1 minute before the multimeter automatically turns off and, a longer sound immediately before the multimeter automatically turns off. 1. -
Page 15: C A P A C I T Y M E A S U R E M E Nt
1. Connect the black test lead to the "COM" jack and the red test lead to the jack 2. Set the switch to 3. Press the "FUNC" button until the icon appears on the display 4. Touch the leads you want to test with the test leads 1. -
Page 16: S O U N D L E V E L M E A S U R E M E Nt
With this multimeter it is also possible to perform relative humidity measurements. The integrated sensor is positioned near the% RH icon on the top of the multimeter. 1. Place the selector on the% RH position 2. Place the multimeter in the place where you need to measure relative humidity. 3. -
Page 17: Maintenance
If the position of the selector is not changed or any button is pressed within about 15 minutes, the backlight of the dispay switches off and the multimeter enters "Sleep" mode. To exit the "Sleep" mode, simply change the position of the selector or press any button. To disable the Auto Power Off function, hold down the FUNC key while turning on the Meter. - Page 18 This tool is guaranteed free from manufacturing and material defects, for normal service use, for a period of one year. If during this period the instrument should encounter defects attributable to the manufacturer, the Fasangas Srl company will act, at its discretion, repairing the appliance or replacing it with others of equal value and characteristics without any expense for the buyer.
