AMG Medical FeverScan 016-662 User Manual

Non-contact infrared thermometer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Model: 016-662
NOTE: The user must check that the equipment functions safely and see that it is in proper
working condition before being used.
Rev1 0420 P/N 911-016662
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FeverScan 016-662 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for AMG Medical FeverScan 016-662

  • Page 1 Model: 016-662 NOTE: The user must check that the equipment functions safely and see that it is in proper working condition before being used. Rev1 0420 P/N 911-016662...

  • Page 2: Table Of Contents

    CONTENTS Features......................3 II. Intended Use....................... 3 III. Safety Precautions....................3 IV. How FeverScan I.R. non-contact Infrared Thermometer Works…....4 V. How To Take A Temperature................4 VI. Basic Instrument....................5 VII. Instructions......................6 VIII. Setting And Function Of Menu.................7 IX. Changing the Battery................... 8 X.

  • Page 3: Features

    I.FEATURES 1. Special design to take the Human Body Temperature with a 3-5cm (1.2-2 in) distance from forehead. 2. Reliable and stable measurement, thanks to the advantage Infrared Detection System. 3. Audible alarm if temperature is more than 38℃ (100.4℉). 4.

  • Page 4: How Feverscan I.r. Non-Contact Infrared Thermometer Works

    Ⅳ.How the Fever Scan I.R. Non-Contact Infrared Thermometer Works All objects, solid, liquid or gas, emit energy by radiation. The intensity of this energy depends on the temperature of the object. The FeverScan I.R. infrared thermometer is therefore able to measure the temperature of a person by the energy the person emits.

  • Page 5: Basic Instrument

    Notice Please observe the following before any temperature measurement to ensure a stable and reliable result: - Push back hair from the forehead. - Wipe away any perspiration from the forehead. - Avoid any drafts (e.g. from nasal specs, air conditioning...) - Allow a 3-5 seconds interval between two measurements.

  • Page 6: Instructions

    Ⅶ. Instructions 1. Install battery. 2. For the first use or when inserting new batteries, wait from 10-15 minutes for the warm-up of the unit. This will allow the unit to become acclimated to the temperature of the room. 3. Press On/Scan button, aim towards the forehead (see the diagram below for the 016-662 positioning), from a distance of 3cm~5cm, When press the “On/Scan”...
  • Page 7 1. SWITCH ON THE DEVICE Press the “On/Scan” button, one second after the screen panel in full display, it will enter the standby mode with the sign “---℃” or “---℉”. Then press the “On/Scan” button again, you will get the measuring result in 1 second. But if there is no more operation, it will turn off in 30 seconds automatically.

  • Page 8: Changing The Battery

    thermometer from its temperature but it is not convenient to use. You can use recalibration function to adjust the FeverScan I.R. to make it the same test result with mercury thermometer after recalibration. Besides,, when you use FeverScan I.R. for the people with different skin color (For example: the yellow race, black people and so on) you can use recalibration too.

  • Page 9: Maintenance Of The Product

    5. Temperature display resolution: 0.1° C (0.1°F) 6. Measuring range: In body mode: 32.0℃ ~ 43.0℃ (89.6℉ ~ 109.4°F) Under body mode, there is three color backlits Green color backlit: ≦37.3℃ (99.1℉),means normal temperature. Orange color backlit: 37.4℃ ~ 37.9℃ (99.3℉ ~ 100.2℉), means low fever. Red color backlit: ≧38℃...

  • Page 10: Classification

    This device complies with the EU Directive 93/42/EEC concerning medical products, the ISO80601-2-56 and the European Standard EN60601-1-2 and is subject to particular precautions with regard to electromagnetic compatibility. XIV. Classification 1.Internally powered equipment; 2.Type Bf applied part; 3.IP22; 4. Sterilization or disinfection: N/A; 5.

  • Page 11: Emc Declaration

    Temperature readings are too close Pause for 3-5 seconds minimum between together, and the thermometer did not readings; a 15 seconds pause is recommended. have time to reboot. Take measurements at the recommended The measuring distance is too far. distance (app. 3-5 cm ; 1.2in-2in ). EMC Declaration XVI.
  • Page 12 CISPR 11 Harmonic emissions Not application IEC 61000-3-2 Voltage fluctuations/ flicker emissions Not application IEC 61000-3-3 Table 2 Guidance and manufacturer’s declaration - electromagnetic Immunity IEC 60601-1-2 Compliance level Immunity Test Test level Electrostatic ±8 kV contact ±8 kV contact discharge (ESD) ±2 kV, ±4 kV, ±8 kV, ±2 kV, ±4 kV, ±8 kV, ±15...
  • Page 13 on power supply input lines IEC 61000-4-11 30 A/m Power frequency 30 A/m magnetic field 50Hz/60Hz 50Hz/60Hz IEC 61000-4-8 Conduced RF Not application Not application IEC61000-4-6 10 V/m 10 V/m Radiated RF 80 MHz – 2,7 GHz 80 MHz – 2,7 GHz IEC61000-4-3 80 % AM at 1 kHz 80 % AM at 1 kHz...
  • Page 14 CDMA850, 18 Hz LTE Band 5 1720 GSM 1800; CDMA 1900; 1845 GSM 1900; Pulse 1700- DECT; modulation 1990 Band 217 Hz 1970 1,3,4,25;UMT Bluetooth, WLAN, Pulse 2400- 2450 802.11 b/g/n, modulation 2570 RFID2450, 217 Hz LTE Band 7 5240 Pulse 5100- WLAN...
