- Page 2 Installation manual Montageanleitung ● Notice de montage ● Istruzioni per il montaggio ● Monteringsanvisning Pavilion PAY44-5742 Pavillon ● Pavillon ● Padiglione ● Lysthus Width 571 x Depth 421 x Height 371 cm Breite/Tiefe/Höhe ● largeur/profondeur/hauteur ● lunghezza/profondita/altezza vid /dyp/høyde ●...
-
Page 3: Preparation For Assembly
Installation manual - English Garden pavilion painting and maintenance Wood is a natural material, growing and adapting depending on weather conditions. Large and small cracks, colour tone differences and changes, as well as a changing structure of wood are not errors, but a result of wood growing and a peculiarity of wood as a natural material. -
Page 4: Base Frame
Installation manual - English Foundation A good foundation is the most important aspect guaranteeing the duration and safety of your pavilion. Only a completely level and bearing foundation will ensure problem-free installation of the pavilion, its stability and especially the matching of the doors. With a good foundation, your pavilion will stand for many years more. - Page 5 Installation manual - English Walls When installing the walls, it is important to remember that: The logs are always assembled with their tongue upwards! If necessary, use the hitting block and hammer! Never directly hit the tongue with the hammer! Install the walls in accordance with the appended wall plans (see Technical specifications).
-
Page 6: Door And Window
Make sure that the part of the frame with the deeper notch is installed upwards. The lateral jamb parts have hinges and are mirrored. It is recommended to install the leaves later. Assembly of the double window and double door: Window: Door ver. 1 (PAY44-4242).: Door ver. 2. (PAY44-5742):... - Page 7 151 must be screwed (5x90 mm screw) to walls as shown on the drawing. In case of pavilion PAY44-5742 you must screw part pos. 151 and part pos. 152 (5x90 mm screw) to walls as shown on the drawing.
- Page 8 Assembly of eave edgings Attach the eave edgings pos. 100 (in pavilion PAY44-5742 pos. 100 and pos. 101) to the roof elements with screws. Use 4.5x50 mm screws. Ideally the top side of the eave edging should be on the same line with the top side of the roof board.
-
Page 9: General Advice
Installation manual - English Storm braces The storm braces (pos. 140) must be attached in the corners of the pavilions on the both sides of the wall. Fix the storm braces with 6x110 bolts, shims and nuts. The top of the storm brace (with the round hole) has to be on the same level with the top log of the wall.
