KT 50Ah User Manual

USER MANUAL
Lithium iron phosphate
LiFePO4 battery
12,8 V
1. SAFETY NOTES
1.1.GENERAL RULES
Read this manual before use.
Explosion or fire hazard. Lithium-ion battery ter-
minals are always live. Therefore, it is forbidden to
place items or tools directly on the li-ion battery.
Too deep discharge is very dangerous and may
damage the battery. Therefore, it is obligated to
use internal safety relay.
It is forbidden to open or disassemble li-ion battery.
The battery contains electrolyte that is very corro-
sive. In normal operating conditions contact with
electrolyte is impossible. If the battery case is da-
maged, it is forbidden to touch exposed electrolyte
due to corrosive effects.
Never short circuit positive (+) and negative (-) pole of the battery!
CAUTION!
NON-COMPLIANCE WITH MANUAL, REPAIRS MADE WITH OTHER THAN ORIGINAL PARTS
OR UNAUTHORISED REPAIRS RENDER THE WARRANTY VOID.
1.2. TRANSPORTATION
CAUTION!
The li-ion battery must be transported in its original
case in upright position.
If the battery is transported in packs on pallets and the use of straps
is required, use soft straps to support the load to avoid damage.
It is forbidden to stand below the battery when it is hoisted.
Always handle the battery with handles, never the terminals!
2.2.GENERAL INFORMATION
Lithium-iron-phosphate (LiFePO4 or LFP) batteries have no memory effect and provide the highest energy density. The self-discharge effect is
negligible and they have long lifetime. The li-ion battery with iron and phosphate admixtures has the safest cells available on the market. The
nominal voltage of cell is 3,2 V. Therefore the 12,8 V Li-ion battery consists of 4 cells connected in series.
The nominal capacity of the battery is:
• 50 Ah • 75 Ah • 100 Ah • 150 Ah
2.1. EFFICIENCY
The energy efficiency of the entire cycle of a lithium-ion battery
(discharge from 100% to 0% and recharge from 0% to 100%) is 92%.
By comparison, in a lead-acid battery, the energy efficiency is only
80%. The LiFePO4 battery can be charged and discharged at high
current levels without loss of capacity and has a very high durability
(the number of complete charge-discharge cycles while maintaining
up to 80% of nominal capacity is up to 2000).
The energy density of the battery reaches over
120 Wh/kg, which is very desirable and energy efficient.
1
• 200 Ah
https://www.kon-tec.eu/batteries/
50Ah
150Ah
Wear protective eye-glasses and clothing during
using the li-ion battery.
Any uncovered battery parts or material such as
electrolyte or powder on skin, or eyes must be
flushed with plenty of clean water immediately.
Then consult with a doctor. Spillages on clothing
should be flushed with water
In case of overcharge, over discharge or any
damage to the battery there may be released dan-
gerous gas compounds.
The battery is heavy. In case of damage or an
accident it can become explosive. During montage
or transport ensure proper protection and use
suitable equipment. Li-ion battery is sensitive to
shock. Handle with care
1.3. UTILIZATION OF LI-ION BATTERIES
Batteries marked with the recycling symbol must be disposed via
recognized recycling agency. Batteries may be returned to the
manufacturer by agreement. Used batteries must not be mixed with
domestic or industrial waste.
2.2. DIMENSIONS AND WEIGHT
Capacity [Ah] Weight [kg] Dimensions [mm]
50 5,8 196x165,5x175
75 9,5 260x168x213
100 12,5 308x169x211
150 19,6 483,5x170x241
200 26 483,5x170x241
2.3. APPLICATION
- Electric vehicles (EV),
- Outboard motors,
- Power source for inverters 12 V-/230 V~,
- Toys.
Kon-TEC Kraczkowa 1647 37-124 Kraczkowa, Poland
Tel.: +48 695 904 655 email: info@kon-tec.eu
75Ah 100Ah
200Ah
www.kon-tec.eu
