Summary of Contents for Fishguard Fx System
- Page 1 User Manual...
-
Page 2: Table Of Contents
Contents Fishguard Fx System Fx Control Unit -Front Elevation -Sound Selection -Battery Replacement Fx Floodlight -Front Elevation -Rear Elevation -Battery Replacement Ambient Lighting -Front Elevation -Rear Elevation -Battery Replacement Activating Security System Communication -Optimum Range System Setup -Fx Sensor Alignment... -
Page 3: Fishguard Fx System
Fishguard Fx System Fx Sensor Fx Control Unit Fx Sensor Fx Floodlight (Add-on) Fx Sensor (Add-on) -
Page 4: Fx Control Unit
Fx Control Unit Front Elevation Antenna Sound Selection/Pairing Fx Control Unit (Blue LED) Fx Floodlight (White LED) Fx Sensor (Green LED) Fx Sensor (Red LED) Fx Sensor (Amber LED) Pairing Point Speaker... -
Page 5: Sound Selection
Fx Control Unit Sound Selection Door Bell Dog Growl Dog Bark Owl Hoot Pairing Mode System Status Check: LEDs for all active units will illuminate when selecting an alternative sound. LEDs will go out after 5 seconds... -
Page 6: Battery Replacement
Fx Control Unit Battery Replacement Lock Insert Tether Quarter Turn Lock (unlocked position) End Cap Release Turn Quarter Turn Lock anticlockwise to unlock; clockwise to lock, with unit facing up. (4 x AA Batteries required) Up to 70 hours battery life The EndCap ts tightly;... -
Page 7: Fx Floodlight
Fx Floodlight Front Elevation Security Lighting Ambient Detection Lens Ambient Lighting Battery Twist Lock Locking Disc... -
Page 8: Rear Elevation
Fx Floodlight Rear Elevation Security Status LED Security Dimmer Security Liight On/O Ambient Light On/O Ambient Dimmer Ambient Detection Lens Ambient Lighting Battery Twist Lock Locking Disc... -
Page 9: Battery Replacement
Fx Floodlight Battery Replacement Battery Tray Battery Twist Lock Turn battery twist lock anticlockwise to release; clockwise to lock. (4 x AA Batteries required) Up to 80 hours battery life... -
Page 10: Ambient Lighting
Ambient Lighting Turn Ambient Lighting On. Ambient Lighting will illuminate Ambient Lighting is activated by infrared sensors behind the Ambient Detection Lens’ Ambient Lighting will go out 30 seconds after last detection Detection Range up to 3m Turn Ambient Lighting O . Ambient Lighting will go out... -
Page 11: Front Elevation
Fx Sensor Front Elevation Detection Lens Battery Twist Lock Locking Disk Take care not to mark Detection Lens... -
Page 12: Rear Elevation
Fx Sensor Rear Elevation Silicon Band (optional) Sensor Status LED Battery Twist Lock Locking Disk Use Silicon Band to cover Sensor Status LED if visible at night... -
Page 13: Battery Replacement
Fx Sensor Battery Replacement Battery Tray Battery Twist Lock Turn battery twist lock anticlockwise to release; clockwise to lock. (2 x AA Batteries required) Up to 500 hours battery life... -
Page 14: Activating Security
Activating Security Turn Control Unit On (click), blue LED will illuminate Turn Fx Sensors On. Status LEDs will illuminate above the On/O buttons. Corresponding Control Unit LEDs will ash slowly (whilst infrared sensors adjust to the environment) Turn Security Light On (top button on the Fx Loo ight). Status LED will illuminate above the On/O button. -
Page 15: System Communication
System Communication Optimum Range Optimum range is achieved by keeping the Control Unit upright at all times (100m range) System range will be severely e ected if the Control Unit is laid at... -
Page 16: System Setup
System Setup Fx Sensor Alignment Vertically align Fx Sensor for optimum detection and reliability. 0° 0° 10° 10° 10° 10° 20° 20° 20° 20°... -
Page 17: Fx Sensor Field Of View
System Setup Field of view Keep Fx Sensor Unit faces clear of branches and foliage to avoid false detection Be aware of environmental movement in windy conditions... -
Page 18: Optimum Height
System Setup Optimum Height Fx Sensors can be set at any height. For optimum performance of the ambient lighting the Fx Floodlight should be set minimum of 500mm 700mm 600mm 500mm 400mm 200mm 100mm... -
Page 19: Fx Sensor Detection
System Setup Fx Sensor Detection Each Fx Sensor has a di erent colour status LED, indicating which Sensor is triggered. Position the Fx Sensors like trip wires. Detectionis most e ective when crossing the invisible beam. Detection range can be a ected by extreme light and temperature; ideally suited to nightime operation... -
Page 26: Troubleshooting
Troubleshooting Possible Causes Fixes Out of range Ensure Fx Sensors and Fx Floodlight are within 100m of the Control Unit Ensure the Control Unit is upright Fx Sensor or FX Floodlight have been Turn Fx Sensor/Fx oodlight back on, turned o or turn the Control unit On/O Unit won’t turn On Batteries are exhausted... - Page 27 Troubleshooting Issue Possible Causes Fixes Blue LED On continuously Control Unit batteries are exhausted Replace batteries with new premium on Control Unit batteries Corresponding Fx Sensor The corresponding Unit batteries are Replace batteries with new premium or Fx Floodlight LEDs exhausted batteries showing ON continuously...
-
Page 28: Product Care / Cautions
Guidelines Product Care / Cautions Fx Floodlight and Fx Sensos are weather proof, including heavy rain. (Do Not submerge in water as it will invalidate guarantee) Control Unit is not weatherproof, light rain only (Do Not leave outside in the rain, or submergein water as it could invalidate guarantee) Avoid looking directly at the Security Lighting LEDs Take care not to mark the Detection Lenses... -
Page 29: Batteries
Guidelines Batteries Use Alkaline Batteries only; not suitable for Lithium Batteries Always use Premium brand Batteries for optimum results Use Non-Rechargeable Batteries only (Rechargeable Batteries are lower voltage and will not work) Always replace batteries with brand new ones, don’t mix battery brands, and use batteries before their Use-By date Battery life will be a ected by product use and batttery quality Guarantee... - Page 30 © 2020 Mogoza Ltd. All rights reserved.
