SEARCHLIGHTS DHR 260DS
Deck operated
MANUAL
Searchlights
TOPLICHT
Art-Nr.
3322-222
3322-224
3322-522
3321-102
3322-103
Deck operated
Typ
Ausführung / Leuchtmittel
260DS024
Scheinwerfer / Halogen 24 V
260DS220
Scheinwerfer / Halogen 24 V
260DS070
Scheinwerfer / Metall Halide
Halogenlampe M35
Standrohr 800 mm
Notkestraße 97 · 22607 Hamburg
DHR 260
Spannung Leistung Reichweite
24 V
250 W
230 V
250 W
230 V
200 W
24 V
250 W
Den Haan Rotterdam B.V.
Wijnhaven 81
3011 WK ROTTERDAM
The Netherlands
Phone: +31 (0)10 – 413 07 55
Fax: +31 (0)10 – 413 54 87
E-mail:
info@dhr.nl
Rev. 1
1100 m
1100 m
1800 m
Schiffsausrüster
Schiffsausrüster
Tel.: +49 ( 0 ) 40 - 88 90 100
Tel.: +49 ( 0 ) 40 - 88 90 100
www.toplicht.de
www.toplicht.de
Advertisement
Table of Contents
Summary of Contents for Toplicht DHR 260DS
- Page 1 SEARCHLIGHTS DHR 260DS Deck operated Notkestraße 97 · 22607 Hamburg Rev. 1 MANUAL Searchlights DHR 260 Deck operated TOPLICHT Art-Nr. Ausführung / Leuchtmittel Spannung Leistung Reichweite 3322-222 260DS024 Scheinwerfer / Halogen 24 V 24 V 250 W 1100 m 3322-224...
-
Page 2: Introduction
SEARCHLIGHTS DHR 260DS Deck operated Notkestraße 97 · 22607 Hamburg Den Haan Rotterdam Rev. 1.0 Page 2 of 14 5 November 2004 Introduction Den Haan Rotterdam, specialist in developing and manufacturing navigation lights for ships since 1922. Besides, 40 years active in producing searchlights for pleasure craft, inland trade and seagoing vessels. -
Page 3: Table Of Contents
SEARCHLIGHTS DHR 260DS Deck operated Notkestraße 97 · 22607 Hamburg Den Haan Rotterdam Rev. 1.0 Page 3 of 14 Table of contents Introduction........................2 Table of contents ......................3 Safety notes ........................4 Mounting instructions.....................4 Maintenance........................5 Lamp replacement ....................5 Preventive maintenance ...................5 Technical specification....................6 Guarantee ........................7... -
Page 4: Safety Notes
SEARCHLIGHTS DHR 260DS Deck operated Notkestraße 97 · 22607 Hamburg Den Haan Rotterdam Rev. 1.0 Page 4 of 14 Safety notes WARNING Risk of electrical shock - Turn power off before inspection, installation or removal Risk of fire - Keep combustible materials away from lamp Pressurized lamp—unexpected rupture may cause injury, fire, or property damage... -
Page 5: Maintenance
SEARCHLIGHTS DHR 260DS Deck operated Notkestraße 97 · 22607 Hamburg Den Haan Rotterdam Rev. 1.0 Page 5 of 14 Maintenance Lamp replacement 1. Switch off the main power Caution – hot lamp. Let the lamp cool down, wait for at least 10 minutes before going further 2. -
Page 6: Technical Specification
SEARCHLIGHTS DHR 260DS Deck operated Notkestraße 97 · 22607 Hamburg Den Haan Rotterdam Rev. 1.0 Page 6 of 14 Technical specification • Tilt : + 55° / - 35° • Materials: - Material : Seawater resistant Aluminium - yellow chromatted - Finish : UV-resistant ‘qualicoat’... -
Page 7: Guarantee
SEARCHLIGHTS DHR 260DS Deck operated Notkestraße 97 · 22607 Hamburg Den Haan Rotterdam Rev. 1.0 Page 7 of 14 Guarantee For this DHR deck operated searchlight we grant a guarantee of 2 years. The guarantee begins with the day when the equipment is sold or before, when it is operated for the first time. The presentation of your invoice is your warranty. -
Page 8: Annex 1 - Dimensions Searchlight Dhr 260 - Deck Operated
SEARCHLIGHTS DHR 260DS Deck operated Notkestraße 97 · 22607 Hamburg Den Haan Rotterdam Rev. 1.0 Page 8 of 14 Annex 1 – Dimensions Searchlight DHR 260 – Deck operated The electrical construction of the searchlight is manufactured in accordance with international standard IEC 60598-1, conform the directives 73/23/EEC and 93/68/EEC. -
Page 9: Annex 2 - Wire Diagram With Halogen Lamp
SEARCHLIGHTS DHR 260DS Deck operated Notkestraße 97 · 22607 Hamburg Den Haan Rotterdam Rev. 1.0 Page 9 of 14 Annex 2 – Wire diagram with halogen lamp The electrical construction of the searchlight is manufactured in accordance with international standard IEC 60598-1, conform the directives 73/23/EEC and 93/68/EEC. -
Page 10: Annex 3 - Wire Diagram With Metal Halide Lamp - Slave Panel
SEARCHLIGHTS DHR 260DS Deck operated Notkestraße 97 · 22607 Hamburg Den Haan Rotterdam Rev. 1.0 Page 10 of 14 Annex 3 – Wire diagram with metal halide lamp - slave panel The electrical construction of the searchlight is manufactured in accordance with international standard IEC 60598-1, conform the directives 73/23/EEC and 93/68/EEC. -
Page 11: Annex 4 - Wire Diagram With Metal Halide Lamp - Remote Controlled
SEARCHLIGHTS DHR 260DS Deck operated Notkestraße 97 · 22607 Hamburg Den Haan Rotterdam Rev. 1.0 Page 11 of 14 Annex 4 – Wire diagram with metal halide lamp - remote controlled The electrical construction of the searchlight is manufactured in accordance with international standard IEC 60598-1, conform the directives 73/23/EEC and 93/68/EEC. -
Page 12: Annex 5 - Spare Parts Dhr260Ds - With Halogen Lamp 250W
SEARCHLIGHTS DHR 260DS Deck operated Notkestraße 97 · 22607 Hamburg Den Haan Rotterdam Rev. 1.0 Page 12 of 14 Annex 5 – Spare parts DHR260DS - With halogen lamp 250W The electrical construction of the searchlight is manufactured in accordance with international standard IEC 60598-1, conform the directives 73/23/EEC and 93/68/EEC. -
Page 13: Annex 6 - Spare Parts Dhr260Ds - With Metal Halide Lamp
SEARCHLIGHTS DHR 260DS Deck operated Notkestraße 97 · 22607 Hamburg Den Haan Rotterdam Rev. 1.0 Page 13 of 14 Annex 6 – Spare parts DHR260DS - With metal halide lamp The electrical construction of the searchlight is manufactured in accordance with international standard IEC 60598-1, conform the directives 73/23/EEC and 93/68/EEC. - Page 14 SEARCHLIGHTS DHR 260DS Deck operated Notkestraße 97 · 22607 Hamburg Schiffsausrüster Schiffsausrüster Tel.: +49 ( 0 ) 40 - 88 90 100 Tel.: +49 ( 0 ) 40 - 88 90 100 www.toplicht.de www.toplicht.de...
