Cleveland Range, LLC
1333 East 179th Street
Cleveland, Ohio, 44110 U.S.A
OPERATING and MAINTENANCE INSTRUCTIONS
Models: HCDH-20.20 Companion Holding Cabinet
Models:
HCDH SERIES for use with Convotherm C2020 Roll-In Rack (not included).
Cabinet model number:
Cabinet serial number:
Authorized Service Agency:
Ph:
Keep this manual for future reference.
Fax:
FL-2335-CLV
Rev. 0 (2/07)
Advertisement
Summary of Contents for Cleveland HCDH Series
- Page 1 1333 East 179th Street Cleveland, Ohio, 44110 U.S.A OPERATING and MAINTENANCE INSTRUCTIONS Models: HCDH-20.20 Companion Holding Cabinet Models: HCDH SERIES for use with Convotherm C2020 Roll-In Rack (not included). Cabinet model number: Cabinet serial number: Authorized Service Agency: Fax: Keep this manual for future reference.
-
Page 2: Table Of Contents
Rev. 0 (2/07) Rev. 0 (2/07) Cleveland Range, LLC Cleveland Range, LLC 1333 East 179th Street 1333 East 179th Street Cleveland, Ohio, 44110 U.S.A Cleveland, Ohio, 44110 U.S.A TABLE OF CONTENTS SUBJECT PAGE INSTALLATION INSTRUCTIONS ....................2 Illustration (Leg Adjustment), Figure 1 ................2 OPERATING INSTRUCTIONS ....................3... - Page 3 Cleveland Range, LLC Rev. 0 (2/07) Page 1 of 14 1333 East 179th Street Cleveland, Ohio, 44110 U.S.A OPERATING and MAINTENANCE INSTRUCTIONS Models: HCDH-20.20 Companion Holding Cabinet IDENTIFYING YOUR CABINET: Look for this label on the back of your cabinet. This information is needed when calling for questions or service.
- Page 4 Holding Cabinet Cleveland Range, LLC Rev. 0 (2/07) Page 2 of 14 1333 East 179th Street Cleveland, Ohio, 44110 U.S.A OPERATING and MAINTENANCE INSTRUCTIONS Models: HCDH-20.20 Companion Holding Cabinet HOW TO INSTALL UNIT: NOTE: DO NOT PUT FOOD IN CABINET!
- Page 5 Holding Cabinet Cleveland Range, LLC Rev. 0 (2/07) Page 3 of 14 1333 East 179th Street Cleveland, Ohio, 44110 U.S.A OPERATING and MAINTENANCE INSTRUCTIONS Models: HCDH-20.20 Companion Holding Cabinet Figure 2 HOW TO HOLD: Push POWER switch to “ON.” Yellow POWER LIGHT will come on.
-
Page 6: How To Clean The Unit
Holding Cabinet Cleveland Range, LLC Rev. 0 (2/07) Page 4 of 14 1333 East 179th Street Cleveland, Ohio, 44110 U.S.A OPERATING and MAINTENANCE INSTRUCTIONS Models: HCDH-20.20 Companion Holding Cabinet Cleaning hints: Wipe up spills as soon as possible. Clean cabinet regularly to avoid heavy dirt build-up. - Page 7 Companion FL-2335-CLV Holding Cabinet Cleveland Range, LLC Rev. 0 (2/07) Page 5 of 14 1333 East 179th Street Cleveland, Ohio, 44110 U.S.A OPERATING and MAINTENANCE INSTRUCTIONS Models: HCDH-20.20 Companion Holding Cabinet TROUBLE-SHOOTING CHART: FAILURE POSSIBLE CAUSE 1a. Switch is “OFF”.
- Page 8 Companion FL-2335-CLV Holding Cabinet Cleveland Range, LLC Rev. 0 (2/07) Page 6 of 14 1333 East 179th Street Cleveland, Ohio, 44110 U.S.A OPERATING and MAINTENANCE INSTRUCTIONS Models: HCDH-20.20 Companion Holding Cabinet CABINET REPLACEMENT PARTS: ITEM DESCRIPTION 120V 208V 240V Heater Kit, Air, 1000 Watts each...
- Page 9 Companion FL-2335-CLV Holding Cabinet Cleveland Range, LLC Rev. 0 (2/07) Page 7 of 14 1333 East 179th Street Cleveland, Ohio, 44110 U.S.A OPERATING and MAINTENANCE INSTRUCTIONS Models: HCDH-20.20 Companion Holding Cabinet CABINET REPLACEMENT PARTS:...
-
Page 10: Replacement Parts (Cabinet)
FL-2335-CLV Holding Cabinet Cleveland Range, LLC Rev. 0 (2/07) Page 8 of 14 1333 East 179th Street Cleveland, Ohio, 44110 U.S.A OPERATING and MAINTENANCE INSTRUCTIONS Models: HCDH-20.20 Companion Holding Cabinet REPLACEMENT PARTS FOR THE POWER UNIT: REPLACEMENT PARTS: ITEM DESCRIPTION... -
Page 11: Wiring Diagram
Companion FL-2335-CLV Holding Cabinet Cleveland Range, LLC Rev. 0 (2/07) Page 9 of 14 1333 East 179th Street Cleveland, Ohio, 44110 U.S.A OPERATING and MAINTENANCE INSTRUCTIONS Models: HCDH-20.20 Companion Holding Cabinet WIRING DIAGRAM... -
Page 12: How To Reverse The Door Opening
Cleveland Range, LLC Rev. 0 (2/07) Page 10 of 14 1333 East 179th Street Cleveland, Ohio, 44110 U.S.A OPERATING and MAINTENANCE INSTRUCTIONS Models: HCDH-20.20 Companion Holding Cabinet HOW TO REVERSE THE DOOR OPENING: The doors on the HCDH2020 & HCWH2020 are shipped with the hinges on the left side of the cabinet as standard. -
Page 13: Warranty
fi rst. CLEVELAND RANGE agrees to repair or replace, at its option, f.o.b. factory, any part which proves to be defective due to defects in material or workmanship during the warranty period, providing the equipment has been unaltered, and has been PROPERLY INSTALLED, MAINTAINED, AND OPERATED IN ACCORDANCE WITH THE CLEVELAND RANGE OWNER’S MANUAL. -
Page 14: Authorized Service Agencies
Rev. 0 (2/07) Page 12 of 14 1333 East 179th Street Cleveland, Ohio, 44110 U.S.A AUTHORIZED SERVICE AGENCIES The following is a listing of regional distributors of parts and service throughout the United States. Contact your nearest distributor for the name of an Authorized Service Agency in your area. - Page 15 Companion FL-2335-CLV Holding Cabinet Cleveland Range, LLC Rev. 0 (2/07) Page 13 of 14 1333 East 179th Street Cleveland, Ohio, 44110 U.S.A 11 Hawaii 21 Massachusetts 30 New Jersey Food Equipment Parts & Svc. GCS Service, Inc. American Kitchen Machines...
- Page 16 Fax: (703) 866-4071 Chattanooga, TN 37415 Electrical Appliance Repair (423) 870-4552, (800) 727-8447 GCS Service, Inc. 5805 Valley Belt Road, Cleveland, OH 44131 Fax: (423) 624-3381 2421 Grenoble Road, Richmond, VA 23294 (216) 459-8700, (800) 621-8259 (OH) (804) 672-1700, (800) 899-5949 Fax: (216) 459-8707 GCS Service Inc.
