- Page 1 WiFi Camera Eyepiece KoPa® HD-UWF User’s Manual Meiji Techno America meijitechno.com...
-
Page 2: Table Of Contents
HD-UWF User’s Manual Meiji Techno America meijitechno.com Content CHAPTER 1 NOTES AND SAFETY REQUIREMENTS ------------------------------------------------------------- 1 1.1 Cautions and Notes -------------------------------------------------------------------------------------------------- 1 CHAPTER 2 SOFTWARE SYSTEM REQUIREMENTS ------------------------------------------------------------- 2 2.1 System Requirements Under USB Work Mode ------------------------------------------------------- 2 CHAPTER 3 PACKING LIST -------------------------------------------------------------------------------------------------------- - 3 CHAPTER 4 FUNCTION INTRODUCTION OF EACH PART ----------------------------------------------------- 4 4.1 Name and Function for Each Part of the WiFi Camera Eyepiece --------------------------- 4... -
Page 3: Chapter 1 Notes And Safety Requirements
HD-UWF User’s Manual Meiji Techno America meijitechno.com Chapter 1 Notes and Safety Requirements 1.1 Cautions and Notes To avoid danger or damage incurred to the lens, do not touch the lens or sensor directly wth your fingers To avoid failure or electric shock hazard and so on, do not disassemble or modify the internal structure of the device. -
Page 4: Chapter 2 Software System Requirements
HD-UWF User’s Manual Meiji Techno America meijitechno.com Chapter 2 Software System Requirements 2.1 System Requirement under USB Work Mode ● Windows 7 (64 bits), Windows 8 (64bits), Windows 8.1 (64bits), Windows 10 (64 bits) ● Dual core 3GHz or higher CPU ●... -
Page 5: Chapter 3 Packing List
HD-UWF User’s Manual Meiji Techno America meijitechno.com Chapter 3 Packing List 1. WiFi Camera Eyepiece 2. Hexagon key 3. Installation disk 4. USB Power Adapter - 3 -... -
Page 6: Chapter 4 Function Introduction Of Each Part
HD-UWF User’s Manual Meiji Techno America meijitechno.com Chapter 4 Function Introduction of Each Part 4.1 Name and Function for Each Part of the WiFi Camera Eyepiece 1. Female interface: connected with the eyepiece end of biological microscope. 2. Fastening screws: tighten the screws with the hexagon key to fix the eyepiece end of the biological microscope. -
Page 7: Chapter 5 Product Assembly Guide
HD-UWF User’s Manual Meiji Techno America meijitechno.com Chapter 5 Product Assembly Guide 5.1 WiFi camera Eyepiece Assembly 5.1.1 Assembly with biological microscope 1. Separate eyepiece part from objective part as shown in figure 1 1) Loosen the fixing screw of the microscope. -
Page 8: Chapter 6 Instructions
HD-UWF User’s Manual Meiji Techno America meijitechno.com Chapter 6 Instructions 6.1 Software installation 6.1.1 USB working mode Install software KoPa Capture: Place the coming CD in your computer's DVD drive and click KoPa Capture Install to complete the installation of the application. For specific installation methods, please refer to User Manual of KoPa Capture English 6.1.2 WiFi working mode... -
Page 9: Chapter 7 Disclaimer
HD-UWF User’s Manual Meiji Techno America meijitechno.com Chapter 7 Disclaimer In order to protect the legitimate rights and interests of users, please carefully read the instructions, disclaimers and safety instructions provided with this product before using it. The company reserves the right to update the above documents.
