Installation and operating
manual
PURE-COMPACT water- oil separator
Please read the following instructions carefully before installing separator housing unit into
service. Trouble free and safe operating of the unit can only be guaranteed if
recommendations and conditions stated in this manual are respected.
Advertisement
Table of Contents
Summary of Contents for PURE PURE-COMPACT
- Page 1 Installation and operating manual PURE-COMPACT water- oil separator Please read the following instructions carefully before installing separator housing unit into service. Trouble free and safe operating of the unit can only be guaranteed if recommendations and conditions stated in this manual are respected.
- Page 2 PURE-COMPACT - Installation and operating manual Components Part Filter head Inlet connection Outlet connection Wall mounting bracket Filter cap O-rings Filter element...
-
Page 3: Technical Data
PURE-COMPACT - Installation and operating manual Technical data Cold climate zone Mild climate Hot climate zone Size 15°C 60%RH zone 25°C 60%RH 40°C 100%RH Max oil adsorption[g] WOSm1 1,23/43,05 1,08/37,8 0,62/21,9 Max FAD [Nm /min]/[scfm] 0,57 0,90 1,91 Max condensate flow [l/h]... -
Page 4: Safety Instructions
PURE-COMPACT - Installation and operating manual Safety instructions The relevant safety at work and accident prevention regulations, plus operating instructions, shall apply for operating the separator. The separator has been constructed in accordance with the generally recognized rules of engineering. -
Page 5: Appropriate Use
PURE-COMPACT - Installation and operating manual Appropriate use PURE-COMPACT water oil separators are intended for separation of lubricant oil from condensate generated in compressed air systems. This appliance must be used only for the purpose for which it was specifically designed. All other uses are to be considered incorrect. -
Page 6: Installation
Unpack the device Fill the filter element with clean water! PURE-COMPACT separator is optimized for mounting on the wall and therefore wall mounting bracket is included. (wall mounting screws are not included) Make sure that you have easy access to the device and that there is enough space to unscrew and remove filter element. -
Page 7: Maintenance
PURE-COMPACT - Installation and operating manual Maintenance It is rec ommended, that you do a check once per week to evaluate filter element saturation. To test water quality use test set. Instructions are attached in test set. Filter element must be replaced when first of the following parameters appears: ... -
Page 8: Warranty Exclusion
PURE-COMPACT - Installation and operating manual Warranty exclusion The guarantee shall be void if: The operating instructions were not followed with respect to initial commissioning and maintenance. The unit was not operated properly and appropriately. The unit was operated when it was clearly defective.
