Installation Instructions
OVERVIEW - Engineer's Specification
The Potter PVC system shall include one Master Panel and one or more Distributed Panels.
The system shall be microprocessor based, and shall be compatible for use with contact
closures from the Fire Alarm Control Panel, (FACP). The system shall have a high-speed
communication bus and have the capacity for 6 channels of combined audio and data on a
single pair of wires. The field wiring for the communication bus may be configured for either
Style 4 or Style 7 supervision. The system shall have the capacity for Fire Fighters Phone
communication. The system shall have a minimum capacity of 2048 monitor and control
points.
The Master Panel shall contain an integral microphone, dual channel digital message
repeater, (DMR) and digital tone generator, 120 VAC power supply, and battery charger.
Note: Panels may be supplied with transformers wired for 240 VAC for those regions where
this is required. Please refer to Ratings section for Primary Power differences.
The system shall be modular in design, and shall be expandable such that additional system
control points may be configured. The system shall include integral self-diagnostic routines
that shall continually monitor system status, and shall indicate the precise type of trouble
conditions should they occur in the system. A trouble condition within the system shall cause
a trouble indication to be transmitted to the FACP.
Distributed panels shall provide a minimum of 4 Class "B" (Style Y) speaker circuits,
expandable to eight total. Alternately, panel may be configured for 4 Class "A" (Style Z)
speaker circuits. Panel will provide up to 6 simultaneous audio channels, up to 16 Fire
Phone circuits. Amplifiers will contain their own power supplies, battery chargers and provide
auxiliary power for other components. Speaker circuits shall be supervised for short and open
circuit conditions, and shall be able to withstand transient or continuous short-circuit
conditions without damage to the system.
System may be configured for General Alarm All Call operation, Alarm by Zone or
Floor Above / Floor Below as required. Contact closures shall allow immediate broadcast of
an alarm signal and evacuation message to the appropriate area. Non-Alarm areas may
receive alert tones and messages as required or activated by the FACP.
The alarm signal/evacuation message shall be broadcast until the FACP is reset, or until
emergency personnel interrupt the broadcast with a manual page.
To prevent unauthorized tampering, the voice evacuation system shall disable the
microphone if the microphone is keyed continuously for 3 minutes or more. Systems that do
not have this feature shall not be acceptable.
For technical assistance please call:
866-956-1211
5757 Phantom Dr. St. Louis, Missouri 63042
www.pottersignal.com
P/N PV-5010 R7.16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PVC 25 and is the answer not in the manual?

Questions and answers

Summary of Contents for Potter PVC 25

  • Page 1 Installation Instructions OVERVIEW - Engineer’s Specification The Potter PVC system shall include one Master Panel and one or more Distributed Panels. The system shall be microprocessor based, and shall be compatible for use with contact closures from the Fire Alarm Control Panel, (FACP). The system shall have a high-speed communication bus and have the capacity for 6 channels of combined audio and data on a single pair of wires.
  • Page 2: Installation

    Please read this Manual completely before installing the PVC System. INSTALLATION Installer must insure that all wiring and devices installed in system meet the following standards: National Electrical Code (NFPA 70) NFPA Standard 72 Life Safety Code (NFPA 101) Install equipment in a clean, dry environment, avoid installation where equipment could be subjected to vibration.
  • Page 3: System Operation

    System Operation **Note** ALL panels in system are pre-programmed at the factory Alarm When an input on the PVC-II FACP Interface card is pulled down to circuit common (0VDC), the Evacuation Signal and Message will be broadcast into the selected Evacuation Zone.
  • Page 4 PVC Control Panel Refer to Master Panel Controls and Display diagram (Page 6). The Control Panel status indicators are 'Alarm', 'Fault' and 'Power'. During 'Power On Diagnostics', the system is scanned for active Distributed Panels and peripherals. The Message Display indicates how many Distributed Panels have been found and all event buffers are cleared.
  • Page 5: Typical System Layout

    Potter PVC Distributed Panel Voice Evacuation True Multiplex System Speaker Circuits Typical System Layout Fire PVC-25 PVC-25 PVC-50 Phone PVC-50 PVC-100 PVC-100 Local Audio Amplifiers Fire Phone Circuit NetComm Loop: Unshielded Twisted Pair, Single pair 18/2 or larger, Unshielded twisted pair (UTP)
  • Page 6 Master Panel Wiring NetCom Bus refer to illustration on page 9 for info Supervised on jumper J3 placement *A - Optional wiring for Style 7 supervision Master Panel Controls and Displays Alarm Fault Power Message Display MP 64/P panel System Reset Paging All-Call Paging Microphone Fault Silence...
  • Page 7 Ratings section for Primary Power differences. PVC 25(E) / 50(E) / 100(E) TROUBLE CODES When a unit goes into a Trouble Condition, the Yellow LED wil remain on until the trouble is cleared. The Green LED will flash a Code to indicate the type of Trouble Condition. There will be a pause between repeats of the code.
  • Page 8 Field wiring connections: Master Panel DCC #6-32 wire clamp screw 14-18 AWG Connection Detail #8-32 wire clamp screw 12-18 AWG Horizontal wire entry terminal 18-26 AWG Terminal Designation Wire gauge determined by circuit load From Last Next Optional - Style 7 Style 4 Supervision Conduit...
  • Page 9 PVC-II / PWR Connection Detail Terminal Designation To FACP Input Control 1- 8 Input Control (1mA 5VDC) (N.O. Dry Contact) 9 Circuit Common (NEG) 10 FACP Bell Circuit + (Alarm 11 FACP Bell Circuit - Polarity) (10mA 24VDC) Input 1 FACP EOLR Card 2 FACP EOLR Non-Supervised - Power Limited...
  • Page 10 Connection Detail Terminal Designation Supervised - Power Limited EOLR CLASS “B” (Style “Y”) Match EOLR to TB-9 value WIRING SPEAKER OUTPUT Break wire to maintain supervision. Do not loop wire around speaker terminals. 50W Maximum Standard Life Safety Speakers, Strobes connected and powered separately. Speaker line EOLR must be Ground faults are indicated at 10K impedance or less.
  • Page 11 PVC Specifications Communications Bus: The communications bus conforms to the RS-485 standard and requires the use of UTP- cable for 1M Baud data rates. Wiring must be run in conduit in a daisy chain from the Master Panel to the first Dist. Panel, from each Dist. Panel to the next Dist. Panel and from the last Dist. Panel back to the Master Panel.
  • Page 12: Specifications

    PVC 25 / 50 / 100 Specifications ELECTRICAL RATINGS: PVC 25 / 25E PVC 50 / 50E PVC 100 / 100E Primary Input Voltage 120 Vac @ 60 Hz 120 Vac @ 60 Hz 120 Vac @ 60 Hz Primary Input Current 0.8 A @ 120 Vac...
