Bertucci Performance Field Watch Owner's Manual

1
Congratulations! ... Nice Choice!
You are now the owner of a Bertucci
every Bertucci Watch has been carefully designed, made from only the best materials, and loaded with
®
premium features. Additionally, Bertucci
This is the basis for our Promise of Performance™ to you. Please carefully read this manual to familiarize
yourself with your new Bertucci Watch. Please contact us with any questions you may have. Contact
®
information is in section 15.
Thank You!
Our Story – Your Watch:
Our story is simple... It's about building a better watch. It's a Promise of Performance™ to you that is
derived from a belief that innovative design and attention to detail matter. It is this focus, passion, and
integrity that drive us in the watches we make for you.
If you were to own only one watch... it would be a watch well suited for your life's endeavors. It would
need to possess the qualities of durability, singularity of purpose, and versatility. Designed to balance form
and function, to be equally rugged and refined, with a classic, understated, enduring style... distinctly a
Bertucci Field Watch™. Ready to survive the day to day challenges that come your way... wherever they
®
may be.
*Manufactured using one of more of the following U.S. Pat. No: 488388, 488075, 488724, 582296, 609586, 645766, 7832605, 8,960,510,B2 and other patents pending.
3 TITANIUM & STAINLESS STEEL CASES
Screw Down Crown Setting Instructions:
(Note: A red crown clip may be on setting crown - please carefully remove.)
1 Turn crown counter clock-wise to unscrew (see fig.1 to the right). The crown is completely unscrewed
when it turns freely.
(Note: If crown is already in the out position or unscrewed, with second hand stopped, go to step 2.)
2 Gently and carefully pull crown out to stop second hand. Do not pull too hard (fig. 2).
3 Rotate the crown clock-wise advancing the hour and minute hands to set the desired time (fig. 3).
4 Push crown in to re-start second hand (fig. 4).
5 Push in again and turn crown clock-wise to engage threads. Continue to turn clockwise to firmly screw/
re-thread down crown. (A screwed down crown will prevent water damage to the movement.)
Do not overtighten (fig. 5).
4 TITANIUM & STAINLESS STEEL CASES
Screw Down Crown Setting Instructions: w/ DATE
(Note: A red crown clip may be on setting crown - please carefully remove.)
1 Turn crown counter clock-wise to unscrew (see fig. 1 to the right). The crown is completely unscrewed
when it turns freely.
(Note: If crown is already in the out position or unscrewed, with second hand stopped, go to step 2.)
2 Gently and carefully pull crown to 1st position. You will feel a "click" (fig. 2). Do not pull too hard.
3 Turn crown clock-wise or counter clock-wise (depending on the model) to advance the date... continue to
advance the date to yesterday's date (fig. 3).
4 Carefully pull the crown out further to 2nd position for a second "click." Rotate the crown clock-wise to
advance the time past midnight and you will see the date advance to today's date. Continue to advance
to set the desired time. This will ensure the AM/PM is correct (fig. 4). Note: Date will need to be reset
for months not ending with 31 days.
5 Push crown in to re-start second hand (fig. 5).
6 Push in again and turn crown clock-wise to engage threads. Continue to turn clockwise to firmly screw/
re-thread down crown. ( A screwed down crown will prevent water damage to the movement.)
Do not overtighten (fig. 6).
5 FIBER REINFORCED POLY-RESIN / POLYCARBONATE CASES
Push In Crown Setting Instructions:
(Note: A red crown clip may be on setting crown - please carefully remove.)
1 Gently and carefully pull crown out to stop second hand.
(Note: If crown is already in the out position, with second hand stopped, go to step 2.)
2 Gently and carefully pull crown out to stop second hand. Do not pull too hard.
3 Turn crown clock-wise or counter clock-wise, moving hour and minute hands, to set to the desired time.
4 Push crown in to re-start second hand.
6 FIBER REINFORCED POLY-RESIN / POLYCARBONATE CASES
Push In Crown Setting Instructions: w/ DATE
(Note: A red crown clip may be on setting crown - please carefully remove.)
1 Gently and carefully pull crown out to stop second hand.
(Note: If crown is already in the out position, with second hand stopped, go to step 2.)
2 Gently and carefully pull crown halfway out. You will feel a "click". Do not pull too hard.
(See section 4 step 2).
3 Turn crown clock-wise or counter clock-wise (depending on the model) to advance the date, continue to
advance the date to yesterday's date. (See section 4, step 3).
4 Carefully pull the crown out a bit further for a second "click". Turn the crown clock-wise to cycle the time
past midnight, you will see the date advance to today's date. Continue to advance to set the desired
time, this will ensure the AM/PM is correct (See section 4 step 4).
5 Push crown in to re-start second hand.
® Performance Field Watch.™ You have something special because
Watches are backed up with an industry leading 3 year warranty.
®
A-1S, A-2S, M-1S, A-1T, A-2T, A-3T,
A-4T, M-1T, B-1T, C-1T, D-1T
M-1S, A-2T, A-4T
2
Durability by Design
Rugged U.S. Patented
Unibody™ case for
extreme durability
and comfort
Hardened, scratch
resistant crystals
1 2
5
IMPORTANT!
It is critical that
the crown is
screwed down.
1
4
2
6
IMPORTANT!
It is critical that
the crown is
screwed down.
A-2R,
A-3P
Note: Case back is engraved with the case type
A-5P
®
Premium precision &
reliable all-metal quartz
movements
Equipped with U.S.
Patented long lasting
high performance band
3 4
Correct Incorrect
Properly screwed down Not screwed down
crown (setting knob). crown.
2 3
1
5
Correct Incorrect
Properly screwed down Not screwed down
crown (setting knob). crown.
(over)
