Anchor Seville LP-500 Owner's Manual

Lectern sound system

Advertisement

Quick Links

HAVING TROUBLE W/ YOUR SOUND SYSTEM?
CONDITION
POSSIBLE SOLUTION
No Sound (Power LED OFF)
• turn POWER switch on; plug in power cord
• check for blown fuse
No Sound (Power LED ON)
• turn up volume control of input used
• set INT SPKR switch to ON position
• make sure external speaker & all cables are completely plugged in
Feedback w/ Lectern Mic
• lower the mic volume control
• direct lectern away from reflective surfaces
• try adjusting tone controls
No Sound w/ Line Input
• check for output from source
• plug input cables completely in
HAVING TROUBLE W/ YOUR WIRELESS SYSTEM? (WIRELESS MODELS ONLY)
CONDITION
POSSIBLE SOLUTION
No Sound (RX Indicator ON)
• set MUTE switch to on (handheld mic only)
• turn up Wireless Level Control
• make sure mic is plugged into body pack transmitter
No Sound (RX Indicator OFF)
• push mic power button
• turn Seville POWER switch on
• make sure transmitter power switch is on
• replace battery in transmitter
NEED MORE HELP? View demonstration videos on proper system setup & operation:
www.anchoraudio.com/seville.php
ANCHOR AUDIO CUSTOMER SERVICE
888-444-6077
SEVILLE TECHNICAL SPECIFICATIONS
Rated Power Output
70W continuous
Max SPL @ Rated Power 107 dB @ 1 meter
Frequency Response
65 Hz – 15 KHz
AC Power Reqs.
110 – 125 Volts AC, 50/60 Hz
210 – 240 Volts AC, 50/60 Hz
(40 VA nominal, 120 VA max)
Speaker Type
6.5 inch woofer, high-output tweeter
Dimensions (HWD)
49 x 24 x 21" / 125 x 61 x 53 cm
Weight
122 pounds / 55 Kg
Anchor Audio, Inc.
Portable Sound Systems • Torrance, California
Inputs
Lectern Mic
Lo-Z, balanced, phantom power, XLR
Auxiliary Mic
Lo-Z, balanced, phantom power, XLR
Line
Hi-Z, unbalanced, 1/4"-phone
Sensitivity For Rated Output
Microphone
-52 dBV (2.5 mVrms)
Line
-14 dBV (200 mVrms)
Outputs
Mic (post fader)
Lo-Z, transformer balanced, XLR
Line (post fader)
buffer isolated, 1/4" phone
Speaker
70W @ 4ohm, switched, 1/4" phone
(Specifications subject to change without notice)
SEVILLE
LECTERN SOUND SYSTEM
OWNER'S MANUAL
GETTING STARTED ................................................................................................................................................. 2
SPEAKER FEEDBACK ............................................................................................................................................... 3
BASIC SYSTEM OPERATION ................................................................................................................................. 4/5
CARING FOR THE SEVILLE ...................................................................................................................................... 5
SEVILLE LECTERN ACCESSORIES ............................................................................................................................ 5
WIRELESS SYSTEM SETUP & OPERATION ............................................................................................................................... 6/7
HAVING TROUBLE W/ YOUR SOUND SYSTEM? ...................................................................................................... 8
SEVILLE TECHNICAL SPECIFICATIONS ................................................................................................................... 8
100-0064-000/C - 1/07
