Available types and technical data

AEL5961 230 Vac positioner card
AEL5962 115 Vac positioner card
24Va c p o s i t i o n e r c a r d (exc e p t f o r
AEL5963
AEL54213 _ , AEL55313 _ and AEL56413 _ )
24 Vac positioner card (for AEL54213 _ ,
AEL5964
AEL55313 _ and AEL56413 _ actuators only)
AEL5951 2 auxiliary limit switches (Electronic card)
AEL5952 Auxiliary feedback potentiometer
AEL5952.1 Tandem feedback potentiometer
AEL5952.2 Tandem feedback potentiometer
AEL5952.3 Auxiliary feedback potentiometer
AEL5952.4 Tandem feedback potentiometer
AEL5952.5 Auxiliary feedback potentiometer
AEL5953 Tandem feedback potentiometer
AEL5954 115 - 230 V anti-condensate heater
AEL5956 24 V anti-condensate heater
AEL5981
Position transmitter
AEL5982 Position transmitter
The potentiometer must use its whole range (almost 1 full turn). To facilitate different actuator strokes replacement pinion kits are
available. Please contact Spirax Sarco for further information.
Pinion 25 teeth with AEL5 _
Pinion 30 teeth with AEL5 _
Pinion 50 teeth with AEL5 _
Special parts
Pinion 65 teeth with AEL5 _
Pinion 75 teeth with AEL5 _
For information on AEL5 series actuators see TI-P358-25
Local regulations may restrict the use of this product to below the conditions quoted.
Accessories
for the AEL5 Series
of Electric Linear Actuators
Power consumption 1 VA
Power consumption 1 VA
Power consumption 1 VA
Power consumption 1 VA
5 A - 230 Vac - including cams, mounting kit and PCB
1000 ohms,
2 x 1000 ohms
2 x 1000 ohms
2000 ohms
2 x 2000 ohms
500 ohms
2 x 1000 ohms
2 wire 4 - 20 mA
3 wire 0 / 4 - 20 mA
For stroke <= 20 mm
For stroke between 20 mm to 30 mm
For stroke between 30 mm to 50 mm
For stroke between 50 mm to 65 mm
For stroke between 65 mm to 70 mm
20 to 30 mm stroke, including mounting kit and pinion
20 to 30 mm stroke, including mounting kit and pinion
25 mm maximum stroke, including mounting kit and pinion
20 to 30 mm stroke, including mounting kit and pinion
20 to 30 mm stroke, including mounting kit and pinion
20 to 30 mm stroke, including mounting kit and pinion
20 to 30 mm and 30 to 50 mm stroke,
including mounting kit and pinion
TI-P358-28
CH Issue 3
