We Engineer Confidence
®
1RK-SPDR-STRIP-23
ONErack Spider Strip
1RK-SPDR-HALF-7
ONErack Spider Half
User Guide
MNL-1RK-SPDR-V1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1RK-SPDR-STRIP-23 and is the answer not in the manual?

Questions and answers

Summary of Contents for Tvone 1RK-SPDR-STRIP-23

  • Page 1 ® We Engineer Confidence ® 1RK-SPDR-STRIP-23 ONErack Spider Strip 1RK-SPDR-HALF-7 ONErack Spider Half User Guide MNL-1RK-SPDR-V1.0...
  • Page 2 In this guide Introduction ....................1 Product Features ..................1 In the box ..................... 2 Locking Mains Lead .................. 2 Using the ONErack Spider PSU’s ..............3 Power Modules ..................3 Setting the Output Voltage ..............3 Preparing the Lead ................... 4 Status LED’s ....................
  • Page 3 The ONErack spider can be installed at the back or side of the rack to provide the ultimate installation flexibility. There are 2 ONErack Spider PSU available: - 1RK-SPDR-STRIP-23 ONErack Spider Vertical Strip 1RK-SPDR-HALF-7 ONErack Spider Half Rack This manual describes operation of both units.
  • Page 4 If you replace the AC Mains lead, or wish to use your own, its recommended to use leads with a locking feature. In the unlikely event that a component is missing or damaged, please contact tech.usa@tvone.com or tech.europe@tvone.com. tvONE...
  • Page 5 Using the ONErack Spider PSU’s Both models have Power Modules fitted, status LED’s and a power Meter. The power modules need to be configured to the required voltage of your 3 party equipment, and you can use the LED’s and Power Meter to check the status, and diagnose faults as explained here.
  • Page 6  no LEDs illuminate, please contact tech.usa@tvone.com or tech.europe@tvone.com. The fuse has tripped. If the PSU and FUSE LED’s are both lit, the internal DC Overload fuse of the ONErack Spider PSU has tripped. This is probably due to too many loads attached that exceed the rating of the model you have chosen.
  • Page 7 Power Module Status LED The Power Module has its own Green status LED, Normally on. If it is off the load may have exceeded the 35W Max. To reset the fuse without turning off the Main PSU Remove the loads connected to this Power Module. Unscrew and partly slide out the power module.
  • Page 8 Information in this document is subject to change without notice. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or any means electronic or mechanical, including photocopying and recording for any purpose other than the purchaser's personal use without the written permission of tvONE. Copyright © 2021 tvONE™. All rights reserved.
