Summary of Contents for Catoma Switchblade Frameset
- Page 1 Switchblade Frameset Setup & Adjustments Operator’s Manual...
- Page 2 Learn more about Switchblade System at www.catoma.com/gear-overview PROTECTED BY ONE OR MORE PATENTS: US 8678258 B1, US 10231534 B1 D815981, D630011, D833749...
-
Page 3: Table Of Contents
Switchblade Frameset Setup & Adjustments CONTENTS FRAMESET FITMENT 1 Sizing Guide COMPONENTS 3 Main Components 5 Attachment Points MAKING ADJUSTMENTS 7 Overview 8 Frameset Removal 9 Shoulder Straps + Frame Pad 11 Pack Belt OTHER INFORMATION 13 Wearing the Frameset 14 Care &... -
Page 4: Sizing Guide
Sizing Guide - three step Process Fitment Step 1: Determine Torso length Torso In order to begin fitment of your Switchblade Frameset, Length you’ll need to measure your body in three areas: 1) neck, 2) torso and 3) waist. Average Torso 17-22”... - Page 5 NOTE: Pack Belt is offered in two sizes, initial issue of the pack will be with a regular belt - for a large belt see supply or contact Catoma directly to purchase your own. SIZE WAIST SIZE Regular 30”...
-
Page 6: Main Components
Main Components of the frameset The Switchblade™ is a modular load carriage system. Each unit includes an identical frameset (shown below) consisting of the following: 1) framesheet, 2) set of shoulder straps, 3) adjustable framepad, 4) adjustable waist belt, and 5) washers and leashes. Thanks to this framset design, the user then has the capability to configure additional pack pieces to their needs. - Page 7 Each frameset comes with 2 metal safety leashes to completely secure the pivot pins to the framesheet. Wearing the frameset without the safety leashes can result in a loose or broken framesheet which can result in personal injury or death. 1.800.826.0446 | www.catoma.com...
-
Page 8: Attachment Points
Attachment Points Components *Shown with the frameset secured to a Raid pack body. The attachment points are the same for the Assualt pack and the Molle Panel Frame. Designing with the mission in mind... - Page 9 Be sure to connect all 6 Attachment Buckles TOP LOAD LIFTERS (SNAP-ON LOOPS) shoulder straps Pack Belt Stabilizer Straps Fully Secured PACK To frameset 1.800.826.0446 | www.catoma.com...
-
Page 10: Making Adjustments
Overview of custom fitment Making Adjustments The following page will show you how to disassemble your frameset so you can make fine-tuned adjustments. Below are a few things you need to know before beginning the adjustment process. If your pack is configured properly and no adjustments are needed you are all set. -
Page 11: Frameset Removal
INSTALLING FRAMESET: Reverse the steps above. Be sure to install the frameset with a Pull Webbing at bottom of Pull Webbing at bottom of weightless pack / panel. Framesheet to release frameset Framesheet to release frameset 1.800.826.0446 | www.catoma.com... -
Page 12: Shoulder Straps + Frame Pad
Shoulder Straps & Frame Pad Fitment Making Adjustments The sizing component of the frameset is the framesheet, and it is designed with several fitment points for a fine-tuned fit for the end user, made possible by removing and relocating the shoulder straps and frame pad (see page 13). - Page 13 NOTE: The Frame Pad is Adjustable and made up of two pieces. The Frame Pad is secured together by hook and loop (velcro) you can adjust this if needed. 1.800.826.0446 | www.catoma.com...
- Page 14 BODY ARMOR COMPATIBILITY: Frame Pad REMOVAL For better fitment with body armor Depending on your body type, you may find it beneficial to remove the frame pad from the frameset in order for the pack to sit more flush against your rear armor plates. It is necessary to remove the frameset from the pack (shown on page 8) in order to disassemble it and remove the frame pad.
- Page 15 Framesheet the Framesheet Separate shoulder straps from Separate shoulder straps from Re-attach Belt and return Re-attach Belt and return frame pad and remove upper pad frame pad and remove upper pad frameset to pack frameset to pack 1.800.826.0446 | www.catoma.com...
-
Page 16: Pack Belt
Pack Belt Fitment Making Adjustments The Switchblade belt is adjustable from waist sizes 30”-40” by simply extending or tightening the adjustment straps at its front. However, if a larger belt is needed, the standard belt can be removed and replaced with our large belt. - Page 17 Use your judgment on how tight to set these straps when fine tuning your fitment. disconnect pivot pin to Remove disconnect pivot pin to Remove and Replace pack belt and Replace pack belt 1.800.826.0446 | www.catoma.com...
-
Page 18: Other Information
Wearing the Frameset Other Information We’ve put together steps to highlight the importance of safely removing the pack. It’s best to follow these guidelines so that they become a habit and can be performed in an emergency. Incorrect removal of the pack can result in severe injury or even death. -
Page 19: Care & Maintenance
The pack’s nylon fabric can get singed or melted. FEEDBACK If you have feedback using our gear and would like to buy it for yourself, visit www.catoma.com and be sure to take advantage of our military / law enforcement discount. - Page 20 NOTES Designing with the mission in mind...
- Page 21 . Stains can be pre-washed with a brush. After washing, hang dry. A water-repellent such as Nikwax or Scotchgaurd can be sprayed on according to the manufacturer’s instructions. Allow the water-repellent treatment to dry before using. Learn more about Switchblade System at www.catoma.com/gear-overview...
- Page 23 PROUDLY DESIGNED AND MADE IN THE U.S.A.
