ROCKINGER Monitor-Set
zum Aufrüstsatz Drawbar Finder
ROCKINGER Monitor Set
for the upgrade kit Drawbar Finder
ROCKINGER set de Moniteur
par kit d'équipement
de Drawbar Finder
Montage- und Betriebsanleitung
Installation and operating instructions
Instructions de montage et d'utilisation
Member of JOST World
DE
EN
FR
Advertisement
Table of Contents
Summary of Contents for Rockinger RO RC-PC Series
- Page 1 Montage- und Betriebsanleitung Installation and operating instructions Instructions de montage et d’utilisation Member of JOST World ROCKINGER Monitor-Set zum Aufrüstsatz Drawbar Finder ROCKINGER Monitor Set for the upgrade kit Drawbar Finder ROCKINGER set de Moniteur par kit d’équipement de Drawbar Finder...
-
Page 3: Table Of Contents
Table of contents Monitor Set ROCKINGER Monitor Set Safety instructions for Drawbar Finder Upgrade Kit as optional equipment for upgrade kits and remote control for use with: 1. Installation 17 – 18 RC-PC and RC-PL-2.0 1.1 Before installation for types RO... -
Page 4: Rc-Pc And Ro I Rc
Clean the device with a soft, slightly moistened cloth. Use a mild household detergent. Never use strong solvents, such as thinners or benzene, as these could damage the paint on the device. ROCKINGER 4 1 6 Member of JOST World... -
Page 5: Installation
If your vehicle has been par- Fig . 2 Scope of delivery of ROCKINGER Drawbar Finder Monitor ked in direct sunlight for a longer period and the inside temperature has risen considerably, you must allow the device to cool down before use. -
Page 6: System Connections
Route and secure the wiring harness so that it cannot chafe or get trapped. Fuse Camera (not supplied) CA 1 12 / 24 V CA 2 CA1 TRI CA 2 TRI Fig . 4 System connections ROCKINGER 4 1 8 Member of JOST World... -
Page 7: Operation
4. To return to the main menu from the submenu, press the Menu button for more than 2 seconds. ˆ Input cable – Mounting rail ı Loudspeaker Fig . 5 View of monitor ROCKINGER Member of JOST World... -
Page 8: Display Menu / Main Menu
– Setting the Auto Scan function – Advanced menu Note: If you connect a trigger line (see page 18), you will no longer be Fig . 7 Main menu able to open the main menu. ROCKINGER 4 2 0 Member of JOST World... -
Page 9: Camera Settings
2. You can change the UP/DOWN image of the camera (separate control of CAM 1/CAM 2). 3. Each camera can be named, and the name of the selected camera is shown on the OSD. Fig. 8 Camera settings ROCKINGER Member of JOST World... -
Page 10: Trigger Settings
Here, you can move the marker Left/Right and Up/Down, or expand it. Note: If “MARKER” is set to “OFF”, the parking assistant marker is not shown when the vehicle is shifted into reverse gear. Fig . 10 Marker ROCKINGER 4 2 2 Member of JOST World... -
Page 11: Autoscan Settings
“ON” setting: The monitor is switched on automatically when the ignition is switched on, regardless of which mode was last enabled before the ignition was switched off. Fig. 12 Advanced menu Factory Reset: Reset to the factory settings. ROCKINGER Member of JOST World... -
Page 12: Maintenance / 4. Problems
Incorrect signal input Select camera CA 2 with the selected on the monitor Select button Wrong camera image See chapter 2.3: on the monitor (shown Wrong menu setting Camera settings back-to-front) ROCKINGER 4 2 4 Member of JOST World... -
Page 13: Disposal
Please pay attention to the local regulations, and do not dispose of your old equipment with normal household waste. The correct disposal of your old equipment will help to prevent possible negative conse- Fig. 13 Disposal quences for the environment and people’s health ROCKINGER Member of JOST World... - Page 14 JOST-Werke Deutschland GmbH · Siemensstr. 2, D-63263 Neu-Isenburg · Tel. +49 (0) 61 02 2 95 - 0 · Fax +49 (0) 61 02 2 95 -298 · www.jost-world.com MUB 016045 M 20 (REV --) 09/2020...
