BATHROOM FURNITURE FITTING GUIDE
Note: For safety reasons Unit must be secured to the wall using
suitable fixings (pre-drilled holes provide in back panel of unit)
When fitting a basin to a unit, a bead of silicone should be applied
to the top edge of the basin unit to seal between the basin and unit.
Tools required for installations
Advertisement
Table of Contents
Summary of Contents for Empire BeBa 25825
- Page 1 BATHROOM FURNITURE FITTING GUIDE Tools required for installations Note: For safety reasons Unit must be secured to the wall using suitable fixings (pre-drilled holes provide in back panel of unit) When fitting a basin to a unit, a bead of silicone should be applied to the top edge of the basin unit to seal between the basin and unit.
- Page 2 Hinge Adjustment C-Horizontal A-Vertical B-Lateral Loosen screw‘A’on all Loosen screw‘B’.Adjust Loosen screw ‘B’ ½ turn. hinges. Adjust door and door and retighten screw. Turn screw‘C’until door is retighten screw. positioned correctly and retighten screw‘B’. Drawers Remove/Install To Remove the metal drawer: press the button as follow Step A, then pull out in level position ; To Install the metal drawer: press the button as follow Step A, then push in in level position Drawer position: if drawer position needs altering follow Step B or C according to the drawer positon on unit.
- Page 4 Wall hung unit installation. ( fixings in box) Please measure the L distance between each brackets on unit. and H ( height as customers request. The standard height is 850mm (including basin height) from floor to wash basin request hight handle in middle position Mirror cabinet and Storage unit.
