SICO SAS Series Assembly Instructions And Parts List

Dual height steps
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

BEFORE YOU BEGIN...

Read and understand these instructions
before operating.
Use caution and care for your back when
lifting, pushing, pulling, or folding and
unfolding these units. Never lift more than
you are able to safely handle.
WARNING
To avoid injury, read and understand
these instructions before you start to
set up the stage.
Printed in USA (08/09)
DUAL HEIGHT STEPS

TOOLS REQUIRED

- Two 17mm wrenches
If you have any problems during setup,
contact SICO Customer Care at
® SICO Incorporated.
SAS SERIES
AND PARTS LIST
1-800-424-0796
Part No. 281610 Rev. C
