Summary of Contents for AOMWAY TX004
- Page 1 AOMWAY RC VISION SYSTEMS AOMWAY 5.8GHz Transmitter & Receiver User Manual WWW.AOMWAY.COM...
-
Page 2: Transmitter Specifications
AOMWAY RC VISION SYSTEMS 1. Transmitter Specifications: Model# TX004 TX003 TX1000 Output Power 25/200mw 25/100/200/600mw 1000mw Working Voltage 6-26v 6-26v 7-26v Power Consumption 12v170mA@200mw 12v170mA@200mw 12V 650mA Frequencies 64CH: 64CH 32CH Format NTSC/PAL NTSC/PAL NTSC/PAL Output Voltage 5V/12V SMA-Jack Antenna... - Page 3 Jumper onto LEFT socket for 5V output voltage. b) Jumper onto RIGHT socket for 12V output voltage. (same as the input voltage of receiver) 4. Tx Accessories TX Power TX004 TX003 1000mw (V4) Antenna X1 3db omni antenna 3db omni antenna...
- Page 4 AOMWAY RC VISION SYSTEMS 6. Receiver Specifications: Model DIV006 V4(DVR) DVR Function DVR with auto save function Working 7-26v Voltage Power 12V,210mA Consumption Channel 64CH（RaceBand） Format NTSC/PAL selectable via menu Sensitivity ≥-95db Digital Display, Channel Single Button Selection, Selection Auto Scan, Diversity...
- Page 5 AOMWAY RC VISION SYSTEMS 8. Frequency Chart: 9. DVR Operation WWW.AOMWAY.COM...
- Page 6 10s before re-plug on power, otherwise DVR will not be ready to use. - When power on, DVR will ouput AOMWAY logo on screen, and then display RF/AV signal; DVR is standing by at this moment and LED light stays solid on.
- Page 7 AOMWAY RC VISION SYSTEMS - AV1 passes signal to DVR first, and then output; this is in order to prevent blue screen and enable user to check actual recording status. - AV2 can output signal directly to AAT or monitor, etc.
