- Page 1 Hardware Reference Manual Document Number: 100092-00 Revision F March 2016...
-
Page 2: Table Of Contents
Contact Information ........................18 8.2. Warranty Information ........................18 8.3. Calibration Notice ........................19 8.4. Return Material Authorization Procedure for the SeeGull EXflex Scanning Receiver ....19 Accessories and Service Options ....................20 9.1. Accessories ..........................20 9.2. Service Options ..........................20 PCTEL, Inc. - Page 3 List of Figures Figure 1 - SeeGull EXflex Scanning Receiver ....................... 7 Figure 2 - Front View of SeeGull EXflex Scanning Receiver Showing Connections ............. 7 Figure 3 - SeeGull EXflex Scanning Receiver top view....................11 Figure 4 - SeeGull EXflex Scanning Receiver side view ..................... 11 Figure 5 - SeeGull EXflex Scanning Receiver rear view .....................
-
Page 4: Preface
E-UTRA 26 (Upper Ext 850 MHz) analyze wireless market data. E-UTRA 27 (Lower Ext 850 MHz) The SeeGull EXflex Scanning Receiver is a E-UTRA 28 (700 MHz APAC) software-defined receiver, capable of E-UTRA 29 (US 700 MHz) ... - Page 5 Blind Scan C/I (Co-Channel Interference) UMTS [WCDMA/HSPA(+)] Blind Scan is available for LTE FDD, Maximum # of Channels: 24 TD-LTE, UMTS [WCDMA/HSPA], GSM, Top N Scan CDMA, EV-DO and TD-SCDMA PCTEL, Inc., RF Solutions Page 5 Revision F...
-
Page 6: Notices
The scanning receiver itself is not intended for “in weather” outdoor use. NOTICE: There are no user serviceable parts inside the SeeGull EXflex Scanning Receiver. 1.4. Compliance RoHS Compliance The PCTEL SeeGull EXflex Scanning... -
Page 7: Overview And System Requirements
Section 4 for more details.) USB Interface Power Input System Status LED Figure 2 - Front View of SeeGull EXflex Scanning Receiver Showing Connections Figure 1 - SeeGull EXflex Scanning Receiver PCTEL, Inc., RF Solutions Page 7 Revision F... -
Page 8: Options
RSSI Optional multi-technology measurements measurements use analog and digital filters available for the SeeGull EXflex are to select the right frequency band and described below. These options can be subsequently measure total power. - Page 9 MIB and SIBs 1-13. In the UMTS [WCDMA/HSPA(+)] BCH, the MIB and SIBs 1, 2, 3, 5, 7, 11 and 19 are The SeeGull EXflex supports scanning of available.. In the TD-SCDMA the MIB and numerous GSM and LTE BCCH,andUMTS...
-
Page 10: System Requirements
The scanning receiver should be powered with the SeeGull EXflex Scanning Receiver. through the power cord provided by PCTEL. However, in most cases, a typical If another power cord is used, the power... -
Page 11: Installation
There are sixteen (16) mounting holes (4-40 screw) on the chassis of the unit that are used for mounting in the user’s Figure 4 - SeeGull EXflex Scanning Receiver side enclosure/rack. Note that the maximum view depth of screw insertion from the chassis exterior is ¼”. -
Page 12: Setup
6. The system is ready for use. 1. SMA Connector to RF antenna 2. SMB Connector to GPS antenna 4. Power connector 3. USB data connector Figure 6 - SeeGull EXflex Scanning Receiver front display PCTEL, Inc., RF Solutions Page 12 Revision F... -
Page 13: Operation
Note: It is highly recommended to have the SeeGull EXflex Scanning Receiver recalibrated every year. 4.2. Software Upgrades SeeGull EXflex scanning receiver stores the application program in internal non-volatile memory, and accordingly, is capable of being upgraded via software. Upgrades may be needed to incorporate new features or bug fixes. -
Page 14: Rf Antenna Information
SMA connector 5. RF Antenna Information for the RF, as shown in Figure 7. This section discusses antennas that are used with the SeeGull EXflex Scanning Receiver system. 5.1. Antenna Verification Verify that all the necessary antennas are included in the shipment and that each is marked. -
Page 15: Gps Antenna Information
GPS. Figure 10 - OP379H 5.3. GPS Antenna Information PCTEL offers a single standalone GPS antenna, the OP034H. The OP034H is a High Gain GPS standalone antenna which comes standard with a magnetic mounting base and a SMB connector. See Figure 11 Figure 11 - OP034H PCTEL, Inc., RF Solutions... -
Page 16: Walk Test Kit Information
The PCTEL SeeHawk Walk Test Kit comprises a complete set of accessories 6.2. Indoor RF Antenna Information that enable the indoor use of the PCTEL PCTEL offers wideband rubber duck style SeeGull EXflex Scanning Receiver. The antennas for indoor use. There are three... -
Page 17: Troubleshooting
Fuse Holding Nut If the SYS LED located on the face of the scanning receiver is not illuminated, please Figure 13 - SeeGull EXflex Scanning Receiver check the connection first, then the fuse, Power Plug which is located in the cigarette lighter end of the power cord. -
Page 18: Support
Buyer for breach of +1-301-515-0036 ALES warranty and shall constitute fulfillment of all liabilities of PCTEL with respect to the Table 1: Phone Numbers quality and performance of the Products. PCTEL shall have no obligation to make... -
Page 19: Calibration Notice
The calibration data is stored in the internal non-volatile memory in 1 dB steps for the whole input All repairs must be performed by PCTEL in signal dynamic range. Recalibration is accordance to the procedure outlined... -
Page 20: Accessories And Service Options
ANT, 450-512 MHZ MULTI-BAND MAG. MOUNT, OP138 SPARE EU BATTERY POWER CORD OP123 HIGH PERFORMANCE Table 5: SeeGull EXflex Walk Test Kit Accessories ANT, 698-3800 MHZ MULTI-BAND MAG. MOUNT, OP278H HIGH PERFORMANCE ANT, 698-3800 MHZ MULTI-BAND MAG. MOUNT W/ OP379H... -
Page 21: Table 6: Seegull Exflex Calibration Service
SEEGULL EXFLEX RECEIVER FULL CALIBRATION: OPS132 SEEGULL EXFLEX RECEIVER EXTENDED CALIBRATION REPORT: OPS133 EXFLEX RECEIVER Table 6: SeeGull EXflex Calibration Service Fixed Cost Repair Service Part Description Number RMA EVALUATION FEE: QUOTED TO CUSTOMERS WITH UNITS OUTSIDE OF WARRANTY WHO SEND UNITS IN FOR EVALUATION. - Page 22 This document contains proprietary information that is protected by copyright; it is intended for use by PCTEL and its customers only. It is not to be disclosed to a third party. All rights reserved. No part of this document may be photocopied or reproduced in any way without the prior written permission of PCTEL, Inc.
