USER MANUAL – RAIZER® II – VERSION 2.1 1. Foreword Congratulations on your purchase of the Raizer. This is an original user manual for your new Raizer II. Hereinafter we use the term Raizer for Raizer II, if nothing else is specifically indicated. -
Page 5: Eu Declaration Of Conformity
The above product is manufactured under the following management system: EN ISO 9001: 2015 Quality management, Certificate No. 5749-3027770-01-02-01 Søren Elisiussen Position Name Liftup A/S, Hagensvej 21, DK-9530 Støvring, Denmark Place 17 September 2019 Date Signature Yorkshire Care Equipment | T: 01423 799960 | E: enquiries@yorkshirecare.com | www.yorkshirecareequipment.com... -
Page 6: Labelling Of The Equipment
USER MANUAL – RAIZER® II – VERSION 2.1 3. Labelling of the equipment Insert copy of CE certification mark here Yorkshire Care Equipment | T: 01423 799960 | E: enquiries@yorkshirecare.com | www.yorkshirecareequipment.com... -
Page 7: Terms Of Use
Read the user manual thoroughly before using the lifting chair Do not dispose of batteries, electrical or electronic equipment with unsorted household rubbish. When disposing of this device, ensure compliance with local ordinances and regulations. Yorkshire Care Equipment | T: 01423 799960 | E: enquiries@yorkshirecare.com | www.yorkshirecareequipment.com... -
Page 8: Technical Specifications
USER MANUAL – RAIZER® II – VERSION 2.1 5. Technical specifications 5.1 Dimensional drawings Yorkshire Care Equipment | T: 01423 799960 | E: enquiries@yorkshirecare.com | www.yorkshirecareequipment.com... -
Page 9: Specifications
170 g (0,38 lbs.) Working temperature: +5ºC to +40ºC/ 41ºF to 104ºF Storage temperature: -25ºC to +70ºC / 13ºF to 158ºF Dust and water: IP 4x Expected service life: >5 years Yorkshire Care Equipment | T: 01423 799960 | E: enquiries@yorkshirecare.com | www.yorkshirecareequipment.com... -
Page 10: Specifications Radio Components
+5ºC to +40ºC / 41ºF to 104ºF Storage temperature: -25ºC to +70ºC / 13ºF to 158ºF Expected service life: >5 years We reserve the right to make technical modifications Yorkshire Care Equipment | T: 01423 799960 | E: enquiries@yorkshirecare.com | www.yorkshirecareequipment.com... -
Page 11: Patents And Design Registration
• EP2911637 PCT/DK2015/050041 • • US 09561144 • US 09980866 US-2018-0042791-A1 • • 52936AU01 The product is protected by the following design registrations: • D55542EU01 • DM/087 953 Yorkshire Care Equipment | T: 01423 799960 | E: enquiries@yorkshirecare.com | www.yorkshirecareequipment.com... -
Page 12: Safety Instructions
100 %. This means that in case the person is unable to keep the upper body/torso in an upright position, you should use a breast belt or several safety belts (optional equipment) Yorkshire Care Equipment | T: 01423 799960 | E: enquiries@yorkshirecare.com | www.yorkshirecareequipment.com... -
Page 13: Handling
Cleaning may only be done using a well-wrung cloth. NEVER use a high-pressure jet or running water to rinse the chair and NEVER immerse it in water, as this can damage the product. Yorkshire Care Equipment | T: 01423 799960 | E: enquiries@yorkshirecare.com | www.yorkshirecareequipment.com... -
Page 14: Functionality
Charging may also be done using the USB cable; however, this takes considerably longer than with the charger (approx. 20 hours for a full charge. Yorkshire Care Equipment | T: 01423 799960 | E: enquiries@yorkshirecare.com | www.yorkshirecareequipment.com... -
Page 15: Operating The Raizer
UP/DOWN arrow keys on the side of the chair. Check that the chair is charged prior to use. The battery indicator must not flash red. Battery indicator Yorkshire Care Equipment | T: 01423 799960 | E: enquiries@yorkshirecare.com | www.yorkshirecareequipment.com... - Page 16 BE CAREFUL not to lose the remote con- trol when releasing it from the Raizer. Yorkshire Care Equipment | T: 01423 799960 | E: enquiries@yorkshirecare.com | www.yorkshirecareequipment.com...
-
Page 17: Operation
Fit one side at a time. Correct assembly Incorrect assembly (first mount the backrest) (do NOT mount the legs at first) Yorkshire Care Equipment | T: 01423 799960 | E: enquiries@yorkshirecare.com | www.yorkshirecareequipment.com... -
Page 18: Placing The Raizer
Always attach the backrest at first. If the legs are attached at first, it will disturb the fitting of the backrest. Take care that the backrest is attached into the correct hole Yorkshire Care Equipment | T: 01423 799960 | E: enquiries@yorkshirecare.com | www.yorkshirecareequipment.com... -
Page 19: Mounting The Seat Belt
Raizer, as this may cause the person to be crushed. (The seat belt clip however will break off before any personal damage). Yorkshire Care Equipment | T: 01423 799960 | E: enquiries@yorkshirecare.com | www.yorkshirecareequipment.com... -
Page 20: Mounting The Backrests
If necessary, place your foot in front of the seat to stop it from slipping forward. A confirmation tone will sound, when the backrest has been correctly fitted (). Yorkshire Care Equipment | T: 01423 799960 | E: enquiries@yorkshirecare.com | www.yorkshirecareequipment.com... -
Page 21: Mounting The Legs
(). Right front leg Insert the leg carefully, until it klicks into place. A double confirmation tone will sound when the last leg has been correctly fitted (). Yorkshire Care Equipment | T: 01423 799960 | E: enquiries@yorkshirecare.com | www.yorkshirecareequipment.com... -
Page 22: Alerts Prior To Lifting
DO NOT run the chair up before you have made sure that the person’s feet, arms, hands and other extremities will not be endangered by the movements of the lifting chair.! Yorkshire Care Equipment | T: 01423 799960 | E: enquiries@yorkshirecare.com | www.yorkshirecareequipment.com... -
Page 23: Lifting A Person
5. Press the UP arrow (↑) until the person has reached the requested position. 6. The Raizer will automatically stop when reaching its top position and the person is in an upright sitting position. Yorkshire Care Equipment | T: 01423 799960 | E: enquiries@yorkshirecare.com | www.yorkshirecareequipment.com... - Page 24 The wheels of the legs are only meant to avoid scratches to the floor in connection with the lifting procedure. The Raizer is not designed for transport of persons. Yorkshire Care Equipment | T: 01423 799960 | E: enquiries@yorkshirecare.com | www.yorkshirecareequipment.com...
-
Page 25: Disassembly
When the Raizer has been disassembled, all parts are stowed away in the transport bag. Yorkshire Care Equipment | T: 01423 799960 | E: enquiries@yorkshirecare.com | www.yorkshirecareequipment.com... -
Page 26: Charging The Raizer
10-15 minutes’ charging is sufficient for 1 lift. A full charge gives approx. 40 lifts at room temperature. The number of lifts will be reduced at lower temperatures. Yorkshire Care Equipment | T: 01423 799960 | E: enquiries@yorkshirecare.com | www.yorkshirecareequipment.com... -
Page 27: Maintenance
30°C. You can disinfect the bags by using alcohol-based disinfectants at a concentration of 70–85 v/v%. Wash at max. 30 C° No tumble drying No ironing No bleach Yorkshire Care Equipment | T: 01423 799960 | E: enquiries@yorkshirecare.com | www.yorkshirecareequipment.com... -
Page 28: Pairing The Transmitter And The Receiver (Remote Control)
When the control LED starts to flash quickly, the remote control is no longer associated/paired with the Raizer. Alternatively: If the remote control is open, you may push “reset” to restore the initial state. Yorkshire Care Equipment | T: 01423 799960 | E: enquiries@yorkshirecare.com | www.yorkshirecareequipment.com... -
Page 29: The Remote Control
2. Remove the back panel 3. Swap the battery 4. Refit the back panel and make sure that the remote control is working correctly. Yorkshire Care Equipment | T: 01423 799960 | E: enquiries@yorkshirecare.com | www.yorkshirecareequipment.com... -
Page 30: Service Inspections
All service inspections performed must be logged in the service logbook, cf. the example in section 14. Yorkshire Care Equipment | T: 01423 799960 | E: enquiries@yorkshirecare.com | www.yorkshirecareequipment.com... -
Page 31: Service Logbook
USER MANUAL – RAIZER® II – GB VERSION 2.1 14. Service logbook Yorkshire Care Equipment | T: 01423 799960 | E: enquiries@yorkshirecare.com | www.yorkshirecareequipment.com... -
Page 32: Spare Parts And Accessories
For further details regarding spare parts and service, please contact your distributor. Part no. Description Photo/illustration 107464 Headrest 104871 (4 pcs. for a complete unit) 104862 Backrest (2 pcs. for a complete unit) 107250 Safety belt Yorkshire Care Equipment | T: 01423 799960 | E: enquiries@yorkshirecare.com | www.yorkshirecareequipment.com... - Page 33 USER MANUAL – RAIZER® II – GB VERSION 2.1 Part no. Description Photo/illustration 105026 Remote Control 105192 Battery charger, 15W, Magnetic Male 105082 Charger Cable USB 107463 Carry case (including quick guides) 107240 Cover for seat Yorkshire Care Equipment | T: 01423 799960 | E: enquiries@yorkshirecare.com | www.yorkshirecareequipment.com...
- Page 34 107273 Trolley (Optional equipment) 107374 Clip and belt 104913 Hanger for trolley 103314 Triple wheel for trolley, 2 pcs. (Optional equipment) 103313 Bike bracket kit, trolley (Optional equipment) Yorkshire Care Equipment | T: 01423 799960 | E: enquiries@yorkshirecare.com | www.yorkshirecareequipment.com...
- Page 35 USER MANUAL – RAIZER® II – GB VERSION 2.1 Part no. Description Photo/illustration 103741 Disposable hygiene cover (10 pcs.) (Optional equipment) 102890 Battery 12V 5Ah LiFePo4 Raizer 107230 Stop device for Raizer II Yorkshire Care Equipment | T: 01423 799960 | E: enquiries@yorkshirecare.com | www.yorkshirecareequipment.com...
-
Page 36: Troubleshooting
16. Troubleshooting On our website we offer some helpful videos which will provide you with information on alarms/signals and troubleshooting, assembly and disassembly of the Raizer: https://www.liftup.dk/en/products/accessories/raizer-video-guide/ Yorkshire Care Equipment | T: 01423 799960 | E: enquiries@yorkshirecare.com | www.yorkshirecareequipment.com... -
Page 37: Electrical Diagram
USER MANUAL – RAIZER® II – GB VERSION 2.1 17. Electrical diagram Yorkshire Care Equipment | T: 01423 799960 | E: enquiries@yorkshirecare.com | www.yorkshirecareequipment.com... -
Page 38: Disposal
Cf. Danish Working Environment Authority Executive Order 1109 §14. Enjoy your new Raizer! Kind regards, Yorkshire Care Equipment Yorkshire Care Equipment | T: 01423 799960 | E: enquiries@yorkshirecare.com | www.yorkshirecareequipment.com... - Page 39 USER MANUAL – RAIZER® II – GB VERSION 2.1 Yorkshire Care Equipment | T: 01423 799960 | E: enquiries@yorkshirecare.com | www.yorkshirecareequipment.com...
