- Page 1 TESTING Bluhm & Feuerherdt GmbH Production and distribution of construction-material testing devices Motzener Str. 26b DE - 12277 Berlin Tel. +49(0)30/7109645-0 Fax +49(0)30/7109645-98 www.testing.de Operating Manual Vibrating Table...
-
Page 2: Table Of Contents
Scrapping, disposal ..................19 After-sales service .................... 21 10.1 Date of this version of the Operating Manual ..........21 10.2 Copyright ......................21 10.3 Spare parts and technical help ................ 21 Enclosures: European Union Declaration of Conformity Circuit diagram Testing and Measuring Record... -
Page 3: Basic Instructions
Vibrating Table 2.0231 / 2.0268 / 2.0269 2.0131 / 2.0233 / 2.0234 2.0271 Basic instructions Designation Designation of the device: Please see the name plate on the machine, which shows the complete characteristic data and the electric properties of the system. Purpose for which this system was designed This Operating Manual contains the information required for operation of the products described here, for the purpose for which they have been designed. -
Page 4: Conditions Under Which This Vibrating Table May Not Be Used
Vibrating Table 2.0231 / 2.0268 / 2.0269 2.0131 / 2.0233 / 2.0234 2.0271 The manufacturer accepts no liability for any damage caused by incorrect use of the system. Changes reserved: The manufacturer retains the right to change the technical de- scriptions as well as the system to which they relate without advance notice. -
Page 5: Safety Regulations
TESTING products. Therefore, it is absolutely necessary that all measures are carried out by qualified personnel. All personnel who are involved with the project planning, in- stallation and operation must be familiar with the safety concepts and qualified in such matters. -
Page 6: Information About The Ce Symbol
The machine must be positioned at a location that is fire proof and explosion proof. 1.5.3 Information about the CE symbol TESTING Bluhm & Feuerherdt GmbH testing devices carry the CE symbol. The CE marking confirms that the product conforms with the EC Directives that must be taken into consideration for the product and also that the product is in compliance with the “essential requirements”... -
Page 7: Acceptance Of Delivery, Transport
Vibrating Table 2.0231 / 2.0268 / 2.0269 2.0131 / 2.0233 / 2.0234 2.0271 Practice has also shown that even CE marked devices such as monitors or displays can be affected when their manufacturers accept such an influence (e.g. the flickering of dis- plays) as the minimum quality under EMC conditions. -
Page 8: Connection To The Power Supply
Vibrating Table 2.0231 / 2.0268 / 2.0269 2.0131 / 2.0233 / 2.0234 2.0271 Connection to the power supply The machine must be connected to the building power system by Danger a qualified electrician. In accordance with the pertinent standards, the yellow-green con- nection terminal must be attached to the earthing system before additional electrical connections are made. -
Page 9: Device Characteristics
Vibrating Table 2.0231 / 2.0268 / 2.0269 2.0131 / 2.0233 / 2.0234 2.0271 Device characteristics Mechanical features The Vibrating Table is constructed of robust steel plate. The surfaces are powder coated. Switching on/off depends on the model (see table) The power connection is provided by a full-rubber, two-pole and earthing-pin plug. Standard vibrating tables without magnetic clamping device The root-mean-square (RMS) value for acceleration to which the upper parts of the op- erator’s body is subjected is not more than 2.5 m/s². -
Page 10: Electric Smog
Vibrating Table 2.0231 / 2.0268 / 2.0269 2.0131 / 2.0233 / 2.0234 2.0271 The amount of noise that is caused by the machine is dependent upon a number of dif- ferent factors, including for example the product, the site of installation, etc. It is therefore impossible to given a generally valid sound level pressure. -
Page 11: Standard Vibrating Tables Without Magnetic Clamping Device
Vibrating Table 2.0231 / 2.0268 / 2.0269 2.0131 / 2.0233 / 2.0234 2.0271 Standard vibrating tables without magnetic clamping device 2.0131 2.0231 2.0268 2.0269 2.0233 2.0234 2.0271... - Page 12 Vibrating Table 2.0231 / 2.0268 / 2.0269 2.0131 / 2.0233 / 2.0234 2.0271...
-
Page 13: Models With Magnetic Clamping Device
Vibrating Table 2.0231 / 2.0268 / 2.0269 2.0131 / 2.0233 / 2.0234 2.0271 Models with magnetic clamping device 2.0131M 2.0231M 2.0268M 2.0269RSMU 2.0233M 2.0234M 2.0233M2 2.0234M2 2.0271SM2... - Page 14 Vibrating Table 2.0231 / 2.0268 / 2.0269 2.0131 / 2.0233 / 2.0234 2.0271...
-
Page 15: Placing The Vibrating Table Into Operation
Vibrating Table 2.0231 / 2.0268 / 2.0269 2.0131 / 2.0233 / 2.0234 2.0271 Placing the Vibrating Table into operation The device may only be operated in dry rooms! The following limit values apply: Permissible temperature: from 5 °C to +40 °C Operating humidity range: from 20 % to 75 % r.H. -
Page 16: How To Set The Timer Switch St64-31.07
Vibrating Table 2.0231 / 2.0268 / 2.0269 2.0131 / 2.0233 / 2.0234 2.0271 Models with magnetic clamping device Place a filled concrete mould on the vibratory plate of the table. Set the desired vibration time (from a minimum of 1 second to a maximum of 9,999 sec- onds) Start the vibration function by using the START/STOP button. -
Page 17: Setting The Time For The Timer To Run
Vibrating Table 2.0231 / 2.0268 / 2.0269 2.0131 / 2.0233 / 2.0234 2.0271 By pressing the START-STOP button, you can show the value of the respective pa- rameter. If you then at the same time also press the upward button () or the down- ward button () while still holding down the START-STOP button, you can change the value of the parameter being shown. -
Page 18: Explanation Of The Display
Vibrating Table 2.0231 / 2.0268 / 2.0269 2.0131 / 2.0233 / 2.0234 2.0271 Explanation of the display The very large and especially bright characters simplify checking work and mak- ing settings, under all conditions. As a result of the high safety class of the front panel (IP-66), the system can with- stand water and rough treatment. -
Page 19: Troubleshooting
Vibrating Table 2.0231 / 2.0268 / 2.0269 2.0131 / 2.0233 / 2.0234 2.0271 Troubleshooting Caution Work on such electrical equipment may be performed only by suita- bly trained specialist personnel. FAULT CAUSE REMEDY Table doesn’t work Fuses triggered Replace fuses Electr. - Page 20 Vibrating Table 2.0231 / 2.0268 / 2.0269 2.0131 / 2.0233 / 2.0234 2.0271 The product and the packaging material are made from recyclable materials. The separate, environment friendly disposal of material residues promotes the recycling of reusable materials. This product complies with directive 2012/19/EC of the European Parlia- ment and Council of Ministers on waste electrical and electronic devices.
-
Page 21: After-Sales Service
May 2020 10.2 Copyright The copyright to this Operating Manual is held by: TESTING Bluhm & Feuerherdt GmbH This Operating Manual is intended for use only by the User and his/her staff. It contains instructions and data that may NOT be: ... - Page 22 EC Declaration of Conformity in accordance with the Machinery Directive 2006/42/EC Appendix II 1.A The authorised representative established in the community, Mr. Feuerherdt hereby declares that the following product Manufacturer: TESTING Bluhm & Feuerherdt GmbH Motzener Str. 26b 12277 Berlin Product designation: vibrating table Serial number:...
