ProLaser 4 Menus
The menu button accesses the following settings or modes:
Distance
Sets min/max range limits to target vehicle for school and
work zone enforcement. Fire the laser at the desired
target and press enter to set min/max ranges. Any target
measured outside the range limits will not be displayed.
Set Direction
Sets target direction discrimination to Approaching only,
Receding only, or Both.
DIF-TEST
Two-target, differential distance accuracy test mode.
HUD
Toggle Range in HUD on/off.
Options
Select from four aiming
reticles.
Self-Test
Press the test button to run internal accuracy tests.
HUD Alignment
Place the ProLaser 4 in range mode. Select an isolated
Test
target ~100 feet away and sweep HUD horizontally and
vertically across target. Listen for audio tone and verify
aiming reticle on target coincides with tone and range
measurement in HUD.
Differential
Select two targets ~ 50 and 100 feet away. Target each
Distance Test
when prompted and verify range accuracy.
9652 Loiret Boulevard, Lenexa, KS 66219-2406
(800)4KUSTOM
(800) 458-7866
www.kustomsignals.com
KSI Part # 006-0966-11 Rev. 2
ProLaser 4 Quick Start Guide
North Carolina Configuration
HUD Display
www.kustomsignals.com
(800) 4KUSTOM
(800) 458-7866
Advertisement
Table of Contents
Related Manuals for Kustom Signals ProLaser 4
Summary of Contents for Kustom Signals ProLaser 4
- Page 1 Self-Test Press the test button to run internal accuracy tests. HUD Alignment Place the ProLaser 4 in range mode. Select an isolated Test target ~100 feet away and sweep HUD horizontally and HUD Display vertically across target. Listen for audio tone and verify aiming reticle on target coincides with tone and range measurement in HUD.
- Page 2 8. Release the trigger to lock the measurement in the HUD and rear panel display. The ProLaser 4 will enter default sleep mode after two (2) minutes, and will power down after 15 minutes. Sleep timers are adjustable.
