Matrix Tippkemper IDENTIX IDR-11 P Series Manual

IDENTIX IDR-11xxP / IDN-11xxP-GD / IDD-11xxP-GD
Photo-Sensors with TEACH-IN function and adjustable sensitivity
IDD-11..P-GD
0158
II 2G Ex d IIC T6 Gb
II 2D Ex tb IIIB T90°C Db IP67
Technical data
Light source
IDD-11xxP-GD: Type of Ex protection Gas, at 94/9/EC
IDD-11xxP-GD: Type of Ex protection Dust, at 94/9/EC
IDD-11xxP-GD: Applicable in Ex zones
IDN-11xxP-GD: Type of Ex protection Gas, at 94/9/EC
IDN-11xxP-GD: Type of Ex protection Dust, at 94/9/EC
IDN-11xxP-GD: Applicable in Ex zones
Working space, at white paper 30cmx20cm
Response time
Time for TEACH-IN
Supply voltage
Current consumption
Max. power dissipation
Output
Input TEACH-IN
Potentiometer for fine adjustment
Housing
Enclosure rating, at EN 60529
Vibration and shock resistance
Working temperature range T
amb
Storage temperature range
Connection cable, length: IDR=3m, IDN/IDD=10m
Socket, only IDR/IDN-11xxP(-GD)-S99
Accessories included, all types
Accessories, only IDN/IDD-11xxP-GD
Accessories, only IDN-11xxP-GD-S99
Accessories, not included,
IDR/IDN-11xxP(-GD)-S99
Options:
IDR/IDN/IDD-1151P(-GD)
ID.-1132P/1152P/1191P(-GD)
ID.-1133P(-OP)
IDR/IDN-11xxP(-GD)-S99
IDR-1150P-S104
IDR-1150P-S123
ID.-1150P(-GD)-S182
Fibre optics connection
Function:
At Teach-In the sensor measure the quantity of
diffuse reflected light and safe this reference value.
During normal running the actual measured value
will be compared with the saved reference value. If
more or less quantity of light received, the output will
be switched OFF. The tolerance of allowable differ-
ence can be adjusted by the potentiometer.
Function of the output at measurement and LED display:
Output function at standard wiring of the supply voltage:
Cable: S104 / S123: Socket S99:
+24VDC 1 brown
0V 2 white
Output 3 blue
Input TEACH-IN 4 black
PE yl-gr Housing
Output function at reversed wiring of the supply volt-
age: Cable: S104 / S123:
+24VDC 2 white
0V 1 brown
Output 3 blue
Input TEACH-IN 4 black
PE yl-gr Housing
Housing M30
• Adjustment by "Teach-In" function
• Well applicable with different fibre optics
• Infrared, red or yellow light sources
• Fine adjustable sensitivity
• Types IDD-.. -GD: Applicable in Ex zones 1, 2, 21, 22
• Types IDN-.. -GD: Applicable in Ex zones 2, 22
Types IDR IDR-1130P
Types IDN IDN-1130P-GD
Types IDD IDD-1130P-GD
870nm, infrared
appr.10 - 400mm
Vibration: 30g over 20Hz to 2kHz. Shock: 100g for 3ms
4+PE x 0,5mm
2x Nuts M30 (or 1x clamp on request)
1x Spare safety screw with packing ring for potentiometer sealing
- Safety lock device, mount at the cable connection, for locking the connection.
- 1x Warning plate "WARNING - Explosion Hazard - Do Not Disconnect While Circuit
is Live Unless Area Is Known To Be Non-Hazardous", self-sealing, for gluing on
the cable connector
- 1x Dust-protection cap for the sensor socket
- Cord set M12, types RKTS 5-298/xx or RKWTH 5-298/xx,Lumberg
- Same specifications as IDx-1150P(-GD), reduced optical power,
output during TEACH-IN not activated.
Range: 1.5cm to 10cm, on white paper.
- Same specifications as base devices, reduced optical power.
- reduced optical power IDx-1131P(-GD), increased optical power, 0.5m-3m on white
paper, special for light barrier applications with wide area fibre optics QW.
- Socket M12: Lumberg RSFM 5, 5 pins.
- Response time: 1.25ms, reduced optical power, special for light barrier applications with
fibre optics. Cable: 10cm, with socket M12,
- Response time: 0.8ms, reduced optical power, special for light barrier applications with
fibre optics. Cable: 10cm, with socket M12,
- Same specifications as IDx-1150P, increased optical power, special for light barrier
function, for glass detection. Response time: 200ms. With special optical tubes at the
fibre optic probes M18 at the emitter and receiver probe. (Special Tubes M18/90/8).
LED TEACH-IN
At activated TEACH-IN:
No valid reference data measured.
LED shows
Output = OFF
RED
IDR/IDN/IDD-1151P: Output not served
At activated TEACH-IN:
Valid reference data measured
and saved.
LED shows
Output = ON
GREEN
IDR/IDN/IDD-1151P: Output not served
LED = GREEN
1 / brown
3 / blue
4 / black
2 / white
5 / grey
Socket S99:
3 / blue
1 / brown
4 / black
2 / white
5 / grey
ISO 9001:2008 / ATEX
IDN-11..P-GD
II 3G Ex nA IIB T4 Gc
II 3D Ex tc IIIA T135°C Dc IP67
IDR-1131P IDR-1150P
IDN-1131P-GD IDN-1150P-GD
IDD-1131P-GD IDD-1150P-GD
870nm, infrared 630nm, red
II 2G Ex d IIC T6 Gb
II 2D Ex tb IIIB T90°C Db IP67
Zones 1, 2, 21, 22
II 3G Ex nA IIB T4 Gc
II 3D Ex tc IIIA T135°C Dc IP67
Zones 2, 22
appr.400 - 1000mm
7.5ms
180ms
24VDC +-10%
60mA
1.7W
PNP, max. 100mA, short circuit protected
PNP compatible
Yes
M30, brass, nickel plated
IDN and IDD: IP 67 / IDR: IP 65
-10°C < T < +50°C
amb
-20°C ... +70°C
2 , TPU, shielded, leads numbering marked, halogen free
M12, Lumberg, RSFM-5
Binder 713/4-pins.
Binder 713/4-pins.
Actual measured value is greater or less
then the reference value, including the
tolerance, determinately by the potentiom-
Actual measured value equal to the
reference value, within the determinately
+24VDC
PNP=ON
R 15Ω
Output
NPN=OFF
0V
+24VDC
PNP=OFF
R 15Ω
Output
NPN=ON
0V
IDR-1190P
IDN-1190P-GD
IDD-1190P-GD
590nm, yellow
appr.10 - 400mm
At measurement
eter. Output = OFF
tolerance.
Output = ON.
LED = RED
+24VDC
PNP=OFF
R 15Ω
Output
NPN=ON
0V
+24VDC
PNP=ON
R 15Ω
Output
NPN=OFF
