- Page 1 LITTLE DAVID OWNERS MANUAL LD7D THE LOVESHAW CORPORATION LOVESHAW - EUROPE P. O. BOX 83, RT. 296 UNIT 9, BRUNEL GATE SOUTH CANAAN, PA 18459 W. PORTWAY INDUSTRIAL ESTATE ANDOVER, HAMPSHIRE SP103SL TEL: (570) 937-4921 ENGLAND FAX: (570) 937-4370 44-264-3575-11...
-
Page 2: Table Of Contents
MAIN FRAME BELT THREADING DIAGRAM HEAD ELECTRICAL SYSTEM LUBRICATION TROUBLE - SHOOTING TAPE CARTRIDGE WARRANTY ILLUSTRATED REPLACEMENT PARTS TABLE OF CONTENTS *NOTE: WHEN ORDERING PARTS FOR ST. STEEL MACHINE, ADD (SS) TO END OF PART NUMBER LOVESHAW an ITW Company... -
Page 3: General Safety Precautions
EDGE OF THE BOX. RELEASE HANDS AS SOON AS THE BELTS TAKE THE BOX. DO NOT WEAR JEWELRY, LOOSE CLOTHING, SUCH AS TIES, SCARVES, ETC. AND LONG HAIR SHOULD BE PULLED BACK WHEN OPERATING THE MACHINE. SAFETY GLASSES SHOULD BE WORN WHEN WORKING ON OR AROUND THE MACHINE. LOVESHAW an ITW Company... -
Page 4: Belt Lagging Installation
JOGGING THE MACHINE ON/OFF WHILE PULLING THE CUT STRIP OF LAGGING). REPLACE BELT AND CHECK ALIGNMENT. BELT WILL HAVE MOVED TO THE OPPOSITE SIDE THAT WAS CUT. THIS PROCEDURE MAY HAVE TO BE REPEATED UNTIL THE BELTS ARE CENTERED. LOVESHAW an ITW Company... -
Page 5: Machine Specifications
NUMBER OF BOXES/MIN.: VARIES WITH BOX SIZE CLOSURE MATERIAL - PRESSURE SENSITIVE TAPE WIDTH: 1.5 inches to 38 mm to 2 inches 50 mm MAX. ROLL DIAMETER: 15 inches 380 mm WEIGHT: (uncrated) 180 lbs. 81 kg. LOVESHAW an ITW Company... -
Page 6: Introduction
LOVESHAW CORPORATION BOX 83 ROUTE 296 SOUTH CANAAN, PA 18459 PHONE: 1-800-962-2633 / 570-937-4921 LOVESHAW - EUROPE UNIT 9 BRUNEL GATE WEST PORTWAY INDUSTRIAL ESTATE ANDOVER, HAMPSHIRE SP10 3SL ENGLAND ORE YOUR NEAREST LITTLE DAVID DISTRIBUTOR LOVESHAW an ITW Company... -
Page 7: Installation
CONVEYOR SHOULD BE PROVIDED AT THE OUT FEED END OF THE MACHINE TO RECEIVE THE BOXES AS THEY ARE DISCHARGED FROM THE MACHINE. IMPORTANT: BE SURE THE TABLE AND CONVEYOR ARE 1/4” (6 mm) BELOW THE MACHINE BELT HEIGHT. LOVESHAW an ITW Company... -
Page 8: Operation
CLOSED ON THE REAR OF THE BOX, SHOULD FEED THE BOX INTO THE MACHINE UNTIL THE BELTS TAKE IT FROM HIM. THE MACHINE WILL SEAL THE TOP AND BOTTOM FLAPS AND DISCHARGE THE BOX TO THE OUT FEED CONVEYOR AUTOMATICALLY. LOVESHAW an ITW Company... -
Page 9: Main Frame
REPLACED AT THE SAME TIME. IT IS IMPORTANT THAT FACTORY SUPPLIED BELTS BE USED SINCE THEY ARE OF SPECIAL CONSTRUCTION. BELT THREADING DIAGRAM PART NUMBER DESCRIPTION PSC301244-4 BELT PSC301217-4 DRIVE ROLLER PSC301232 BELT TENSIONING SPRING K286D GUIDE ROLLER PSC301208-5 INFEED ROLLER BRACKET PSC301211-4 INFEED ROLLER LOVESHAW an ITW Company... -
Page 10: Head
ADJUSTED, THE HEAD WILL BE PARALLEL TO THE BED OF THE MACHINE AND WILL NOT COCK ON THE MAST AND THE BEARINGS SHOULD RUN FREELY. MOVE THE HEAD THROUGH ITS FULL TRAVEL AND CHECK THAT THERE IS PROPER CLEARANCE AT THE HIGH POINTS. REPLACE HEAD COVER. LOVESHAW an ITW Company... -
Page 11: Electrical System
STARTER SWITCH. THE MOTORS AND FRAME ARE GROUNDED THROUGH THE ELECTRICAL CONNECTOR. THE CIRCUIT BREAKER IS FACTORY SET. IF IT TRIPS, IT SHOULD BE RESET AFTER INSPECTION OF THE ELECTRICAL SYSTEM. WARNING: THE INSPECTION OF THE ELECTRICAL SYSTEM SHOULD BE DONE BY A QUALIFIED ELECTRICIAN ONLY! LOVESHAW an ITW Company... -
Page 12: Lubrication
THE REDUCER USES 6 TO 8 OZS. OF SCH634. THE MAST SHOULD BE CLEANED AND SPRAYED WITH A SILICONE LUBRICANT - THIS SHOULD BE DONE ON A WEEKLY BASIS TO ENSURE FREE MOVEMENT OF THE HEAD. LOVESHAW an ITW Company... -
Page 13: Trouble Shooting
CHECK THE DRAG OF THE TAPE. TOO MUCH DRAG MAY CAUSE OVERRUNNING OF THE TAPE ROLL. ADJUST THE TAPE CORE DRAG SETTING. TAPE TENSION SET TOO HIGH. CHECK ROLLER STOP INSIDE CARTRIDGE. CHECK THAT THE TAPE IS PROPERLY THREADED AND THAT TAPE CORE IS PROPERLY CENTERED. LOVESHAW an ITW Company... - Page 14 IF KNIFE STOP BLOCK IS CAUSING FRICTION ON KNIFE STUDS, ROTATE UNTIL FREE. TAPE TENSION IS SET TOO LOW. TAPE NOT CENTERED ON BOX: USE SCREW IN CENTER OF TAPE CORE TO RE-ALIGN. TAPE NOT BEING WIPED: CHECK MAIN SPRING. TAPE TENSION IS SET TOO HIGH. LOVESHAW an ITW Company...
- Page 15 BOX SLIPS AGAINST BELTS: LOWER HEAD SLIGHTLY TO INCREASE PRESSURE ON BOX. BELTS RUB AGAINST FRAME: CHECK THAT BELTS ARE POSITIONED CORRECTLY IN BETWEEN THE BELT GUIDE ROLLERS. CHECK FOR MISSING OR BROKEN BELT TENSIONING SPRINGS. LOVESHAW an ITW Company...
-
Page 16: Tape Cartridge
NUT ON THE KNIFE ARM STUD AND ROTATING THE STUD UNTIL THE LARGE NUT CONTACTS THE BUMPER AT THE DESIRED SETTING. KNIFE ARM TENSION IS CONTROLLED BY THE COMPRESSION SPRING ON THE STUD. TIGHTEN THE NYLOK NUT FOR GREATER TENSION. ALWAYS POWER DOWN MACHINE FIRST. LOVESHAW an ITW Company... - Page 17 RAISE REAR OF CARTRIDGE AND MOVE CARTRIDGE UP AND OUT OF MACHINE. THREADING IS THE SAME AS TOP CARTRIDGE. GRABBING THE CARTRIDGE BY REAR ROLLER AND FRONT SHAFT, ANGLE FRONT OF CARTRIDGE ONTO MOUNTING BOLTS AND THEN LOWER REAR OF CARTRIDGE. LOVESHAW an ITW Company...
- Page 18 1 YEAR ALL OTHER PARTS (EXCEPT FOR WEAR AND MOVING PARTS.) *LIMITED WARRANTY – LOVESHAW, AN ITW COMPANY (HEREIN AFTER “LOVESHAW”) WARRANTS ONLY THAT THE GOODS SOLD BY IT SHALL BE FREE FROM DEFECTS IN MATERIAL AND WORKMANSHIP, UNDER PROPER AND NORMAL USE AND...
-
Page 19: Illustrated Replacement Parts Table Of Contents
ILLUSTRATED REPLACEMENT PARTS TABLE OF CONTENTS FRAME ASSEMBLY HEAD ASSEMBLY HEAD COUNTER BALANCE ASSEMBLY MAST ASSEMBLY SIDE RAIL ASSEMBLY INFEED ROLLER ASSEMBLY ELECTRICAL COMPONENT ASSEMBLY ELECTRICAL SCHEMATIC TAPE CARTRIDGE LOVESHAW an ITW Company... - Page 20 THIS DRAWING AND SUBJECT MATTER THEREON IS THE EXCLUSIVE PROPERTY OF DWG NO METRIC = .3mm FINISH LOVESHAW-ITW AND IS TO BE TREATED BY YOU AS CONFIDENTIAL PRPRIETARY .XXX = .1mm INFORMATION. THIS DRAWING OR SUBJECT MATTER THEROF SHALL NOT BE MATERIAL...
- Page 21 Parts List ITEM QT PART NUMBER DESCRIPTION 1 .CBAL301E HEAD COUNTER BALANCE 1 PSC127A-3 COVER, DETENT PLATE 1 PSC302301-6 HEAD WELDMENT 1 PSC301322 CLAMP SW. SCREW 5 LD12B-1022-4 SHAFT 8 PSC138-3 SPACER 1 PSC301324-3 CLAMP NUT-HEAD 1 PSC301330-6 HEAD FRAME OPER. SIDE 1 PSC301331L-5 HOLD DOWN RAIL LEFT 1 PSC301331R-5...
- Page 22 Parts List ITEM PART NUMBER DESCRIPTION LD12B-2008-3 CONSTANT FORCE SPRING SC75 COLLAR PSC302222-3 SHAFT SPRING MAST LD12B-2002B-4 DRUM SPRING DRAWN Dennisw 6/25/2002 CHECKED TITLE HEAD COUNTER BALANCE ASSY. APPROVED SIZE DWG NO .CBAL301E SCALE SHEET...
- Page 23 Parts List ITEM PART NUMBER DESCRIPTION PSC302218-4 MAST PLUG PSC302212-5 (*) MAST PSC302213-4 STRAP, MAST FRAME OPC302207-5 MAST (FOR HIGH OPTION ONLY) DRAWN Dennisw 6/24/2002 CHECKED TITLE MAST ASSEMBLY APPROVED SIZE DWG NO MST301E SCALE SHEET...
- Page 24 DWG NO .SRA7D SCALE METRIC = .3mm FINISH LOVESHAW-ITW AND IS TO BE TREATED BY YOU AS CONFIDENTIAL PRPRIETARY .XXX = .1mm INFORMATION. THIS DRAWING OR SUBJECT MATTER THEROF SHALL NOT BE MATERIAL CHECKED REPRODUCED OTHER THAN FOR YOUR OWN USE OR TO BE DISCLOSED TO OTHER...
- Page 25 Parts List ITEM PART NUMBER DESCRIPTION PSC301208-5 INFEED ROLLER BRACKET K286D ROLLER PSC301211-4 INFEED ROLLER PSC301224 BUSHING DRAWN Dennisw 6/25/2002 CHECKED TITLE INFEED ROLLER ASSEMBLY APPROVED SIZE DWG NO IRLRA301 SCALE SHEET...
- Page 26 Parts List ITEM QT PART NUMBER DESCRIPTION 1 PSC301238 REDUCER 1 PSC634A MOTOR 1 A204 CONNECTOR (NOT SHOWN) 1 PSC614 BELT LAGGING (NOT SHOWN) 1 PSC301241-4 MOTOR CABLE (NOT SHOWN) 1 PSC301235-GE MOTOR STARTER (NOT SHOWN) 1 PSC505A-115-4 LINE CABLE (NOT SHOWN) 1 PSC611 STRAIN RELIEF (NOT SHOWN) 1 PSC636G-GE...
- Page 28 LITTLE DAVID TAPE CARTRIDGE MANUAL .CAC50 THE LOVESHAW CORPORATION LOVESHAW - EUROPE P. O. BOX 83, RT. 296 UNIT 9, BRUNEL GATE SOUTH CANAAN, PA 18459 W. PORTWAY INDUSTRIAL ESTATE ANDOVER, HAMPSHIRE SP103SL TEL: (570) 937-4921 ENGLAND FAX: (570) 937-4370 44-264-3575-11...
- Page 29 THIS DRAWING AND SUBJECT MATTER THEREON IS THE EXCLUSIVE PROPERTY OF DWG NO METRIC = .3mm FINISH LOVESHAW-ITW AND IS TO BE TREATED BY YOU AS CONFIDENTIAL PRPRIETARY .XXX = .1mm INFORMATION. THIS DRAWING OR SUBJECT MATTER THEROF SHALL NOT BE MATERIAL...
- Page 30 THIS DRAWING AND SUBJECT MATTER THEREON IS THE EXCLUSIVE PROPERTY OF DWG NO METRIC = .3mm FINISH LOVESHAW-ITW AND IS TO BE TREATED BY YOU AS CONFIDENTIAL PRPRIETARY .XXX = .1mm INFORMATION. THIS DRAWING OR SUBJECT MATTER THEROF SHALL NOT BE MATERIAL...
- Page 31 THIS DRAWING AND SUBJECT MATTER THEREON IS THE EXCLUSIVE PROPERTY OF DWG NO = .3mm METRIC FINISH LOVESHAW-ITW AND IS TO BE TREATED BY YOU AS CONFIDENTIAL PRPRIETARY .XXX = .1mm INFORMATION. THIS DRAWING OR SUBJECT MATTER THEROF SHALL NOT BE MATERIAL...
- Page 32 THIS DRAWING AND SUBJECT MATTER THEREON IS THE EXCLUSIVE PROPERTY OF DWG NO = .3mm METRIC FINISH LOVESHAW-ITW AND IS TO BE TREATED BY YOU AS CONFIDENTIAL PRPRIETARY .XXX = .1mm INFORMATION. THIS DRAWING OR SUBJECT MATTER THEROF SHALL NOT BE MATERIAL...
- Page 33 THIS DRAWING AND SUBJECT MATTER THEREON IS THE EXCLUSIVE PROPERTY OF DWG NO METRIC = .3mm FINISH LOVESHAW-ITW AND IS TO BE TREATED BY YOU AS CONFIDENTIAL PRPRIETARY .XXX = .1mm INFORMATION. THIS DRAWING OR SUBJECT MATTER THEROF SHALL NOT BE MATERIAL...
- Page 34 THIS DRAWING AND SUBJECT MATTER THEREON IS THE EXCLUSIVE PROPERTY OF DWG NO METRIC = .3mm FINISH LOVESHAW-ITW AND IS TO BE TREATED BY YOU AS CONFIDENTIAL PRPRIETARY .XXX = .1mm INFORMATION. THIS DRAWING OR SUBJECT MATTER THEROF SHALL NOT BE MATERIAL...
- Page 35 THIS DRAWING AND SUBJECT MATTER THEREON IS THE EXCLUSIVE PROPERTY OF DWG NO METRIC = .3mm FINISH LOVESHAW-ITW AND IS TO BE TREATED BY YOU AS CONFIDENTIAL PRPRIETARY .XXX = .1mm INFORMATION. THIS DRAWING OR SUBJECT MATTER THEROF SHALL NOT BE MATERIAL...
- Page 36 THIS DRAWING AND SUBJECT MATTER THEREON IS THE EXCLUSIVE PROPERTY OF DWG NO METRIC = .3mm FINISH LOVESHAW-ITW AND IS TO BE TREATED BY YOU AS CONFIDENTIAL PRPRIETARY .XXX = .1mm INFORMATION. THIS DRAWING OR SUBJECT MATTER THEROF SHALL NOT BE MATERIAL...
- Page 37 THIS DRAWING AND SUBJECT MATTER THEREON IS THE EXCLUSIVE PROPERTY OF DWG NO METRIC = .3mm FINISH LOVESHAW-ITW AND IS TO BE TREATED BY YOU AS CONFIDENTIAL PRPRIETARY .XXX = .1mm INFORMATION. THIS DRAWING OR SUBJECT MATTER THEROF SHALL NOT BE MATERIAL...
- Page 38 THIS DRAWING AND SUBJECT MATTER THEREON IS THE EXCLUSIVE PROPERTY OF DWG NO METRIC = .3mm FINISH LOVESHAW-ITW AND IS TO BE TREATED BY YOU AS CONFIDENTIAL PRPRIETARY .XXX = .1mm INFORMATION. THIS DRAWING OR SUBJECT MATTER THEROF SHALL NOT BE MATERIAL...
- Page 39 THIS DRAWING AND SUBJECT MATTER THEREON IS THE EXCLUSIVE PROPERTY OF DWG NO = .3mm METRIC FINISH LOVESHAW-ITW AND IS TO BE TREATED BY YOU AS CONFIDENTIAL PRPRIETARY .XXX = .1mm INFORMATION. THIS DRAWING OR SUBJECT MATTER THEROF SHALL NOT BE MATERIAL...
- Page 40 THIS DRAWING AND SUBJECT MATTER THEREON IS THE EXCLUSIVE PROPERTY OF DWG NO SCALE = .3mm METRIC FINISH LOVESHAW-ITW AND IS TO BE TREATED BY YOU AS CONFIDENTIAL PRPRIETARY .XXX = .1mm INFORMATION. THIS DRAWING OR SUBJECT MATTER THEROF SHALL NOT BE CHECKED MATERIAL...
- Page 41 REVISION HISTORY DESCRIPTION DATE RELEASED 7/3/2003 AMYR Parts List ITEM QTY PART NUMBER DESCRIPTION PSC28-3 BRAKE WASHER PSC88-3 TAPE CORE SPRING CAC50-096-4 TAPE CORE SHAFT (THREADED) PSC142-3 TAPE CORE NUT PSC144-3 TAPE HOLDER CAC50-095-3 HEX LOCK NUT PSC30A-5 TAPE CORE CASTING PSC33B-3 COMPRESSION SPRING MS7M3-5...
- Page 42 TAPE CORE ASSEMBLY ADJUSTMENT PROCEDURES (.TCA201 = 3” TAPE CORE AND .TCA301 = 2” TAPE CORE) STEP 1: UNLOCKING THE TAPE CORE FOR ADJUSTMENT: THERE IS A LOCKING BOLT USED TO MAINTAIN THE HEIGHT ADJUSTMENT OF THE TAPE CORE. THIS MUST BE LOOSENED TO CHANGE THE HEIGHT OF THE TAPE CORE.
