[89 mm]
2.50
[63 mm]
.88
[22 mm]
3.50
NOTICE: This drawing is the
property of AMX Corporation.
All information contained herein
that is not generally known
shall be confidential except
to the extent the information
has been previously established.
This drawing may not be copied,
reproduced, or used as the basis
for manufacture or sale without
written permission.
REV
ECN
4908 PRODUCTION RELEASE
A
REL APPR
REL DATE
REV APPR
UNLESS OTHERWISE SPECIFIED:
DAS
4/1/03
DRAWN
TOLERANCE ON DECIMAL DIMENSIONS:
XX = .010
XXX = .005
ENGR SERV
PL
4/11/03
TOLERANCE ON HOLE DIAMETERS:
PS
4/11/03
ENGINEER
UNDER .250 ú
= +/- .005
.250 TO .500
= +.006 -.005
PROD ENGR
TG
4/11/03
OVER .500
= +.008 -.005
FRACTIONAL DIMENSIONS INCLUDING HOLES: +/- 1/64
MD
4/11/03
MATL SUP
ANGLES: +/- 1.0°
SURFACE FLATNESS .003 TIR PER LINEAR INCH.
AK
4/11/03
QUALITY
ALL DIMENSIONS IN INCHES.
THIRD ANGLE
DO NOT SCALE THIS DRAWING.
PROJECTION
REVISIONS
DESCRIPTION
DATE
APPROVED
4/11/03
TM
PICTORIAL,
VST-TTM, VIEWSTAT DUAL TEMPERATURE,
SUPPORT MODULE
SIZE
DWG. NO.
REV.
SCALE
95-0944-10
B
FULL
A
1 OF 1
95-0944-10-A
SHEET
