BIO-UV range
for Swimming pools and Spas
UV10
UV20
UV30
UV40
INSTALLATION AND USER MANUAL
Company BIO-UV SA
ZAC La Petite Camargue
34400 LUNEL - France
Phone: +33 (0)4 99 133 911
www.bio-uv.com
Email :
export@bio-uv.com
Gamme_Piscine_Monolampe_(Anglais_SansChimie).doc, version A, edition du 24/11/2011
Copyright BIO-UV
Marque, Modèles et Brevets déposés – Modèles exclusifs
Page 1/ 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for BIO UV BIO-UV Series
Summary of Contents for BIO UV BIO-UV Series
- Page 1 BIO-UV range for Swimming pools and Spas UV10 UV20 UV30 UV40 INSTALLATION AND USER MANUAL Company BIO-UV SA ZAC La Petite Camargue 34400 LUNEL - France Phone: +33 (0)4 99 133 911 www.bio-uv.com Email : export@bio-uv.com Gamme_Piscine_Monolampe_(Anglais_SansChimie).doc, version A, edition du 24/11/2011 Copyright BIO-UV Marque, Modèles et Brevets déposés –...
-
Page 2: Certificat De Conformite
CERTIFICAT DE CONFORMITE CERTIFICATE OF CONFORMITY Ce certificat confirme que tous les appareils conçus et fabriqués par la société BIO-UV SA depuis le 01/06/2000 sont conformes a toutes les directives CEE particulièrement en matière de directives C.E.M Electriques. This certificate confirm that all products manufactured by BIO-UV SA for sale after June 2000 will comply with the requirements of all relevant EEC directives. - Page 3 We thank you for choosing a BIO-UV ultraviolet water treatment system. Our equipment has been designed to offer you operational reliability in total confidence for many years. CONTENTS Page Safety Warning Exploded view Dimensions Standard installation ...
-
Page 4: Safety Warning
Safety Warning NEVER LOOK AT THE ULTRAVIOLET LAMP WHEN LIT WITHOUT USING PROTECTIVE GOGGLES AS IT COULD CAUSE SEVERE INJURIES, BURNS OR EVEN BLINDNESS. NEVER UNDO THE STAINLESS STEEL TIGHTENING NUT WITH THE FILTRATION RUNNING, AS THE QUARTZ SLEEVE COULD BE EXPELLED FROM ITS HOLDER AT SPEED AND INJURE YOU Before attempting to access the connection terminals, all power supplies should be disconnected. - Page 5 Sterilizer – Exploded view REACTOR UV 10 Ref PMI Description JTS003934 Quartz_Guide PIE001949 Switch BAL001422 Ballast_lw20eb65 QUA000016 Quartz sleeve_d25x594mm LPE000003 UV Lamp JTS000100 O-ring Ø25x5 PIE000659 Washer USI000018 ELE000001 Socket ELE000311 Carter_174x249x100 Lamp operating indicator ELE000817 with LED ACC000967 Grounding lug REACTOR UV 20 Ref PMI Description...
- Page 6 Dimensions DIMENSIONS in mm (excepted K) Model UV 10 275,5 2133 62,5 1"1/2 UV 20 545,5 62,5 1"1/2 UV 30 771.5 82,5 2" UV 40 1196 82,5 1083 2"1/2 1025,5 Gamme_Piscine_Monolampe_(Anglais_SansChimie).doc, version A, edition du 24/11/2011 Copyright BIO-UV Marque, Modèles et Brevets déposés – Modèles exclusifs Page 6/ 6...
-
Page 7: Standard Installation
Standard Installation BIO-UV BIO-UV DOSING Ø50 ou 63 ou 75 UNION PUMP REGULAT INJECTION BIO-UV BY-PASS VALVE pH PROBE HEATING BY-PASS VALVE SWIMMIN G POOL FILTRE PUMP BY-PASS VALVE RECOMMANDATIONS Install the BIO-UV equipment in the equipment room, respecting the 0.1 and 2 safety areas around the volume in accordance with the current installation rules (NF C15100) Unless the equipment is dismantled in order to change the lamps and clean the quartz sleeves, leave enough room to remove the lamps –... -
Page 8: Electrical Connections
ELECTRICAL CONNECTIONS IMPORTANT The connections must be made by a qualified technician. A 30mA differential circuit breaker must be present and a fuse or a circuit breaker must be installed. The power supply must correspond to that shown on the label on the side of the equipment. The power supplied to the pH regulator must be servo-controlled by the filtration. - Page 9 2°/ Particular case : you have a contactor with a coil not supplied with 220-240Vac : • Take a relay (not provided) which must : - have the same tension on its coil as on the contactor coil, - allow at least 5 amperes on its contacts. •...
-
Page 10: Wiring Diagram
WIRING DIAGRAM UV 10 I ON/OFF SWITCH OPERATING INDICATOR LIGHT UV 20 – UV 30 – UV40 ON/OFF SWITCH OPERATING INDICATOR LIGHT N = Neutral / L = Live / PE = Earth Gamme_Piscine_Monolampe_(Anglais_SansChimie).doc, version A, edition du 24/11/2011 Copyright BIO-UV Marque, Modèles et Brevets déposés –... -
Page 11: Maintenance
Maintenance (See exploded view on p6-7) Cleaning the quartz sleeve: Cleaning the quartz sleeve: Cleaning the quartz sleeve: Cleaning the quartz sleeve: The ultraviolet lamps are designed to last for 13,000 hours or be switched on 1,000 times, i.e. approximately 2 Every year you must check that the quartz sleeve has not years for a seasonal outdoor pool, or 1 year for an indoor become opaque due to scale deposits. - Page 12 Guarantees The guarantee for the BIO-UV equipment range applies as follows: 5 years for the stainless steel reactor (materials and weld) other than in the case of use in a highly corrosive environment (brackish or very salty environment, e.g.: seawater), 2 years for all other components, except for the UV lamp (13 000 hours, depending on the number of switchings on/off)
