- Page 1 UNCLASSIFIED Installation Manual PERSISTENT PERIMETER DETECTION RADAR ELM-2114 This document contains proprietary information of ELTA System Ltd. ELM-2114 Operation Manual Subject to be Changed without Notice...
-
Page 2: Table Of Contents
............................ 2 3 9.2. RADHAZ AFETY POWER REQUIREMENTS ......................... 2 4 RECOMMENDED 20[M] CABLE [CAN BE PURCHASE SEPARATELY] ............ 2 5 This document contains proprietary information of ELTA System Ltd. ELM-2114 Installation Manual Subject to Change without Notice... -
Page 3: General
ROI, in tough weather conditions. The main feature of the ELM-2114 is extremely low false alarm rate, crucial for perimeter monitoring. It is equipped with a stationary (non-rotating) planar array covering (Staring at) an azimuth sector of 90°, with detection range capabilities of (up to) 500 m meters for a moving... -
Page 4: Kit Contents
UNCLASSIFIED KIT CONTENTS The ELM-2114 Radar kit contains three (3) components: 2.1. Transceiver: The transceiver module contains an RF front section and a digital circuit. The Transceiver includes a single POE plug. The Transceiver unit is installed on a pole, mast or a tripod, using dedicated mechanical adapter that can be purchase separately. -
Page 5: Installation Removable Media
2.3. Installation Removable Media The enclosed installation Removable Media contains the radar operating application. The ELM-2114 application supported by the following Operating Systems: Win 7 / Win 10 pro. This document contains proprietary information of ELTA System Ltd. ELM-2114 Installation Manual... -
Page 6: System Maps Installation / Setup
Radar placed at the corner of square and the surveillance area is within the square. Place the map file placed in the Maps directory on your operation station. 3.2. Automatic Installation This document contains proprietary information of ELTA System Ltd. ELM-2114 Installation Manual Subject to Change without Notice... -
Page 7: Elm-2114 Operating System Installation
UNCLASSIFIED ELM-2114 OPERATING SYSTEM INSTALLATION The following description specifies the ELM-2114 Operation System installation. Insert the Operating System installation media and follow the on screen installation guide accordingly. The installation includes two stages: 1. ELM2114 – Operating System Installation (HMI) 2. - Page 8 UNCLASSIFIED 4.1.3. License Agreement 4.1.4. Operating System Installation Directory This document contains proprietary information of ELTA System Ltd. ELM-2114 Installation Manual Subject to Change without Notice...
- Page 9 UNCLASSIFIED 4.1.5. Installation Readiness Screen 4.1.6. Installation Process Status This document contains proprietary information of ELTA System Ltd. ELM-2114 Installation Manual Subject to Change without Notice...
- Page 10 UNCLASSIFIED 4.1.7. Installation Completion Screen 4.1.8. Uninstall This document contains proprietary information of ELTA System Ltd. ELM-2114 Installation Manual Subject to Change without Notice...
-
Page 11: Radar Com Set Application
PC. 4.2.1. Radar to PC connection setup screen This document contains proprietary information of ELTA System Ltd. ELM-2114 Installation Manual Subject to Change without Notice... - Page 12 UNCLASSIFIED 4.2.2. System Subnet Detection 4.2.3. Temporary Connection Establishment This document contains proprietary information of ELTA System Ltd. ELM-2114 Installation Manual Subject to Change without Notice...
- Page 13 4.2.4. Final Connection Screen Note: In case the application automatically started following paragraph 5.2.4, it means that the Radar installed and configured correctly. This document contains proprietary information of ELTA System Ltd. ELM-2114 Installation Manual Subject to Change without Notice...
- Page 14 Double click on the ICON shortcut will activate the radar operation system followed by the main system main display screen. Figure 3: Main Display This document contains proprietary information of ELTA System Ltd. ELM-2114 Installation Manual Subject to Change without Notice...
-
Page 15: Radar Configuration Setup
UTM Zone – The zone number of the area according to the UTM's zones map Ground Elevation - Radar height above sea level [M] Radar elevation above ground level [M] 5.1.3. Operational This document contains proprietary information of ELTA System Ltd. ELM-2114 Installation Manual Subject to Change without Notice... - Page 16 Verify that the target known geo-position location is aligned with target's location presented on the display. If there is a mismatching, check the radar's location and azimuth settings and perform the realignment This document contains proprietary information of ELTA System Ltd. ELM-2114 Installation Manual...
-
Page 17: Mechanical Description
There are 4 threading holes (for 1/4 NC Allen bolts) at the radar bottom to attach the Radar to any mechanical adapter. Figure 5: Mechanical Dimensions [mm] This document contains proprietary information of ELTA System Ltd. ELM-2114 Installation Manual Subject to Change without Notice... -
Page 18: Side View And Installation Direction
UNCLASSIFIED 6.2. Side view and installation direction Tx direction Figure 6 : Radar Side View Dimensions This document contains proprietary information of ELTA System Ltd. ELM-2114 Installation Manual Subject to Change without Notice... -
Page 19: 7. Mechanical Installation Guide Lines
α is the deviation from 90 between the Radars. is 39° < α < 45° in order to cover 180° in azimuth, and still get overlapping between the two units at the center of the covered area. This document contains proprietary information of ELTA System Ltd. ELM-2114 Installation Manual... - Page 20 UNCLASSIFIED Figure 7: Two Radars 180 Azimuth Installation This document contains proprietary information of ELTA System Ltd. ELM-2114 Installation Manual Subject to Change without Notice...
-
Page 21: Components Interconnection
UNCLASSIFIED COMPONENTS INTERCONNECTION The following illustration depicts the ELM-2114 System basic interconnection. Figure 8: Components interconnection The ELM 2114 connection to the operation console can be established, using a direct network connection or through a network switch. This document contains proprietary information of ELTA System Ltd. -
Page 22: Safety Instructions
- Consult the dealer or an experienced radio/TV technician for help. Changes or modifications to this equipment not expressly approved by the party responsible for compliance (ELTA Ltd.) could void the user’s authority to operate the equipment. This document contains proprietary information of ELTA System Ltd. -
Page 23: Electrical Safety
LPS. 9.3. RADHAZ Safety The following graph shows that according to IAI ELTA standards, there is no required safe distance from the Radar in operation mode. The Graph can be used for comparison with any other standard. Figure 9: Radiation Power Vs. Radial Distance This document contains proprietary information of ELTA System Ltd. -
Page 24: 10. Power Requirements
0.1 W steps negotiated continuously Derating of maximum cable ambient 5°C with one mode (two pairs) active operating temperature Supported cabling Category 5 Supported modes Mode B This document contains proprietary information of ELTA System Ltd. ELM-2114 Installation Manual Subject to Change without Notice... - Page 25 UNCLASSIFIED 11. RECOMMENDED 20[M] CABLE [CAN BE PURCHASE SEPARATELY] Figure 10: Network Cable This document contains proprietary information of ELTA System Ltd. ELM-2114 Installation Manual Subject to Change without Notice...
