Summary of Contents for Aqua Unikart Classic Motorized
- Page 1 UNIKART trolley for a maximum of 136 kg. Instructions for maintenance and use of the Unikart Classic Motorized Date of commissioning: __________________ Device No.: __________________ ART-NTU-XUNIMPN000 – Instructions for use and use Unikart Classic Motorized...
- Page 2 Do not dispose of it in the wild, but give it to a specialized collection center for electrical and electronic waste and / or ask your dealer for the purchase of a new product. ART-NTU-XUNIMPN000 – Instructions for use and use Unikart Classic Motorized...
- Page 3 (No in case of battery discharge problem). • Keep your hands outside the cylinder system and pantographs. • Keep all electrical, electronic or power source (battery) equipment out of water range. ART-NTU-XUNIMPN000 – Instructions for use and use Unikart Classic Motorized...
-
Page 4: Table Of Contents
B – Refill ............................16 C - Remove the battery ....................... 17 8 – DOCUMENTATION EMERGENCY PROCEDURE: ................23 9 – Maintenance plan ..........................24 10 - PRACTICAL INFORMATIONS ......................26 ART-NTU-XUNIMPN000 – Instructions for use and use Unikart Classic Motorized... -
Page 5: Maintenance And Wearing Parts
• Never use the device in case of deterioration on the axes holding the cylinder or the cylinder itself. ART-NTU-XUNIMPN000 – Instructions for use and use Unikart Classic Motorized... -
Page 6: Use - Procedure
Do not use the seat, seat belt, or stabilizing vest if they are damaged or worn. Do not use the appliance if it is damaged (parts broken, bent, other ...). ART-NTU-XUNIMPN000 – Instructions for use and use Unikart Classic Motorized... -
Page 7: Countersweights
Once the person is deep enough into the water, detach the seat belt by pulling on the end of the belt. Keep your fingers and hands away from the 2 masts of the lift during use. ART-NTU-XUNIMPN000 – Instructions for use and use Unikart Classic Motorized... -
Page 8: Daily Use Of Water Outlet
Raise or lower the seat to get the proper height for transfer. • Detach the belt. • Move the user from the seat to the chair or let him down. • Swivel down the stabilizing arms. ART-NTU-XUNIMPN000 – Instructions for use and use Unikart Classic Motorized... -
Page 9: Your Guarantee
Our responsibility can not be engaged on this subject. E - Conformity Machine Directive 2066/42/CE. Additional note to the CE marking. The product has been tested under normal conditions of use. ART-NTU-XUNIMPN000 – Instructions for use and use Unikart Classic Motorized... -
Page 10: Exploded And Nomenclatures
UNIKART trolley for a maximum of 136 kg. 4 – Exploded and nomenclatures A – General view ART-NTU-XUNIMPN000 – Instructions for use and use Unikart Classic Motorized... -
Page 11: B - Details
UNIKART trolley for a maximum of 136 kg. B – Details ART-NTU-XUNIMPN000 – Instructions for use and use Unikart Classic Motorized... -
Page 12: C - Bom
UNIKART trolley for a maximum of 136 kg. C – BOM ART-NTU-XUNIMPN000 – Instructions for use and use Unikart Classic Motorized... -
Page 13: Montage De Démarrage De L'unikart Motorisé
Pictures of montage : Button knurled Outside spacer (Long) Inside spacer (Courte) Final positioning The cylinder is positioned on the second hole (not the first). Motorized Unikart ready to operate. ART-NTU-XUNIMPN000 – Instructions for use and use Unikart Classic Motorized... -
Page 14: Procedure For Using Motorized Unikart
4) Release the brakes, then move the unit forward to put both front wheels on the mat (in the spaces provided). Stall the device at the bottom of the carpet. 5) Press the two brakes of the rear wheels, these two brakes must be obligatorily interlocked. ART-NTU-XUNIMPN000 – Instructions for use and use Unikart Classic Motorized... - Page 15 Council: Plan to charge the device before each use (At least 10h). The battery that is not used is discharging by itself little by little. Down button Emergency stop button Climb button or system shutdown ART-NTU-XUNIMPN000 – Instructions for use and use Unikart Classic Motorized...
-
Page 16: B - Refill
The cylinder is made of marine grade stainless steel and waterproof, however in a constant environment of high humidity and over time, it could be damaged if it is not maintained (washed, rinsed and dried, see instructions) of Stainless Steel). ART-NTU-XUNIMPN000 – Instructions for use and use Unikart Classic Motorized... -
Page 17: C - Remove The Battery
To remove the battery press the metal tab on the top and pull vertically. It will naturally defeat by pivoting on the back. WARNING ! This part of the battery is heavy, keep it well and do not drop it! ART-NTU-XUNIMPN000 – Instructions for use and use Unikart Classic Motorized... - Page 18 3) Unwind the winch strap (turn counterclockwise when facing the crank) the strap must be unwound at least 3m to be braided. WARNING ! Do not use the strap otherwise than with this braiding! ART-NTU-XUNIMPN000 – Instructions for use and use Unikart Classic Motorized...
- Page 19 (lowest / B) pass the strap next to the cylinder on the crank side of the safety winch. Go on the axis holding the seat and cross all the axes until the last downhill. ART-NTU-XUNIMPN000 – Instructions for use and use Unikart Classic Motorized...
- Page 20 Place the strap in front of the highest hole and pass the axle through the loop of the strap. Screw the knurled knob on the axle. ART-NTU-XUNIMPN000 – Instructions for use and use Unikart Classic Motorized...
- Page 21 6) Unscrew the knurled knob from the cylinder pin. 7) Make sure the strap is tight on all winding levels on the machine. If it is not tight, tighten the strap by winding (clockwise on the crank). ART-NTU-XUNIMPN000 – Instructions for use and use Unikart Classic Motorized...
- Page 22 In no event will the responsibility of Hexagone Manufacture be questionable and this emergency procedure is under your responsibility. Council : Perform the empty procedure once a quarter during periodic system checks ART-NTU-XUNIMPN000 – Instructions for use and use Unikart Classic Motorized...
-
Page 23: Documentation Emergency Procedure
Tip: Perform the empty procedure once a quarter during periodic system checks. - +33 (0)1 34 34 11 55 Hexagone Manufacture In any case, the liability of Hexagone Manufacture cannot be held responsible and this emergency procedure is your responsibility. ART-NTU-XUNIMPN000 – Instructions for use and use Unikart Classic Motorized... -
Page 24: Maintenance Plan
Hexagone reserves the right to change the time between maintenance and the list of parts to change to ensure optimum and safe operation. Any refusal to change parts recommended by Hexagone will render the device out of service. ART-NTU-XUNIMPN000 – Instructions for use and use Unikart Classic Motorized... - Page 25 If technician revision Hexagon or distributor: No intervention number:: Reference or Part Old / new serial number Reference or Part Old / new serial number Additional information - specific: Additional information - specific: ART-NTU-XUNIMPN000 – Instructions for use and use Unikart Classic Motorized...
-
Page 26: Practical Informations
HEXAGONE MANUFACTURE 1-5 rue Michel Carré 95104 – Argenteuil - FRANCE Tél : +33 (0)1 34 34 11 55 Fax : +33 (0)1 34 34 11 50 Web : www.myhexagone.com www.facebook.com/myhexagone ART-NTU-XUNIMPN000 – Instructions for use and use Unikart Classic Motorized...
