- Page 1 I L F O R D S P O R T S V I E W P R O J E C T O R I N S T R U C T I O N BOOK...
- Page 2 Now that you're the owner of a new Sportsview Projector, you'll want to begin using it right away. The Sportsview Pro- jector is extremely simple to operate, but, as with any other precision optical instrument, there is a right way and a wrong way of going about it.
- Page 3 Lamp-house Cover Front Feet Autochange Lever Lamp Switch Inspection W i n d o w M i r r o r Adjusting Lever Fine-Focus Control Wheel Top Casting Retaining Screws Lens...
- Page 4 A type A1/182 lamp is supplied with the Sportsview Projector. Make sure it is of the correct voltage for the mains supply in your area. If it is not, DO NOT USE THE LAMP, but consult your Ilford Photographic Dealer.
- Page 5 In the case of "spotted" slides, the magazine should be loaded so that the spots are in the top right-hand corner facing you. For the very best results, Sportsview Transparency Frames are recommended, although the Sportsview Projector will work very well with transparencies bound between cover glasses or card mounts.
- Page 6 The Sportsview Projector has been designed so that, when the autochange lever is pulled out as far as it will go, the magazine may be moved to any position by hand.
- Page 7 Tilt Adjustment You may need to raise the front of the projector in order to get all of the picture on to the screen. This is done by rotating the two front feet (6) until the correct adjustment is obtained. It is not a good idea to tilt the projector too much because this will give a slightly distorted picture.
- Page 8 When you replace the optical components, make sure they are in the correct position and the right way round. Your Sportsview Projector will not work properly if the heat filter and condensers are replaced incorrectly. This photograph shows the optical components in their correct positions when seen from above.
- Page 9 Before you reassemble the projector, make sure the capping blade is operating correctly. If you are going to carry your Sportsview Projector when it is loaded with a magazine containing slides, it must always be held in the normal operating position. If it is carried on its side, or if it is shaken or bumped about, the slides will come out of the magazine and jam the mechanism.
- Page 10 Extra Magazines Extra magazines are available from your Ilford Photographic Dealer. Many of the types available will not fit, so be sure to ask for Ilford Sportsview Magazines. These are supplied in an attractive transparent storage case, with index, containing two magazines.
- Page 12 ILFORD LIMITED ILFORD ESSEX ISPIB/J.6l/E/6m Printed in England...
