Summary of Contents for DAYLIFF DPW
- Page 1 HIGH PRESSURE WASHER Installation & Operating Manual...
- Page 3 INDEX SPECIFICATIONS WARNINGS USE & MAINTENANCE TROUBLE SHOOTING TERMS OF WARRANTY © Davis & Shirtliff Ltd 2020 Contents herein are not warranted...
-
Page 4: Specifications
1. SPECIFICATIONS Soap Nozzle Dayliff DPW pressure washers are quality engine drive units designed for all washdown and cleaning applications where electric power is unavailable particularly for vehicles, compounds, production lines, tanks etc. The units are powered by economical and reliable Dayliff petrol engines and are mounted on a wheeled frame and supplied with a complete set of accessories including:- •... - Page 5 PUMP DATA Max. Pressure 200 Bar Pump 8.7L/Min Max. Volume Type Air-cooled, 4 stroke OHV petrol engine Displacement 179cc Rated Output 5.5HP Engine Fuel Tank 3.6L Operating Time 2 hours Fuel Consumption 1.8L/Hr Length Width Dimension (mm) Height Weight (Kg)
- Page 6 2. WARNINGS Do not allow children or untrained personnel to operate the pressure washer. CAUTION Do not use the pressure washer if supply cord or other important parts of the equipment are damaged, e.g. safety devices, high pressure hoses, trigger gun. WARNING High pressure hoses, fittings and couplings are important for safety of the appliance.
-
Page 7: Use And Maintenance
The recoil force will arise due to the water stream ejecting from the spray lance. The gun and spray lance should be held firmly . CAUTION Do not change any safety devices. CAUTION Ensure engine is switched off before performing any maintenance or service. -
Page 8: Start Switch
Turn engine ON/OFF switch to ON position. Pull start handle and start engine (Fig 4). Ÿ Start switch Fig 4 Five jet nozzles are supplied that give different sprays according to application. These Ÿ can be easily changed by screwing it to the handle head. High pressure hose should be connected to water-outlet and water-inlet hose should Ÿ... -
Page 9: Regular Service
Fig 6 REGULAR SERVICE PERIOD performed at Before First Every 3 Every 6 Every every indicated month of each Month or months months or 100hrs operating hour interval 5hrs or 25hrs or 50hrs whichever comes first ITEM Check Level Engine Oil Change Check Air Cleaner... -
Page 10: Troubleshooting
4. TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Connect to water supply No water supply Washer starts, but no Clean the filter water comes out Water filter blocked Clean the nozzle Nozzle blocked Screw is loose Tighten Screw Water leakage or oil leakage Change O-ring or washer O-ring or washer is broken... -
Page 11: Terms Of Warranty
5. TERMS OF WARRANTY i) General Liability • In lieu of any warranty, condition or liability implied by law, the liability of Davis & Shirtliff (hereafter called the Company) in respect of any defect or failure of equipment supplied is limited to making good by replacement or repair (at the Company's discretion) defects which under proper use appear therein and arise solely from faulty design, materials or workmanship within a specified period. - Page 12 www.davisandshirtliff.com INS392A-03/18...
