Step 2 / Étape 2 / Paso 2
You will need for this page:
Nécessaire pour cette page:
Usted necesitará para esta página:
6521
(QTY/QTÉ/CANT: 10)
11244
Rear
Arrière
Atrás
(QTY/QTÉ/CANT: 1)
Uncrimped Rib
Nervure non sertie
Reborde ancho
Whenever a crimped rib and an uncrimped
rib meet, the crimped rib should be placed
UNDER the uncrimped rib if possible.
Lors de l'assemblage de toute nervure sertie avec une
nervure non sertie, la nervure sertie doit être placée
SOUS la nervure non sertie autant que possible.
Cuando un reborde rizado y un reborde ancho
se unen, el reborde rizado debe colocarse
DEBAJO del reborde ancho, si es posible.
Floor Frame Assembly
Assemblage cadre de plancher
Tirante del piso ensamblaje
18
12
11244
1
Wall Panel
Rear Corner Panel
Panneau de coin
Panneau de mur
arrière
Panel esquinero
Panel de la pared
trasero
Crimped Rib
Nervure sertie
Reborde rizado
18GY
1
6521
