Safety Precautions

The lightning flash with an arrowhead symbol within an equilateral triangle is
intended to alert the user to the presence of uninsulated "dangerous voltage"
within the product's enclosure that may be of sufficient magnitude to constitute a
risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to
!
the presence of important operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
WARNING:
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE, DUE TO THE HIGH RISK OF FIRE OR
ELECTRIC SHOCK, DO NOT OPEN THE CABINET DANGEROUS HIGH VOLTAGES ARE PRESENT
INSIDE THE ENCLOSURE. ONLYQUALIFIED SERVICE PERSONNELSHOULD ATTEMPT THIS.
C A U T I O N :
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, AND
F U L LY I N S E R T.
C A U T I O N :
This Digital Video Disc Player employs a Laser System. To prevent direct exposure to the laser beam, do not try to open the enclosure.Visible laser radiation
when open and interlocks defeated. Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous
radiation exposure.DO NOT S TA R EI N TO B E A M .
To ensure proper use of this product, please read this owner's manual carefully and retain for future reference. Should the unit require
maintenance, contact an authorized service location, or contact us.only qualified service personnel should remove the cover.
FCC NOTICE:
This equipment has been tested and found to comply with the limits for a Class B digital device. Pursuant with the FCC Rules, Part 15. These limits are
designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates,uses and can radiate radio frequency energy and,if not installed and used in accordance with the instructions,may cause
harmful interference to radio communication,However,this is no guarantee that interference will not occurin a particular installation.If this equipment
does cause harmful interference to radio or television reception,which can be determinedby turning the equipment off and on,the user is encouraged
to try to correct the interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution:To assure continued compliance,(example - use only shielded interface cables when connecting to computer or peripheral
devices).Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to
operate this equipment.
WA R N I N G:
Changes or modifications made to this equipment, not expressly approved by us or parties authorized by us will void all the
manufacture warranties.
THE REGION CODE FOR THE UNIT IS 1.
1
CLASS 1
LASER PRODUCT
CAUTION
RISK OF ELECTRIC SHOCK
DO NOTOPEN
RISQUE DE CHOC ELECTRIQUE NE
AVIS
PAS OUVRIR
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOTREMOVE COVER (OR BACK). NO
USER-SERVICEABLE PART INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
!
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AD-1130W and is the answer not in the manual?

Questions and answers

Summary of Contents for Apex Digital AD-1130W

  • Page 1: Safety Precautions

    Safety Precautions The lightning flash with an arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
  • Page 2: Safety Information

    Safety Information CAUTION: Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. Please carefully study this manual and always keep it available. There are, however, some installation and operation precautions which you should be aware of.
  • Page 3: Safety Information

    Safety Information 14.Protective Attachment Plug - The product is equipped with an attachment plug having overload protection. This is a safety feature. See Instruction Manual for replacement or resetting of protective device. If replacement of the plug is required, be sure the service technician has used a replacement plug specified by the manufacturer that has the same overload protection as the original plug.
  • Page 4: Table Of Contents

    Contents Thank you for purchasing this product. With your DVD player you can enjoy full-length movies with true cinema picture quality and multichannel sound. Unique features of this player include S-video output, selecting of sound and subtitle languages and of different camera angles (depending on the disc), Program playback, Parental Control which lets you decide which discs your children can watch, the player can playback the following discs marked: DVD video disc Audio CD...
  • Page 5: Remote Control

    Remote Control THE INSTRUCTIONS IN THIS MANUAL DESCRIBE THE FUNCTIONS ON THE REMOTE CONTROL. POWER NUMBER KEYS SHUFFLE PROGRAM KODAK T. E . RESUME S L O W S T E P S E T U P 1 0 . AUDIO 11 .
  • Page 6: Connections

    Connections Enjoying Dolby Pro Logic Surround Sound (GOOD) Dolby Pro Logic Surround Enjoy the dynamic realistic sound of Dolby Pro Logic Surround by connecting an amplifier and speaker system (right and left front speakers, a center speaker, and one or two rear speakers). Connect the DVD video player with the S-video cable, if the TV has an S video input.
  • Page 7: Disc Playback

    Disc Playback 1. Press the POWER button displayed on the front panel. 2. Press the OPEN/CLOSE button. This will open the disc tray, and place a playable disc on it. 3. Press ENTER/PLAY. After closing the disc tray playback will start. As the DVD video player is reading the disc, a menu will appear on screen or you may access the menu by pressing the TITLE button.
  • Page 8: Playback Features

    Playback Features 1. Fast forward playback Press during normal playback. Each press wil increase the speed by the following factor: 2X, 4X, 8X or 16X (with no audio). Press ENTER/ to resume normal playback. 2. Fast reverse playback Press during normal playback. Each press wil increase the speed by the following factor: 2X, 4X, 8X or 16X (with no audio).
  • Page 9: Repeat Playback

    Repeat Playback This unit allows you to playback a specific title, chapter, track or segment repeatedly. (title repeat, chapter/track repeat, A-B repeat). HOW TO REPEAT A TITLE, CHAPTER, OR TRACK 1. Select the title, chapter, or track you want to repeat 2.
  • Page 10: Menu

    Program and Shuffle Playback HOW TO SET TITLES, CHAPTERS, OR TRACKS IN A FAVORITE ORDER (PROGRAM PLAYBACK) 1. Insert a disc, then press the PROGRAM button. At this time, the menu will appear. 2. Using the numbered buttons, fill in the title (TT) and chapter (CH) numbers.
  • Page 11: Direction Keys

    Title Selection THE DVD VIDEO DISCS ARE NORMALLY DIVIDED INTO TITLES. THE TITLES ARE SUB-DIVIDED INTO CHAPTERS. MOREOVER, AUDIO CD AND MP3 CD ARE DIVIDED INTO TRACKS. YOU CAN C O N V E N I E N T LY L O C ATE A N Y SPECIFIC TITLE, CHAPTER, OR TRACK WITH THIS DVD VIDEO PLAYER.
  • Page 12: Parental Control

    Parental Control YOU CAN USE THE PARENTAL LOCK FUNCTION ONLY WITH DVD VIDEO DISCS EQUIPPED WITH THE PARENTAL LOCK FEATURE. SETTING THE PARENTAL LOCK DVD video discs equipped with the parental lock function are rated according to their content. The contents allowed by a parental lock level and the way a DVD video disc can be controlled may vary from disc to disc.
  • Page 13: Kodak Picture Cd/Mp3 Playback

    KODAK Picture CD/MP3 Playback YOU CAN USE YOUR DVD PLAYER TO VIEW PHOTOGRAPHS STORED ON A CD-R. T H E PHOTOGRAPHS ON THE DISC NEED TO BE SAVED IN THE JPEG FILE FORMAT. FOR MORE INFORMATION ABOUT JPEGS PLEASE VISIT WWW.JPEG.COM. 1.
  • Page 14: Language/Subtitle Selection

    Language/Subtitle Selection HOW TO SELECT A PLAYBACK AUDIO SETTING This DVD video player allows you to select a preferred language and sound recording system from those included on the DVD video disc. 1. Press the AUDIO button during playback Audio - 1/3 : AC - 3 English Recording systems This DVD video player uses the Dolby Digital, MPEG 2, PCM and DTS recording playback systems.
  • Page 15: On-Screen Display

    On-Screen Display THIS DVD VIDEO PLAYER ALLOWS YOU TO VIEW THE OPERAT I O N A L S TATUS AND DISC INFORMATION ON TO YOUR TV SCREEN. CHECKING THE OPERATIONAL STATUS With this function, you can view on your TV, the following: -Current title -Track number -Total playing time...
  • Page 16: Specifications

    Specifications DVD VIDEO PLAYER/OUTPUTS/SUPPLIED ACCESSORIES DVD VIDEO PLAYER Power supply Power consumption Weight External dimensions Signal system Laser OUTPUTS Video output S video output Audio output (digital audio) Audio output (analog audio) SUPPLIED ACCESSORIES Audio cable (red and white) Remote control Batteries (AA) Video cable (yellow) User’s manual...
  • Page 17: Troubleshooting

    Troubleshooting SYMPTOMS AND CORRECTION Symptom • The power plug is disconnected No power • The TV is not set to receive DVD output No picture • The video cable is not connected securely • The equipment connected with the audio No sound cable is not set to receive DVD signal output.
