Garmin Group Ride Instructions

Group Ride
INSTRUCTIONS

Mounting the Antenna

NOTE: The mounted antenna must be at least 4 cm (1.57 in.)
away from the nearest roll bar or metal surface to avoid radio
interference.
You can use the external antenna mount to mount your antenna
in a more suitable location for your vehicle, such as a roll bar at
the rear of your vehicle, to receive better radio reception. For the
best results, use this method for vehicles that have a roll cage.
1
Screw down and tighten the antenna cable
Ride mount .
2
Find a suitable location for the antenna.
3
Using a flat head screwdriver or
loosen the bolt on the external antenna mount until the
ring separates.
4
Place the mount around the roll bar.
5
Tighten the bolt on the mount until the ring is secure.
6
Screw down and tighten the antenna
antenna mount plate.
7
Route the antenna cable along a suitable path in your
vehicle, and secure it using the included zip ties.
March 2021
onto the Group
5
/ in. (8 mm) nut driver,
16
onto the external
Installing the Antenna on the Group Ride
Mount
NOTE: The mounted antenna must be at least 4 cm (1.57 in.)
away from the nearest roll bar or metal surface to avoid radio
interference.
For the best range performance, use the external antenna
mount. You can mount the antenna directly onto the Group Ride
mount when it is not possible to use the external antenna mount.
Screw down and tighten the antenna onto the Group Ride
mount.

Installing the Fist Microphone and Mount

Before you can attach the fist microphone mount to your
dashboard, you must select a suitable location on the
dashboard.
It is your responsibility to ensure the mounting location complies
with all applicable laws and ordinances, and does not block your
view of the road during the safe operation of your vehicle.
Avoid wires, gauges, air bags, air bag covers, HVAC, and other
items when drilling pilot holes and attaching the mount to the
vehicle. Garmin is not responsible for any damages or
®
consequences arising from the installation.
NOTE: This feature is not available on all product models.
1
Align and insert the connector on the fist microphone onto the
Group Ride mount.
2
Tighten the collar around the connected cable.
GUID-94D95904-F3F7-4AAA-85EE-67751184A60C v2
WARNING
NOTICE
