TO THE OPERATOR:
BEFORE USING THE SPLITFIRE, SPEEDFIRE OR UPPERCUT. IT IS
ABSOLUTELY VITAL TO KNOW THE INFORMATION PRESENTED IN THIS
MANUAL IN ORDER TO USE THE MACHINES IN THE BEST WAY.
WITH THIS KNOWLEDGE AND A PROFESSIONAL APPROACH, YOU WILL BE
ABLE TO SOLVE MANY COMPLICATED CUTTING APPLICATIONS WITH THESE
SYSTEMS.
Rev. 4.2, 2012-11-01
SPT Plasmateknik AB
Transportvägen12
SE-241 38 Eslöv
Sweden
STATE OF THE ARC PLASMA CUTTING TECHNOLOGY
INSTRUCTIONS FOR USE
SPLITFIRE
SPEEDFIRE
UPPERCUT
With PTA 121 hand torch
PLEASE READ AND UNDERSTAND THIS MANUAL
+46 10-172 73 50
Telephone
Email
Internet
info@spt.se
www.spt.se

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPLITFIRE and is the answer not in the manual?

Questions and answers

Related Manuals for SPT Plasmateknik AB SPLITFIRE

Summary of Contents for SPT Plasmateknik AB SPLITFIRE

  • Page 1 With PTA 121 hand torch TO THE OPERATOR: PLEASE READ AND UNDERSTAND THIS MANUAL BEFORE USING THE SPLITFIRE, SPEEDFIRE OR UPPERCUT. IT IS ABSOLUTELY VITAL TO KNOW THE INFORMATION PRESENTED IN THIS MANUAL IN ORDER TO USE THE MACHINES IN THE BEST WAY.

  • Page 2: Table Of Contents

    SPLITFIRE SPEEDFIRE UPPERCUT CONTENTS Page TECHNICAL DATA INSTALLATION OPERATING INSTRUCTIONS CHANGING CONSUMABLES MAINTENANCE TROUBLE SHOOTING SAFETY INSTRUCTIONS WARRANTY RECYCLING...

  • Page 3: Technical Data

    SPLITFIRE SPEEDFIRE UPPERCUT 1. TECHNICAL DATA SPLITFIRE SPEEDFIRE UPPERCUT Power supply 400 V, 3~50 Hz 400 V, 3~50 Hz 400 V, 3~50 Hz Mains fuse 32 A slow blow 16 A slow blow 32 A slow blow Maximum power 10,4 kVA...

  • Page 4: Installation

    Use with generators SPLITFIRE, SPEEDFIRE and UPPERCUT are equipped with filters for use with mobile generators. The generator should be of at least 15 kVA for SPLITFIRE, 22 kVA for SPEEDFIRE and 27 kVA available exclusively for the plasma cutting system.

  • Page 5: Operating Instructions

     Switch the machine’s main power switch on. The READY lamp will light and the fan will start working.  Choose process power, 20-80 for SPLITFIRE, 20-100 A for SPEEDFIRE or 20-120 A for UPPERCUT.  Manouver the torch in position for cutting or gouging.

  • Page 6: Changing Consumables

    SPLITFIRE SPEEDFIRE UPPERCUT 4. CHANGING CONSUMABLES...
  • Page 7 Spanner PTA 120/121 899040 Torch PTA 121 6m complete 899041 Torch PTA 121 15m complete N.B. Don’t use consumables for more than 80 A with the SPLITFIRE or 100 A with the SPEEDFIRE. The result will be poor cutting capability.

  • Page 8: Maintenance

    SPLITFIRE SPEEDFIRE UPPERCUT 5. MAINTENANCE DAILY Inspect and, if necessary, change the torch consumable parts. Inspect and, if necessary, empty the moisture trap on the filter regulator on the rear side of the machine. The trap is emptied by pressing the bottom sealing while compressed air is connected.

  • Page 9: Trouble Shooting

    SPLITFIRE SPEEDFIRE UPPERCUT 6. TROUBLE SHOOTING. Thermal overload / Air supply failure If the fan is working, but the green READY-lamp is not lit, the air supply is not sufficient or the thermal overload protection is active. Check the compressed air supply. If the machine is overheated, let it cool down while switched on until the lamp lights again.

  • Page 10: Safety Instructions

    SPLITFIRE SPEEDFIRE UPPERCUT 7. SAFETY INSTRUCTIONS All endangerments through plasma cutting are related with the process itself. Endangerments may occur due to:  High contact voltage  HV ignition  Electromagnetic interferences  Heat and light radiation  Gases, fumes and smoke ...
  • Page 11 SPLITFIRE SPEEDFIRE UPPERCUT Endangerment through high voltage (HV) A HV-igniter starts the pilot arc. The HV-supply is cut-off automatically after pilot arc has struck. Attention! Never touch nozzle or nozzle cap when power source is switched ON! HV-ignition may establish electromagnetic fields and can influence: ...
  • Page 12 SPLITFIRE SPEEDFIRE UPPERCUT  Always keep cover plates and doors of the plasma machines closed  Avoid excessive length of cutting cables  Arrange potential equalisation between metallic parts around the installation (the operator has to be electrically isolated from those parts) ...
  • Page 13 SPLITFIRE SPEEDFIRE UPPERCUT  Allow cut material to cool down before handling.  Make fire extinguisher available in the cutting area. Handling of pressure cylinders In some cases compressed gases are required for the plasma cutting process. To avoid endangerments the following has to advised: ...

  • Page 14: Warranty

    SPLITFIRE SPEEDFIRE UPPERCUT 8. WARRANTY SPT Plasmateknik AB grants a 24 month warranty for its products. Validity The warranty applies to power sources manufactured by SPT Plasmateknik AB (SPT). The warranty period is 24 months from date of delivery to end user, but not more than 30 months from delivery from factory.

  • Page 15: Recycling

    SPLITFIRE SPEEDFIRE UPPERCUT Further, the warranty does not cover: Fault finding, direct or indirect travel costs, transport costs, travel costs, allowances, accommodation and such. SPT bears no responsibility whatsoever for consequential damages caused by fault in its products, such as, but not limited to, loss of revenue, damages to 3 party, production delays, penalties etc.
